UG-474

ORDERING INFORMATION

BILL OF MATERIALS

Table 1.
Qty Reference Designator
3 CVCC3, CVEE3, CD3
3 CVCC2, CVEE2, CD2
3 CVCC1, CVEE1, CD1
2 CPD, CVOM
4 −IN, +IN, −OUT, +OUT
4 VCC, VEE, VOCM, PD
10 RTN, RTP, RGP, RGN, RFP, RFN, ROP1, RON1, ROP2, RON2
8 TVCC, TVEE, TVOCM, TPD, GND1 to GND4
1 DUT
1 PCB

RELATED LINKS

Table 2.
Resource Description
ADA4940-1 Product Page, Ultralow Power, Low Distortion Differential ADC Driver
AD8131 Product Page, Low Cost, High Speed Differential Driver with a Fixed Gain of 2
AD8132 Product Page, Low Cost, High Speed Differential Amplifier
AD8137 Product Page, Low Cost, Low Power Differential ADC Driver
AD8138 Product Page, Low Distortion Differential ADC Driver
AD8139 Product Page, Ultralow Noise, Rail-to-Rail Differential ADC Driver
Description
Capacitor, 10 µF
Capacitor, 0.1 µF
Capacitor, 0.1 µF
Capacitor/resistor
Side launch SMA connector
Vertical launch SMA connector
Resistor, user-defined value
Test point
Device under test
PC board
Rev. 0 | Page 6 of 8
Evaluation Board User Guide
Package
C1206
C0508
C0402
C0402
SMA/SMT
SMA/SMT
R0603
TP1
8-lead SOIC
