Label Placement

Cybex Owner's Manual
770A-331-4
DE-17219-4 (2)
750A-372-4
1.80
R .12
4 PLACES
CAUTION
SAFETY YELLOW PMS 108 CAUTION
BACKGROUND BLACK TRIANGLE
W/ YELLOW EXCLAMATION POINT,
1.25 Moving parts. Moving parts.
BLACK LETTERS 18.9 PT ARIAL BLACK FONT
Keep hands away Keep hands away
when in use. when in use.
DE-17219-4 B DE-17219-4 B
PART NUMBER
6.5 PT ARIAL TEXT
MASTER
ARTWORK
WHITE BACKGROUND WITH
BLACK 12 PT ARIAL TEXT
(SPECS)
MATERIAL: EXCEPT AS NOTED
DIMENSIONS REMOVE ALL BURRS OWATONNA
IN INCHES BREAK SHARP EDGES
.005/.010 R TITLE:
GENERAL
TOLERANCES: SURFACE FINISH DECAL, CAUTION MOVING PARTS
ALL MATERIAL MUST COMPLY TO
2 DECIMALS ± .03 INDICATED PER
EUROPEAN UNION DIRECTIVE ANSI B46.1-1985
2002/95/EC RoHS (RESTRICTION 3 DECIMALS ± .015 DWG. BY DATE TECH. PUBS. APPR. DATE
OF HAZARDOUS SUBSTANCES) ANGLES ± 1° REMOVE CARBURIZATION JT 7-22-03
AND SCALE FROM LASER CHECKED BY DATE MFG. APPR. DATE
FINISH: FEATURES SHOWN AND PLASMA CUT EDGES
PERPENDICULAR OR
125
PARALLEL SHALL BE GENERAL SIZE SCALE SHEET DWG. NO. REV.
SO WITHIN ± 1° MACHINING B 1:1 1 1 OF DE-17219-4 B
9
770A-332-4
CAUTION
Moving parts.
Keep hands away
when in use.
DE-17219-4 A
DE-17155-4
