PARTS NAME

INDOOR UNIT
OUTDOOR UNIT
OM_AY-AP9NRH_EN.indd Sec1:2
OM_AY-AP9NRH_EN.indd Sec1:2
1
1 Air Inlet
2
2 Open Panel
3
3 Air Filter
4 AUX Button
4
5 Receiver Window
6 Power Supply Cord
5
7 Vertical Airflow Louvre
8 Horizontal Airflow Louvre
6
9 Air Outlet
7
8
9
10 PLASMACLUSTER Lamp
10
(blue
11
12
11 OPERATION Lamp (red
13
12 TIMER Lamp (orange
13 TURBO Lamp
(green
14 Air Inlet
14
15 Refrigerant Pipe and
15
Interconnecting Cord
16 Drainage Hose
16
17 Air Outlet
NOTE:
Actual units might vary slightly
17
from those shown above.
EN-2
)
)
)
)
