I/O Panel - Nexcom NEX 980 User Manual

Chapter 1: Product Introduction

1.4 I/O Panel

1 2
14 13 12
1 COM Port (COM1)
2 COM Port (COM2)
* 3 LAN RJ-45 Port
4 USB 2.0 Ports (USB67)
* 5 LAN RJ-45 Port
6 Line In (Light Blue)
7 Line out (Lime)
* There are two LED next to the LAN port. Please refer to the table below for the LAN port LED
indications.
LAN Port LED Indications
Activity/ Link LED
Status Description Status
Off No Link Off
Blinking Data Activity Orange
On Link Green
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
3 4 5
11 10
9
8 Microphone (Pink)
9 USB 3.0 Ports (USB3_01)
10 HDMI Port (HDMI1)
11 USB 2.0 Ports (USB45)
12 D-Sub Port (VGA1)
13 PS/2 Mouse/Keyboard Port
** 14 DisplayPort (DP1)
ACT/LINK
SPEED LED
LED
Description
10Mbps connection
100Mbps connection
1Gbps connection
LAN Port
6
7
8
SPEED
LED
7
