3.3.8 Super I/O Configuration
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced H/M Monitor

Super IO Configuration

COM1 Configuration
COM2 Configuration
COM3 Configuration
COM4 Configuration
COM5 Configuration
COM6 Configuration
LPT1 Port Configuration
WDT Timeout Reset [Disabled]
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
COM1 Configuration
Use this to set parameters of COM1.
COM2 Configuration
Use this to set parameters of COM2.
COM3 Configuration
Use this to set parameters of COM3.
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
Boot Security Save & Exit
Set Parameters of COM1
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
COM4 Configuration
Use this to set parameters of COM4.
COM5 Configuration
Use this to set parameters of COM5.
COM6 Configuration
Use this to set parameters of COM6.
LPT1 Port Configuration
Use this set parameters of the onboard parallel port.
WDT Timeout Reset
This allows users to enable/disable the Watch Dog Timer timeout to reset
system. The default value is [Disabled].
