Summary of Contents for GAI-Tronics Titan CB
- Page 1 Titan Commander Installation and User Guide Titan CB (1064) Commander CB (1064) Weather Resistant Telephones GAI-TRONICS Doc. No. 502-20-0099-001 Iss3. Dec 2007 (CN33056-001)
-
Page 2: Table Of Contents
Titan ..................... 8 5.3. Commander ................12 Connections and option settings............... 14 6.1. Standard connections and timer setting ........15 6.2. Additional hook contact .............. 15 Aftercare....................16 Technical Specifications ................17 CE Declaration ..................19 Titan CB, Commander CB... -
Page 3: Safety And Care Information
2.1. Changes from previous versions This manual describes an updated range of products (called ‘1064’ models) introduced in March 2005. For those familiar with GAI-Tronics’ products, the list of new or changed features is as follows: • New terminal layout (section 6.1). -
Page 4: Titan Features
Titan doors may be fitted with slamlocks opened by an 8mm square socket key. 2.3. Commander features Commander is a family of rugged, weather-resistant telephones manufactured from moulded glass-reinforced polyester. A range of handset types and keypad configurations are available. Titan CB, Commander CB... -
Page 5: Operation / Testing
Not for use on the PSTN. This is a factory-configured option. Telephones with this option have an internal label marked “Handset Integrity Alert, the call timer is disabled if the handset integrity loop is broken”. Titan CB, Commander CB... -
Page 6: Installation
PABX or telephone network to which the telephone is to be connected, and that installation is carried out by trained personnel. Contact GAI-Tronics if installation service is required. IMPORTANT Installation details differ between the TITAN and COMMANDER product ranges –please make sure you know which product you are installing... -
Page 7: Commander
Before mounting the telephone, check the cable routing and requirements. If glands are required, fit them to the case as follows: 1. Remove the RED blanking plug leaving the other (usually BLACK) in place. Titan CB, Commander CB... -
Page 8: Titan
Titan telephones supplied for flush mounting have no rear enclosure – see section 5.2.3 below. 5.2.1 Wall mounting 1. Using a suitable tool, punch out the 4 holes in the rear enclosure, taking care not to damage or dislodge the plastic bushes. Only four Titan CB, Commander CB... - Page 9 4. Ensure that all four plastic flanged bushes are in place and the rear enclosure is screwed tightly to the surface to prevent any water ingress through the punched holes. 5. Complete the installation by making the appropriate connections (section 6) and re-fitting the face plate. Titan CB, Commander CB...
- Page 10 5.2.2 Pole mounting Kit No 100-02-0208-001 This accessory is for mounting GAI-Tronics telephones on to the side of round poles of 100mm to 200mm diameter, or on to square or rectangular section uprights of 100mm to 150mm across the mounting surface.
- Page 11 Do not rely on this gasket to keep water out if mounting directly to rough surfaces such as brickwork – in these cases use additional sealant around the edges to ensure a weatherproof seal. Titan CB, Commander CB...
-
Page 12: Commander
IMPORTANT: Do not use countersunk headed fixing screws. Only use round head, socket cap head or pan head screws. Take care not to over tighten the screws, doing so may damage the case and will invalidate your warranty. Titan CB, Commander CB... - Page 13 5.3.2 Pole mounting Kit No 100-02-0208-001 This accessory is for mounting GAI-Tronics telephones on to the side of round poles of 100mm to 200mm diameter, or on to square or rectangular section uprights of 100mm to 150mm across the mounting surface.
-
Page 14: Connections And Option Settings
If glands are used, insert the cable through the gland body and tighten the gland nut sufficiently to clamp the cable, making a seal. For Titan models with rear enclosure, ensure sufficient cable is left to allow removal of the faceplate without straining the cable. Titan CB, Commander CB... -
Page 15: Standard Connections And Timer Setting
Note – this optional connection is only available if specifically ordered. Contact GAI-Tronics for details. The additional hook contact is provided on TB1. The diagram shows the state of the changeover contacts when the telephone is on hook. These contact labels are also on the PCB. Titan CB, Commander CB... -
Page 16: Aftercare
It is recommended that the switch cabling is routed via the spare gland in the case. Aftercare The purchase of your GAI-Tronics product does not end our commitment to you. In addition to our warranty obligations, GAI-Tronics are able to offer various levels of maintenance packages, installation and commissioning packages and technical support, from ad-hoc repairs to full maintenance contracts. -
Page 17: Technical Specifications
Die-cast Aluminium (Titan) Glass reinforced polyester (Commander) Handset Material Cycoloy (2850) with stainless steel or polyester curled cord. Weight 3 –5kg depending on option. Dimensions Dependant on model and variant. See 5.1 (Titan) or 5.3 (Commander) Titan CB, Commander CB... - Page 18 Business users should contact their suppliers and check the terms and conditions of the purchase contract and ensure that this product is not mixed with other commercial waste for disposal. Titan CB, Commander CB...
-
Page 19: Ce Declaration
CE Declaration Titan CB, Commander CB... - Page 20 Brunel Drive Stretton Park Burton on Trent DE13 0BZ England Tel: 01283 500500 Fax: 01283 500400 www.gai-tronics.co.uk The policy of GAI-Tronics is one of continuous improvement, therefore the Company reserves the right to change specifications without notice Titan CB, Commander CB...
