3.2 Digital Input Register (BASE + 10)

32 digital input channels can be read from this register
Address: BASE + 10
Attribute: READ Only
Data Format:
Byte 7
Base +10 DI7
Base +11 DI15
Base +12 DI23
Base +13 DI31

3.3 Digital Output Register (BASE + 14)

32 digital output channels can be write and read-back from this register
Address: BASE + 14
Attribute: READ/WRITE
Data Format:
Byte 7
Base +14 DO7
Base +15 DO15
Base +16 DO23
Base +17 DO31
The digital output status can be read back through the same location (BASE +
14)
3.4 DIO Status & Control Register (BASE + 18)
The data transfer mode of digital input is controlled and status is checked
through this register.
Address: BASE + 18
Attribute: READ/WRITE
Data Format:
Byte 7
Base +18 O_ACK
Base +19 ----
Base +20 ----
Base +21 ----
6 5
DI6 DI5
DI14 DI13
DI22 DI21
DI30 DI29
6 5
DO6 DO5
DO14 DO13
DO22 DO21
DO30 DO29
6 5 4
DIN_EN I_TRG TRGPL
I_OVER ---- ----
---- ---- ----
---- ---- ----
4 3 2
DI4 DI3 DI2
DI12 DI11 DI10
DI20 DI19 DI18
DI28 DI27 DI26
4 3
DO4 DO3
DO12 DO11
DO20 DO19
DO28 DO27
3 2
I_FIFO I_TIME0
O_TRG O_FIFO
---- ----
---- ----
1 0
DI1 DI0
DI9 DI8
DI17 DI16
DI25 DI24
2 1 0
DO2 DO1 DO0
DO10 DO9 DO8
DO18 DO17 DO16
DO26 DO25 DO24
1 0
I_REQ I_ACK
O_TIME1 O_REQ
---- O_UND
---- ----
Registers Format 17
