DMA MODE: the optional settings are Auto, SWDMAn, MWDMAn , UDMAn.

This option allows you to enable the HDD S.M.A.R.T Capability

S.M.A.R.T.:

(Self-Monitoring, Analysis and Reporting Technology). The optional settings are Auto;

Disabled; and ENABLED.

32 Bit Data Transfer: the optional settings are: Disabled and Enabled.

Floppy A

This item is for specific floppy disk drive settings. Select according to the specification of the

floppy disk you use.

System Memory

This item will show information about the memory modules(s) installed.

3-5

Advanced BIOS Feature

Advanced Settings

WARNING: Setting wrong values in below sections

May cause system to malfunction

CPU Configuration

Boot Sector Virus Protection

Quick Boot

Boot up Number Lock

ACPI APIC Support

Quiet Boot

↑↓→← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help

F5:Discard Changes

Boot Sector Virus Protection

The selection Allow you to choose the VIRUS Warning

feature for IDE Hard Disk boot sector protection. If this function is enabled and someone

attempt to write data into this area, BIOS will show a warning message on screen and alarm

beep.

Disabled (default) No warning message to appear when anything attempts to access the

Enabled

Quick Boot

Allows BIOS to skip certain tests while booting. This will decrease the needed to boot the

system.

Boot Up NumLock Status

The default value is On.

On (default)

Off

Keypad is arrow keys.

ACPI APIC Support

Include ACPI APIC table pointer to RSDT pointer list.

Quiet Boot

The optional settings are Enabled and Disable.

Disabled: Display normal POST message.

Enabled: Displays OEM logo instead of POST message.
