3-9 Miscellaneous Control

CMOS Setup Utility-Copyright(C)1985-2005 American Megatrends. Inc.
Advanced PCI/PnP Setting
Plug &Play O/S
PCI Legacy Timer
Allocate IRQ to PCI VGA
Palette Snooping
PCI IDE Bus Master
Reserved Memory Size
IRQ Resources
↑↓→← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Discard Changes
Plug &Play O/S
The optional settings are: No; Yes
No: Let the BIOS configure all the devices in the system.
Yes: Let the operating system configure Plug and Play devices, not required for boot if your
system has a Plug and Play system.
Allocate IRQ for PCI VGA
The optional settings are: No; Yes.
Yes: Assigns IRQ to PCI VGA card if card requests IRQ.
No: Does not assign IRQ to PCI VGA card even card requests an IRQ.
Palette Snooping
The optional settings are: Enabled; Disabled.
Enable: inform the PCI device that an ISA graphics devices is installed in the system so the
card will function correctly.
PCI IDE Bus Master
The optional settings are: Enabled; Disabled.
Enable: BIOS uses PCI busmastering for reading/writing IDE devices.
Reserved Memory Size
This item determines the size of memory block to reserve for legacy ISA devices.
Miscellaneous Control
No
64
Yes
Disabled
Disabled
Disabled
Press Enter
F6:Fail-Safe Defaults
34
Help Item
F7:Optimized Defaults
