UG-001 Evaluation Board User Guide
between the AD9272/AD9273 CWDx± outputs and the
AD8339 inputs.
DOUTx+, DOUTx−
If an alternative data capture method to the setup described in
Figure 2 is used, optional receiver terminations, R701 to R710, can
be installed next to the high speed backplane connector.
Rev. 0 | Page 6 of 24
