UG-001
WALL OUTLET
100V TO 240V AC
47Hz TO 63Hz
SWITCHING
POWER
SUPPLY
SWITCHING
POWER
SUPPLY
SIGNAL
SYNTHESIZER
ANALOG INPUT
SPECTRUM
ANALYZER
CW OUTPUT
AGILENT
POWER SUPPLY
GAIN CONTROL INPUT
Figure 2. Evaluation Board Connection
6V DC
2A MAX
SIGNAL
SYNTHESIZER
OPTIONAL CLOCK SOURCE
Rev. 0 | Page 4 of 24
Evaluation Board User Guide
6V DC
2A MAX
PC
RUNNING ADC
ANALYZER
OR VISUAL ANALOG
USER SOFTWARE
