Ls Connector - Analog Devices EZ-EXTENDER 82-000218-01 Manual

A
1
3.3V V_SELECT
DRPRI
2
SCLK
FS
SDA
UARTRX
UARTCTS
GPIO2
GPIO4
GPIO3
GPIO1
RESET
3
UARTRTS
UARTTX
SCL
DTPRI
4
A
B
J3 P2
2 1 1
PWR_IN1 GND1 GND1
4 3 3
PWR_IN2 GND2 GND2
6 5 5
VDDIO1 GND3 GND3
8 7 7
VDDIO2 GND4 GND4
10 9 9
3.3V1 GND5 GND5
12 11 11
3.3V2 GND6 GND6
14 13 13
DRPRI DTPRI DTPRI
16 15 15
DRSEC DTSEC DTSEC
18 17 17
RSCLK TSCLK TSCLK
20 19 19
RFS TFS TFS
22 21 21
SPISEL2 SPISEL1 SPISEL1
24 23 23
SPICLK SPISEL3 SPISEL3
26 25 25
SPISS SPIMOSI SPIMOSI
28 27 27
TIMER SPIMISO SPIMISO
30 29 29
SDA SCL SCL
32 31 31
UARTRX UARTTX UARTTX
34 33 33
UARTCTS UARTRTS UARTRTS
36 35 35
NC RESET RESET
38 37 37
GPIO2 GPIO1 GPIO1
40 39 39
GPIO4 GPIO3 GPIO3
42 41 41
RSVD2 WAKE WAKE
44 43 43
RSVD4 RSVD3 RSVD2
46 45 45
RSVD6 RSVD5 RSVD4
48 47 47
RSVD8 RSVD7 RSVD6
50 49 49
RSVD10 RSVD9 RSVD8
IDC25X2_SMT_F IDC25X2_SMTA
B
C
2
PWR_IN1
4
PWR_IN2
6
VDDIO1
8
VDDIO2
10
3.3V1
12
3.3V2
14
DRPRI
16
DRSEC
18
RSCLK
20
RFS
22
SPISEL2
24
SPICLK
26
SPISS
28
TIMER
30
SDA
32
UARTRX
34
UARTCTS
36
NC
38
GPIO2
40
GPIO4
42
RSVD1
44
RSVD3
46
RSVD5
48
RSVD7
50
RSVD9
Title
Size
Date
C
D
3.3V V_SELECT
U7
3 1
IN OUT
4 2
EN GND
MIC94040
MLF4
J1
2 1
4 3
6 5
UARTTX
8 7
10 9
UARTRX
IDC5X2_SMT_F
R6
10K
0402
ANALOG
20 Cotton Road
Nashua, NH 03063
DEVICES
PH: 1-800-ANALOGD
BLUETOOTH EZ-EXTENDER

LS CONNECTOR

Board No.
A0218-2008
C
3-27-2009_11:41 Sheet
D
1
2
UARTRTS
UARTCTS
3
4
Rev
1.1
3 of 4
