Expansion Interface II Connector (P4)

The board-to-board connector (
interfaces and GPIO signals of the mating EZ-Board. The connector is
located on the top side of the board. For availability and pricing of the
connectors, contact Samtec.
Refer to "Expansion Interface" on page 1-6
Part Description
70-position 0.1'', SMT socket
70-position 0.1'', SMT header

USB Connector (P3)

Part Description
USB Mini-B connector
USB Mini-B to USB A cable
Bluetooth EZ-Extender Manual
Bluetooth EZ-Extender Hardware Reference
) provides signals for the PPI, TWI
P4
Manufacturer
SAMTEC
Mating Connector
SAMTEC
Manufacturer
MOLEX
Mating Connector
ASSMANN
for more information.
Part Number
TSSH-135-01-L-DV-A
SSW-135-22-F-D-VS
Part Number
0675031010
AK672M/2-3
2-11
