Bluetooth EZ-Extender Default
Configuration
The EZ-Extender system contains ESD (electrostatic discharge) sensitive
devices. Electrostatic charges readily accumulate on the human body and
equipment and can discharge without detection. Permanent damage may
occur on devices subjected to high-energy discharges. Proper ESD precau-
tions are recommended to avoid performance degradation or loss of func-
tionality. Store unused EZ-Extender boards in the protective shipping
package.
When removing the Bluetooth EZ-Extender from the package, handle the
board carefully to avoid the discharge of static electricity, which can dam-
age some components (see
Figure 1-1. Default EZ-Extender Hardware Setup
Bluetooth EZ-Extender Manual
Figure 1-1).
1-3
