Jumpers
TWI Flash Address Configuration Jumper (JP1)
The TWI flash address configuration jumper (
address of the configuration flash memory. When multiple EZ-Extenders
are stacked on top of each other, it may be necessary to change the
ting to avoid any conflict with the configuration flash memory on another
EZ-Extender. The default is no jumper installed.
TWI Flash Write Protect Jumper (JP2)
The TWI flash write protect jumper (
intended for internal Analog Devices test purposes only. The default is no
jumper installed.
Soft Reset Configuration Jumpers (JP3–4)
The software reset configuration jumpers (
signal is used to perform a soft reset of the Bluegiga WT12 Bluetooth
module. The default is no jumpers installed.
Bluetooth Module Default Configuration Jumper
(JP5)
The Bluegiga WT12 Bluetooth module default configuration jumper
(
) resets the module's settings to the default values. This feature
JP5
requires software support; refer to the example programs for more infor-
mation. The default is no jumper installed.
UART Receive Data Jumper (JP6)
The UART receive data jumper (
intended for internal Analog Devices test purposes only. The default is no
jumper installed.
2-6
) controls the base
JP1
) is not available; the jumper is
JP2
) determine which GPIO
JP3—4
) is not available; the jumper is
JP6
Bluetooth EZ-Extender Manual
set-
JP1
