Analog Devices icron EL5363 Quick Start Manual

Local Extender
Link
1
Using the included high quality HDMI and USB cables,
connect the Local Extender LEX to a computer.
Computer
3 Directly connect the LEX to the REX with a solid core CAT e
CAT a
back of this page .
Link
4 Power the LEX with the included V AC adapter.
Link HDMI In
For additional details about configuring and operating your EL5363,
refer to the complete online user guide at: www.icron.com/5363
For technical support visit: www.icron.com/support
EL5363
HDMI and USB 2.0 100m CAT 5e/6/7 KVM Extender System
Front
Quick Start Guide
Back
HDMI In
V DC
LEX (rear view)
Link HDMI In
V DC
STP is recommended for best performance refer to detailed cable information on the
HDMI In
V DC
CAT 5e/6/7 Cable
Max. distance is 100m (330 ft) between LEX and REX
V DC
Remote Extender
HDMI + USB 2.0 Extender
Front
Back
Link
HDMI Out V DC
2
Connect the Remote Extender REX to a monitor or TV
with a high quality HDMI cable not included . Connect
your USB devices e.g. keyboard and mouse to the REX.
REX (rear view)
Link
HDMI Out
cable not included . Solid core
Link HDMI Out
Power the REX with the included V AC adapter.
5
Link
HDMI Out
V DC
V DC
