STAMP UART Connector (J1)

The STAMP UART connector (
be plugged onto an EZ-KIT Lite development board supporting a
STAMP interface. The
board. For availability and pricing of the connectors, contact Samtec.
Refer to "Expansion Interface" on page 1-6
Part Description
10-position 0.1", SMT socket
10-position 0.1'', SMT header

Expansion Interface II Connector (J3)

The board-to-board connector (
UART, SPORT interfaces and general-purpose I/O (GPIO) signals of the
mating EZ-Board. The connector is located on the bottom side of the
board. For availability and pricing of the connectors, contact Samtec.
Refer to "Expansion Interface" on page 1-6
Part Description
50-position 0.1'', SMT socket
50-position 0.1'', SMT header
Bluetooth EZ-Extender Manual
Bluetooth EZ-Extender Hardware Reference
) allows the Bluetooth EZ-Extender to
J1
connector is located on the bottom side of the
J1
Manufacturer
SAMTEC
Mating Connector
SAMTEC TSSH
) provides signals for the SPI, TWI,
J3
Manufacturer
SAMTEC
Mating Connector
SAMTEC
or more information.
Part Number
SSW-105-22-F-D-VS
TSSH-105-01-L-DV-A
for more information.
Part Number
SSW-125-22-F-D-VS
TSSH-125-01-L-DV-A
2-9
