Expansion Interface
Expansion interface connectors on top of the Bluetooth EZ-Extender
allow other EZ-Extenders to be mounted on top of the Bluetooth
EZ-Extender. The UART interface is not brought up to the expansion
interface because the interface is used by the WT12 Bluetooth module. All
other signals are passed up to the expansion interface from the mating
EZ-KIT Lite or EZ-Board through the Bluetooth EZ-Extender.
Example Programs
For more information about using the Bluetooth EZ-Extender and run-
ning µClinux on a Blackfin processor, go to
http://docs.black-
fin.uclinux.org/doku.php?id=hw:cards:bluetooth_ez-extender
1-6
Bluetooth EZ-Extender Manual
.
