Billion BiPAC 7800 User Manual

(802.11n) dual wan adsl2+ firewall router
Hide thumbs Also See for BiPAC 7800:
Table of Contents

Advertisement

Quick Links

Download this manual
BiPAC 7800(N)
(802.11n) Dual WAN
ADSL2+ Firewall Router

User Manual

Version released: 1.05
Last revised on August 31 2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BiPAC 7800 and is the answer not in the manual?

Questions and answers

Related Manuals for Billion BiPAC 7800

Summary of Contents for Billion BiPAC 7800

  • Page 1: User Manual

    BiPAC 7800(N) (802.11n) Dual WAN ADSL2+ Firewall Router User Manual Version released: 1.05 Last revised on August 31 2010...

  • Page 2: Table Of Contents

    Table of Contents Chapter 1: Introduction ..................1 Introduction to your Router ................1 Features ....................2 Hardware Specifications ................4 Chapter 2: Installing the Router ................5 Package Contents..................5 Important note for using this router ............6 Device Description ..................7 The Front LEDs ...................7 The Rear Ports ...................8 Cabling .......................9 Chapter 3: Basic Installation ................10 Connecting Your Router ................
  • Page 3 WAN – Main Port (EWAN) ..............46 PPPoE (EWAN) ................46 Obtain IP Address Automatically (EWAN) ........47 Fixed IP Address (EWAN) .............48 Pure Bridge (EWAN) ..............49 WLAN (only for BiPAC 7800N) ............50 Advanced Configuration Mode ..............55 Status ....................55 ADSL .....................57 WAN Statistics ................58 ARP ....................59 DHCP ....................60 System Log ...................61...
  • Page 4 User Management ..............105 Mail Alert ................107 Syslog ...................108 Diagnostics Tools ..............109 Firewall ..................110 Packet Filter ................110 Ethernet MAC Filter .............. 111 Wireles MAC Filter ..............112 Intrusion Detection ..............113 Block WAN Ping ..............113 URL Filter ................114 QoS - Quality of Service .............

  • Page 5: Chapter 1: Introduction

    Chapter 1: Introduction Introduction to your Router Thank you for purchasing BiPAC 7800(N) Router. Your new router is an all-in-one unit that combines an ADSL modem, ADSL2/2+ router and Ethernet network switch to provide everything you need to get the machines on your network connected to the Internet over an ADSL broadband connection.

  • Page 6: Features

    (ITU G.992.5)). EWAN BiPAC 7800(N) EWAN port provides user an alternative means to connect to Cable Modems, VDSL, fiber optic lines and PON besides using ADSL for internet connection. If one uses ADSL to connect to the internet, EWAN can act as the 5th Ethernet port of the LAN. This alternative provides users with more flexibility &...
  • Page 7 Dynamic Domain Name System (DDNS) The Dynamic DNS service allows you to alias a dynamic IP address to a static hostname. This dynamic IP address is the WAN IP address. For example, to use the service, you must first apply for an account from a DDNS service like http://www.dyndns.org/.

  • Page 8: Hardware Specifications

    Hardware Specifications Physical Interface • WLAN: 3 x 2 dbi detachable antennae (BiPAC 7800NA only) • DSL: ADSL port • EWAN: RJ-45 Ethernet port for connecting to ADSL / Cable / FTTH / VDSL device • Ethernet: 4-port 10/100/1000M auto-crossover (MDI / MDI-X) Switch •...

  • Page 9: Chapter 2: Installing The Router

    Chapter 2: Installing the Router Package Contents BiPAC 7800(N) (802.11n) Dual WAN ADSL2+ Firewall Router CD containing the online manual RJ-11 ADSL/Telephone cable Ethernet (RJ-45) cable Three 2dBi detachable antennas (Wireless model only) Power adapter Quick Start Guide Splitter / Microfilter (Optional)

  • Page 10: Important Note For Using This Router

    Important note for using this router...

  • Page 11: Device Description

    Device Description The Front LEDs Meaning Lit orange when WAN port fails to get IP address. Lit green when WAN port gets IP address. Internet Lit off when device in bridged mode or ADSL connection not present. Lit Green when the device is successfully connected to an ADSL DSLAM.

  • Page 12: The Rear Ports

    The Rear Ports Port Meaning Power Switch Power ON/OFF switch. Power Connect it with the supplied power adapter. Press more than 5 seconds to restore the device to its default RESET mode. Push WPS button to trigger Wi-Fi Protected Setup function. (only for BiPAC 7800N) Connect to a PC or an office/home network of 10Mbps, Giga Ethernet...

  • Page 13: Cabling

    The detail instruction in Reset Button 1. Recovery procedures for non-working routers (e.g. after a failed firmware upgrade flash): Hold the Reset Button on the back of the modem in. Keep this button held in and turn on the modem. Once power LED lits orange, release the Reset Button. The modem’s emergency-reflash web interface will then be accessible via http://192.168.1.254 where you can upload a firmware image to restore the modem to a functional state.

  • Page 14: Chapter 3: Basic Installation

    Chapter 3: Basic Installation The router can be configured through your web browser. A web browser is included as a standard application in the following operating systems: Linux, Mac OS, Windows 98/NT/2000/XP/Me/Vista, etc. The product provides an easy and user-friendly interface for configuration. Please check your PC network components.

  • Page 15: Connecting Your Router

    Connecting Your Router Users will not be able to connect to the internet through EWAN if DSL is already connected to the internet. Only one connection type (EWAN or DSL) is allowed to connect to the internet at one time. ADSL Router Mode Broadband Router Mode...

  • Page 16: Network Configuration

    Network Configuration Configuring PC in Windows 7 1. Go to Start. Click on Control Panel. 2. Then click Network Internet. 3. When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel. 4.
  • Page 17 5. Select Internet Protocol Version 4 (TCP/IPv4) then click Properties. 6. In the TCP/IPv4 properties window, select the Obtain an IP address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. 7. Click OK again in the Local Area Connection Properties window to apply the new configuration.

  • Page 18: Configuring Pc In Windows Vista

    Configuring PC in Windows Vista 1. Go to Start. Click on Network. 2. Then click on Network and Sharing Center at the top bar. 3. When the Network and Sharing Center window pops up, select and click on Manage network connections on the left window column.
  • Page 19 5. Select Internet Protocol Version 4 (TCP/IPv4) then click Properties. 6. In the TCP/IPv4 properties window, select the Obtain an IP address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. 7. Click OK again in the Local Area Connection Properties window to apply the new configuration.

  • Page 20: Configuring Pc In Windows Xp

    Configuring PC in Windows XP 1. Go to Start > Control Panel (in Classic View). In the Control Panel, double-click on Network Connections 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window, click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties.

  • Page 21: Configuring Pc In Windows 2000

    Configuring PC in Windows 2000 1. Go to Start > Settings > Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties.

  • Page 22: Configuring Pc In Windows 95/98/Me

    Configuring PC in Windows 95/98/Me 1. Go to Start > Settings > Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. 2. Select TCP/IP > NE2000 Compatible, or the name of your Network Interface Card (NIC) in your PC. 3.
  • Page 23 Configuring PC in Windows NT4.0 1. Go to Start > Settings > Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Prop- erties. 3. Select the Obtain an IP address from a DHCP server radio button and click...

  • Page 24: Factory Default Settings

    Factory Default Settings Before configuring your router, you need to know the following default settings. Web Interface (Username and Password) Three user levels are provided by this router, thus Administrator, Basic and Advanced respectively. Administrator Username: admin Password: admin Basic Username: user Password: user Advanced (for remote login)

  • Page 25: Information From Your Isp

    LAN and WAN Port Addresses The parameters of LAN and WAN ports are pre-set in the factory. The default values are shown in the tale. LAN Port WAN Port IP address 192.168.1.254 Subnet Mask 255.255.255.0 The PPPoE function is enabled to automatically get DHCP server function Enabled the WAN port configuration...

  • Page 26: Chapter 4: Configuration

    GUI for any detail configuration. This configuration method is usually auto initiated if user is to connect to the internet via Billion's router for the first time.
  • Page 27 3. Please enter all the information in the blanks provided and then click continue. 4. The device will reboot and then load the new configuration. 5. If all information provided is valid and the device successfully connects to WAN, a dialog box will appear to signify the completion of the WAN port setup.
  • Page 28 7. Select Enable and enter the necessary information in the blanks provided for the Wireless LAN setting (wireless setting is only available for BiPAC 7800N) if you would like to use this feature and then click Continue. 8. The system will save your new configuration and complete the setup. You can test the connection by clicking on the URL link provided.

  • Page 29: Configuration Via Web Interface

    Configuration via Web Interface Open your web browser, enter the IP address of your router, which by default is 192.168.1.254, and click or press ‘Enter’ key on the keyboard, a login prompt window will appear. The default username and password are “admin” and “admin” respectively. Congratulations! You are now successfully logged in to the Firewall Router! If the authentication succeeds, the homepage Status will appear on the screen.

  • Page 30: Quick Start

    Quick Start ADSL Mode Step 1: Select WAN port connect mode from the connect mode drop down menu. There are two types of connect mode to choose from: ADSL or EWAN. Here select ADSL and click Continue. If you only want to configure Wireless, press Jump to Wireless setting. Step 2: When ADSL line is not ready, the screen1 below will appear to remind you.
  • Page 31 Step3: Wait while the DSL is scanning, when the scanning is OK, the scanning result will appear, see screen 3, and then it will quickly goes to step 4. Or you can Abort to manually setting to step Screen 3 Step 4: There are 5 types of connection protocols available under ADSL connect mode .Each type of connection mode is described in the following sections of ADSL Connect mode.
  • Page 32 Step 5: The device will reboot and then load the new configuration. Step 6: WAN port configuration is success. And if you want contiune configuring wireless, press Next to Wireless button to go on. Step 7: Enter the ESSID, select the Channel ID and the Security Mode, click Continue to go on. For detail, please turn to WLAN in this manual for help.
  • Page 33 Step 8: Quick Star is finished. You can go to the Status and view the basic information.

  • Page 34: Pure Bridge

    ADSL Connect Mode For ADSL connect mode there are 5 types of connection protocols: PPPoE, PPPoA, IPoA, MPoA Pure Bridge. PPPoE VPI/VCI: Enter the information provided by your ISP. Username: Enter the username provided by your ISP. You can input up to 256 alphanumeric characters (case sensitive).
  • Page 35 PPPoA VPI/VCI: Enter the information provided by your ISP. Username: Enter the username provided by your ISP. You can input up to 256 alphanumeric characters (case sensitive). Password: Enter the password provided by your ISP. You can input up to 32 alphanumeric characters (case sensitive).
  • Page 36 IPoA Connection VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encapsulation method: Select the encapsulation format. Select the one provided by your ISP. IP Address: IPOA WAN IP address can only set fixed IP address. Netmask: User can change it to others such as 255.255.255.128. Type the netmask assigned to you by your ISP (if given).
  • Page 37 MPoA Connection VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encapsulation method: Select the encapsulation format. Select the one provided by your ISP. IP Address: Your WAN IP address. If the IP is set to 0.0.0.0 (auto IP detect), both netmask and gateway may be left blank.
  • Page 38 Pure Bridge Connection VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encap. method: Select the encapsulation format. Select the one provided by your ISP. Click Apply to confirm the settings.

  • Page 39: Ewan Mode

    EWAN Mode Step 1: Select WAN port connect mode from the connect mode drop down menu. There are two types of connect mode to choose from: ADSL or EWAN. Here select EWAN and click Continue. If you only want to configure Wireless, press Jump to Wireless setting. Step 2: there are four availabe protocols.
  • Page 40 Step 4: WAN port configuration is sucess, now Next to Wireless. Step 5: Enter the ESSID, select the Channel ID and the Security Mode. For security information, please turn to WLAN section in this manual for help. Step 6: Quick Start is finished.
  • Page 41 EWAN Connect Mode PPPoE connection Username: Enter the username provided by your ISP. You can input up to 256 alphanumeric characters (case sensitive). Password: Enter the password provided by your ISP. You can input up to 32 alphanumeric characters (case sensitive). Service Name: This item is for identification purposes.
  • Page 42 Obtain an IP Address Automatically Select this protocol enables the device to automatically retrieve IP address. VLAN Mux: check whether to enable VLAN Mux function. 802.1Q VLAN ID: It is a parameter to specify the VLAN which the frame belongs. Enter the VLAN ID identification, tagged: 2-4095.
  • Page 43 Primary DNS / Secondary DNS: Enter the IP addresses of the DNS servers. The DNS servers are passed to the DHCP clients along with the IP address and the netmask. VLAN Mux: check whether to enable VLAN Mux function. 802.1Q VLAN ID: It is a parameter to specify the VLAN which the frame belongs. Enter the VLAN ID identification, tagged: 2-4095.

  • Page 44: Basic Configuration Mode

    Basic Configuration Mode Status Device Information Model Name: Provide a name for the router for identification purposes. System Up-Time: Record system up-time. Hardware Version: Device version. Software Version: Firmware version. Port Status Port Status: User can look up to see if they are connected to Ethernet, EWAN, ADSL and Wireless.

  • Page 45: Wan - Main Port (Adsl)

    WAN – Main Port (ADSL) A WAN (Wide Area Network) is an outside connection to another network or the Internet. PPPoE Connection (ADSL) PPPoE (PPP over Ethernet) provides access control in a manner similar to dial-up services using PPP. VPI/VCI: Enter the information provided by your ISP. Username: Enter the username provided by your ISP.

  • Page 46: Pppoa Connection (Adsl)

    PPPoA Connection (ADSL) PPPoA stands for Point to Point Protocol over ATM Adaptation Layer 5 (AAL5). It provides access control and billing functionality in a manner similar to dial-up services using PPP. VPI/VCI: Enter the information provided by your ISP. Username: Enter the username provided by your ISP.

  • Page 47: Mpoa Connection (Adsl)

    MPoA Connection (ADSL) VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encap. method: Select the encapsulation format. Select the one provided by your ISP. IP Address: Your WAN IP address. If the IP is set to 0.0.0.0 (auto IP detect), both netmask and gateway may be left blank.

  • Page 48: Ipoa Connections (Adsl)

    IPoA Connections (ADSL) VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encap. method: Select the encapsulation format. Select the one provided by your ISP. IP Address: Enter your fixed IP address. Netmask: User can change it to others such as 255.255.255.128. Type the netmask assigned to you by your ISP (if given).

  • Page 49: Pure Bridge Connections (Adsl)

    Pure Bridge Connections (ADSL) VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encap. method: Select the encapsulation format. Select the one provided by your ISP. Click Apply to confirm the settings.

  • Page 50: Wan - Main Port (Ewan)

    WAN – Main Port (EWAN) Besides using ADSL to get connected to the Internet, EWAN port of BiPAC 7800(N) can be used as an alternative to connect to Cable Modems, VDSL and fiber optic lines. This alternative not only provides faster connection to the Internet, it also provides users with more flexibility to get online.

  • Page 51: Obtain Ip Address Automatically (Ewan)

    VLAN Mux: check whether to enable VLAN Mux function. 802.1Q VLAN ID: It is a parameter to specify the VLAN which the frame belongs. Enter the VLAN ID identification, tagged: 2-4095. Click Apply to confirm the settings. Obtain IP Address Automatically (EWAN) Select this protocol enables the device to automatically retrieve IP address.

  • Page 52: Fixed Ip Address (Ewan)

    Fixed IP Address (EWAN) IP Address: Enter your fixed IP address. Netmask: User can change it to others such as 255.255.255.128. Type the netmask assigned to you by your ISP (if given). Gateway: Enter the IP address of the default gateway. Obtain DNS automatically: Click to activate DNS and to enable the system to automatically detect DNS.

  • Page 53: Pure Bridge (Ewan)

    Pure Bridge (EWAN) VLAN Mux: check whether to enable VLAN Mux function. 802.1Q VLAN ID: It is a parameter to specify the VLAN which the frame belongs. Enter the VLAN ID identification, tagged: 2-4095. Click Apply to confirm the settings.

  • Page 54: Wlan (Only For Bipac 7800N)

    WLAN (only for BiPAC 7800N) WPA / WPA2 Wireless Parameters WLAN Service: Default setting is set to Enable. If you do not have any wireless, select Disable. ESSID: The ESSID is the unique name of a wireless access point (AP) used to distinguish one from another.
  • Page 55 If you want to enable the RADIUS function, check Enable and then do the following settings. RADIUS Server IP Address: The IP address of RADIUS authentication server. RADIUS Server Port: The port number of RADIUS authentication server here. Default value is 1812.
  • Page 56 WPA/WPA2 Pre-Shared Key Wireless Parameters WLAN Service: Default setting is set to Enable. If you do not have any wireless, select Disable. ESSID: The ESSID is the unique name of a wireless access point (AP) used to distinguish one from another.
  • Page 57 Parameters WLAN Service: Default setting is set to Enable. If you do not have any wireless, select Disable. ESSID: The ESSID is the unique name of a wireless access point (AP) used to distinguish one from another. For security propose, change to a unique ID name which is already built into the router wireless interface.
  • Page 58 Security Parameters Security Mode: You can disable or enable with WPA or WEP to protect wireless network. The default mode of wireless security is Disable. RADIUS / 802.1x: You can disable or enable the RADIUS service. WEP Authentication: To prevent an unauthorized wireless station from accessing the data transmitted over the network, the router offers a secure data encryption, known as WEP.

  • Page 59: Advanced Configuration Mode

    Advanced Configuration Mode Status Device Information Model Name: Displays the model name. Host Name: Provide a name for the router for identification purposes. Host Name lets you change the router name. System Up-Time: Records system up-time. Current time: Set the current time. See the Time Zone section for more information. Hardware Version: Device version.
  • Page 60 IP Address: WAN port IP address. Netmask: WAN port IP subnet mask.Gateway: The IP address of the default gateway. Primary DNS: The IP address of the primary DNS server.

  • Page 61: Adsl

    ADSL DSP Firmware Version: DSP code version. DMT Status: Current DMT Status. Operational Mode: Display the ADSL state when the connect mode is set to AUTO. Upstream: Upstream rate. Downstream: Downstream rate. SNR Margin (Upstream): This shows the SNR margin for upstream rate. SNR Margin (Downstream): This shows the SNR margin for downstream rate.

  • Page 62: Wan Statistics

    WAN Statistics Protocol: Service name that is used for connection. VPI/VCI: It is provided by ISP. Received: Include received Bytes, Pkts, Errs and Drops. Transmitted: Include transmitted Bytes, Pkts, Errs and Drops.

  • Page 63: Arp

    This table stores mapping information that the device uses to find the Layer 2 Media Access Control (MAC) address that corresponds to the Layer 3 IP address of the device via the Address Resolution Protocol (ARP) feature. IP Address: Shows the IP Address of the device that the MAC address maps to. MAC Address: Shows the MAC address that is corresponded to the IP address of the device it is mapped to.

  • Page 64: Dhcp

    DHCP This Table lists the DHCP lease information for all IP addresses assigned by the DHCP server in the device. IP Address: This is the IP address that is assigned to the host with this MAC address. MAC Address: The MAC Address of internal dhcp client host. Client Host Name: The Host Name of internal dhcp client.

  • Page 65: System Log

    System Log Display system logs accumulated up to the present time. You can trace its historical information with this function. Refresh: Click to update the system log. Clear: Click to clear the current log from the screen.

  • Page 66: Firewall Log

    Firewall Log Firewall Log displays a log that contains information of any unexpected actions that occur to your firewall settings. UPnP Portmap This section lists all the established port-mapping using UPnP (Universal Plug and Play). See the Advanced section of this manual for more details on UPnP and the router UPnP configuration options.

  • Page 67: Configuration

    Configuration When you click this item, the column will expand to display the sub-items that will allow you to further configure your GPON router. LAN, WAN, System, Firewall, QoS, Virtual Server, Wake on LAN, Certificate, Time Schedule and Advanced. The function of each configuration sub-item is described in the following sections.

  • Page 68: Lan

    A Local Area Network (LAN) is a shared communication system network where many computers are connected. This type of network is area defined and is usually limited to a confined region within a building or just within the same storey of a building. There are 5 items within the LAN section: Ethernet, Alias, Wireless (7800N...

  • Page 69: Wireless (Only For Bipac 7800N)

    Wireless (only for BiPAC 7800N) Parameters WLAN Service: Default setting is set to Enable. If you do not have any wireless, select Disable. Time Schedule: Time Schedule: A self defined time period. You may specify a time schedule for your prioritization policy.
  • Page 70 Here we provide two groups of Time Schedule setting. You can flexibly set the time you want the wireless connection works. If you select Always On in group1, then the group2 is disabled. While if you select any other item from the group1 drop-down menu, the group2 will be activated. Select the timeslot you want, then the wireless will work according to the time of the two time schedule settings.
  • Page 71 AP Firmware Version: The Access Point firmware version. WPS Service: Select Enable if you would like to activate WPS service. WPS State: This column allows you to set the status of the device wireless setting whether it has been configured or unconfigured. For WPS configuration please refer to the section on Wi-Fi Network Setup for detail.

  • Page 72: Wireless Security (Only For Bipac 7800N)

    Wireless Security (only for BiPAC 7800N) You can disable or enable wireless security with WPA or WEP for protecting wireless network. The default mode of wireless security is disabled. WPA / WPA2 WPA/WPA2 Pre-Shared Key RADIUS/802.1x:Whether to enable RADIUS function or not (For WPA/WPA2/WEP encryption). Security Mode: You can choose the type of security mode you want to apply from the drop down menu.
  • Page 73 RADIUS / 802.1x: Whether to enable RADIUS / 802.1x. WEP Authentication: To prevent unauthorized wireless stations from accessing data transmitted over the network, the router offers secure data encryption, known as WEP. There are 3 options to select from: Open System, Shared key or both. Default Used WEP Key: Select the encryption key ID;...

  • Page 74: Wps (Only For Bipac 7800N)

    WPS (only for BiPAC 7800N) WPS (WiFi Protected Setup) feature is a standard protocol created by Wi-Fi Alliance. This feature greatly simplifies the steps needed to create a Wi-Fi networks for a residential or an office setting. WPS supports 2 types of configuration methods which are commonly known among consumers: PIN Method &...
  • Page 75 Wi-Fi Network Setup (only for BiPAC 7800N) PIN Method: Configure AP as Registrar 1. Jot down the client’s Pin (eg. 16837546). 2. Enter the Enrollee’s PIN number and then press Start. 3. Launch the wireless client’s WPS utility (eg. Ralink Utility). Set the Config Mode as Enrollee, press the WPS button on the top bar, select the AP (eg.
  • Page 76 4. The client’s SSID and security setting will now be configured to match the SSID and security setting of the registrar.
  • Page 77 PIN Method: Configure AP as Enrollee 1. In the WPS configuration page, change the Role to Enrollee. Then press Start. 2. Jot down the WPS PIN (eg. 25879810). 3. Launch the wireless client’s WPS utility (eg. Ralink Utility). Set the Config Mode as Registrar. Enter the PIN number in the PIN Code column then choose the correct AP (eg.
  • Page 78 4. The router’s (AP’s) SSID and security setting will now be configured to match the SSID and security setting of the registrar.
  • Page 79 5. Now to make sure that the setup is correctly done, cross check to see if the SSID and the secu- rity setting of the registrar setting match with the parameters found on both Wireless Configura- tion and Wireless Security Configuration page.
  • Page 81 PBC Method: 1. Press the PBC button of the AP. 2. Launch the wireless client’s WPS Utility (eg. Ralink Utility). Set the Config Mode as Enrollee. Then press the WPS button and choose the correct AP (eg. wlan-ap) from the WPS AP List section before pressing the PBC button to run the scan.
  • Page 82 3. When the PBC button is pushed, a wireless communication will be established between your router and the PC. The client’s SSID and security setting will now be configured to match the SSID and security setting of the router.
  • Page 83 Wi-Fi Network Setup with Windows Vista WCN: 1. Jot down the AP PIN from the Web (eg. 25879810). 2. Access the Wireless configuration of the web GUI. Enable WPS service, set the WPS State to Unconfigured and then click Apply. 3.
  • Page 84 4. Enter the AP SSID then click Next. 5. Enter the passphrase then click Next.
  • Page 85 6. When you have come to this step, you will have comleted the Wi-Fi network setup using the built-in WCN feature in Windows Vista.

  • Page 86: Dhcp Server

    DHCP Server DHCP allows networked devices to obtain information on the parameter of IP, Netmask, Gateway as well as DNS through the Ethernet Address of the device. To configure the router’s DHCP Server, select DHCP Server from the DHCP Server Mode drop- down menu.

  • Page 87: Wan - Wide Area Network

    WAN - Wide Area Network A WAN (Wide Area Network) is a computer network that covers a broad geographical area (eg. Internet) that is used to connect LAN and other types of network systems. There are two items within the WAN section: WAN Interface, WAN Profile ADSL Mode.
  • Page 88 WAN Interface (Dual WAN) Main Port: Select the main port from the drop-down menu. WAN1: Choose ADSL or EWAN for WAN1. Click the link to go to WAN Profile page to configure its parameters. WAN2: Choose one from the remainninng modes. Click the link to go to WAN Profile page to configure its parameters.
  • Page 89 each probe cycle and decided by Probe Cycle duration multiplied by Connection Decision value(e.g. 60 seconds are multiplied by 12 seconds and 5 consecutive fails). Detect Rule (either one): 1. Physical Port Error 2. Ping Fail • No Ping: It will not send any ping packet to determine the connection. It means to disable the ping fail detection.

  • Page 90: Wan Profile

    WAN Profile WAN Profile (ADSL) PPPoE Connection (ADSL) PPPoE (PPP over Ethernet) provides access control in a manner similar to dial-up services using PPP. Description: A given name for the connection. VPI/VCI: Enter the information provided by your ISP. Encap. method: Select the encapsulation format. Select the one provided by your ISP. Username: Enter the username provided by your ISP.
  • Page 91 Primary DNS: Enter the primary DNS. Secondary DNS: Enter the secondary DNS. Connection: Click on Always on to establish a PPPoE session during start up and to automatically re-establish the PPPoE session when disconnected by the ISP. You may uncheck the item to disable this function.
  • Page 92 PPPoA Connection (ADSL) PPPoA stands for Point to Point Protocol over ATM Adaptation Layer 5 (AAL5). It provides access control and billing functions in a manner similar to dial-up services using PPP. Description: A given name for the connection. VPI/VCI: Enter the information provided by your ISP. Encap.
  • Page 93 Idle Timeout: Auto-disconnect the broadband firewall gateway when there is no activity on the line for a predetermined period of time. MTU: Control the maximum Ethernet packet size your PC will send.
  • Page 94 MPoA Connection (ADSL) Description: A given name for the connection. VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encap. method: Select the encapsulation format. Select the one provided by your ISP. NAT: The NAT (Network Address Translation) feature allows multiple users to access the Internet through a single ISP account by sharing a single IP address.
  • Page 95 IPoA Connections (ADSL) Description: A given name for the connection. VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encap. method: Select the encapsulation format. Select the one provided by your ISP. NAT: The NAT (Network Address Translation) feature allows multiple users to access the Internet through a single ISP account by sharing a single IP address.
  • Page 96 Pure Bridge Connections (ADSL) Description: A given name for the connection. VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encap. method: Select the encapsulation format. Select the one provided by your ISP.
  • Page 97 WAN Profile – Main Port (EWAN) Besides using ADSL to connect to the Internet, BiPAC 7800(N) EWAN port is also an alternative to connect to Cable Modems, VDSL and fiber optic lines. This alternative provides users with faster connection & flexibility to connect to the Internet.
  • Page 98 Idle Timeout: Auto-disconnect the broadband firewall gateway when there is no activity on the line for a predetermined period of time. MTU: Control the maximum Ethernet packet size your PC will send. MAC Spoofing: This option is required by some service Providers. You must fill the MAC address specified by your service provider when this information is required.
  • Page 99 Obtain an IP Address Automatically (EWAN) NAT: The NAT (Network Address Translation) feature allows multiple users to access the Internet through a single IP account by sharing the single IP address. If users on your LAN have their own public IP addresses to access the Internet, NAT function can be disabled. MAC Spoofing: This option is required by some service Providers.
  • Page 100 Fixed IP Address (EWAN) NAT: The NAT (Network Address Translation) feature allows multiple users to access the Internet through a single IP account by sharing the single IP address. If users on your LAN have their own public IP addresses to access the Internet, NAT function can be disabled. MAC Spoofing: This option is required by some service Providers.
  • Page 101 Pure Bridge (EWAN) VLAN Mux: check whether to enable VLAN Mux function. 802.1Q VLAN ID: It is a parameter to specify the VLAN which the frame belongs. Enter the VLAN ID identification, tagged: 2-4095. Click Apply to confirm the settings.

  • Page 102: Vlan Mux Setting

    VLAN MUX Setting A Virtual LAN, commonly known as a VLAN, is a group of hosts with the common set of requirements that communicate as if they were attached to the same broadcast domain, regardless of the physical location. A VLAN has the same attributes as a physical LAN, but it allows for end stations to be grouped together even if they are not located on the same network switch.
  • Page 103 Step 2: Select Pure Bridge mode, Enable VLAN MUX, set 802.1Q VLAN ID 200, Click Add. Step 3: Now go to Configuration > Advanced > VLAN, start to set VLAN. Select Port Based VLAN Type, set VLAN Group Name VLAN 200, select port 1 to join in this VLAN group and link this VLAN group to eth0.200 as follows.

  • Page 104: Adsl Mode

    ADSL Mode ADSL Mode: There are 2 modes “Annex L” and ”Annex M” that user can select for this connection. Modulator: There are 5 modes “ADSL2”, ”ADSL2+”, “G.Lite:”, “T1.413” and “G.DMT” that user can select for this connection. Click Apply to confirm the change.

  • Page 105: System

    System There are five items within the System section: Time Zone, Firmware Upgrade, Backup/Restore, Restart, User Management, Mail Alert, Syslog and Diagnostics Tools. Time Zone The router does not have a real time clock on board; instead, it uses the Simple Network Time Protocol (SNTP) to get the most current time from an SNTP server outside your network.

  • Page 106: Firmware Upgrade

    Firmware Upgrade Your router’s firmware is the software that enables it to operate and provides all its functionality. Think of your router as a dedicated computer, and the firmware as the software that runs in your router. Thus, by upgrading the newly improved version of the firmware allows you the advantage to use newly integrated features.

  • Page 107: Backup / Restore

    Backup / Restore These functions allow you to save a backup of the current configuration of your router to a defined location on your PC, or to restore a previously saved configuration. This is useful if you wish to experiment with different settings, knowing that you have a backup in hand in case any mistakes occur.

  • Page 108: Restart

    Restart There are 2 options for you to choose from before restarting the your 7800(N) device. You can either choose to restart your device to restore it to the Factory Default Settings or to restart the device with your current settings applied. Restarting your device to Factory Default Setting will be useful especially after you have accidentally changed your settings that may result in undesirable outcome.

  • Page 109: User Management

    User Management In order to prevent unauthorized access to your router configuration interface, it requires all users to login with a username and password. Three user levels are provided here. Each user level there’s a default provided password. You must access the router with the appropriate username and password. Here the corresponding passwords are allowed to change.To change your password, simply enter the old password in the Old Password blank.
  • Page 110 Note: by default the other two users of level Advanced and level Basic, thus user and support, are not available, if you want to use the two accounts, check Valid and set their password. And here username is allowed to change, as follows, usename User in User field can be changed.

  • Page 111: Mail Alert

    Mail Alert Mail alert is designed to keep system administrator or other relevant personnel alerted of any unexpected events that might have occured to the network computers or server for monitoring efficiency. With this alert system, appropriate solutions may be tackled to fix problems that may have arisen so that the server can be properly maintained.

  • Page 112: Syslog

    Recipient’s Email (WAN IP Change Alert): Enter the email address that will receive the alert message once an WAN IP change has been detected. . Alert Mail Time (Intrusion Detection): The interval for sending alert mail. Recipient’s Email (Intrusion Detection): Enter the email address that will receive the alert message once intrusion has been detected.

  • Page 113: Diagnostics Tools

    Diagnostics Tools Destination IP / Domain Name: Input the IP or domian name to be tested. Trace IP: Input IP to be traced.

  • Page 114: Firewall

    Firewall Listed are the items under the Firewall section: Packet Filter,Ethernet MAC Filter, Wireless MAC Filter, Intrusion Detection, Block WAN PING URL Filter. Packet Filter Packet filtering enables you to configure your router to block specific internal / external users (IP address) from Internet access, or disable specific service requests (Port number) to / from the Internet.

  • Page 115: Ethernet Mac Filter

    Direction: Determine whether the rule is for outgoing packets or for incoming packets. Time Schedule: A self defined time period. You may specify a time schedule for your prioritization policy. For setup and detail, refer to Time Schedule section. Log: Select Enable for this option if you will like to capture the logs for this Packet filter policy. Add: Click this button to add a new packet filter rule and the added rule will appear at the bottom table.

  • Page 116: Wireles Mac Filter

    Action: Select an action for MAC Filter. This feature is disabled by default. Check Allow or Block to activate the filter. Parameters MAC Address: Enter the ethernet MAC addresses you wish to have the filter rule applies. Time Schedule: A self defined time period. You may specify a time schedule for your prioritization policy.

  • Page 117: Intrusion Detection

    Intrusion Detection The router Intrusion Detection System (IDS) is used to detect hacker’s attack and intrusion attempts from the Internet. If the IDS function of the firewall is enabled, inbound packets are filtered and blocked depending on whether they are detected as possible hacker attacks, intrusion attempts or other connections that the router determines to be suspicious.

  • Page 118: Url Filter

    URL Filter URL (Uniform Resource Locator) (e.g. an address in the form of http://www.abcde.com or http:// www.example.com) filter rule allows you to prevent users on your network from accessing specific websites defined by their URL. There are no predefined URL filter rules, therefore you can add filter rules to meet your requirements.
  • Page 119 Keywords filtering Click the checkbox to enable this feature. To edit the list of filtered keywords, click Details. Enter a keyword to be filtered and click Apply. Your new keyword will be added to the filtered keyword listing. Domains Filtering Click the top checkbox to enable this feature.

  • Page 120: Qos - Quality Of Service

    QoS - Quality of Service QoS helps you to control the data upload traffic of each application from LAN (Ethernet and/ or Wireless) to WAN (Internet). It facilitates you the features to control the quality and speed of throughput for each application when the system is running with full upstream load. Application: Assign a name that identifies the new QoS application rule.
  • Page 121 Example 1: Optimize Your Home Network with QoS If you are actively engaged in using P2P and are afraid of slowing down internet access throughput of other users within your network, you can thus use QoS function to set different priorities for the different applications that members of your network will be using to avoid bandwidth traffic from getting overloaded.
  • Page 122 Example 2: Optimize Your Home Network with QoS If you are running a lot of standard applications you can just create a QoS rule that has its port range set from 1 ~ 1024 and its priority set to High. This port range is defined in RFC and so it can be used by all standard applications like FTP, Telnet, HTTPS etc.

  • Page 123: Virtual Server

    Virtual Server Virtual Server allows you to direct incoming traffic from WAN side (identified by Protocol and External port) to the Internal server with private IP address on the LAN side. The Internal port is required only if the external port needs to be converted to a different port number used by the server on the LAN side.

  • Page 124: Port Mapping

    Port Mapping Application: Select the service you wish to configure. Protocol: A protocol is automatically applied when an Application is selected from the listbox or you may select a protocol type which you want. External Port & Internal Port: Enter the public port number & range you wish to configure. Internal IP Address: Enter the IP address of a specific internal server to which requests from the specified port is forwarded.

  • Page 125: Dmz

    the specified IP address. The DMZ Host is a local computer exposed to the Internet. When setting a particular internal IP address as the DMZ Host, all incoming packets that do not use a port number which is already used by any other Virtual Server entries will first be checked by the Firewall and NAT algorithms before it is passed to the DMZ host.

  • Page 126: Wake On Lan

    Wake on LAN This feature provides greater flexibility for users to turn on / boot the computer of the network from a remotely site. MAC Address: Enter the MAC address of the target computer or you can select the MAC address directly from the Select drop down menu on the right.

  • Page 127: Certificate

    Certificate This feature is used for TR069 ACS Server authentication of the device used certificate, if necessary. If the imported certificate doesn't match the authorized certificate of the ACS Server, the device will have no access to the server. Trusted CA Certificate Name: the certificate identification name.
  • Page 128 Click Import Certificate button to import your certificate. Enter the certificate name and insert the certificate.
  • Page 129 Click Apply to confirm your settings.

  • Page 130: Time Schedule

    Time Schedule The Time Schedule supports up to 16 time slots which helps you to manage your Internet connection. In each time profile, you may schedule specific day(s) i.e. Monday through Sunday to restrict or allow the use of the Internet by users or applications. Time Schedule correlates closely with router time.

  • Page 131: Advanced

    Advanced Configuration options within the Advanced section are for users who wish to take advantage of the more advanced features of the router. Users who do not understand the features should not attempt to reconfigure their router, unless advised to do so by support staff. Here are the items within the Advanced section: Static Route,...

  • Page 132: Static Arp

    Static ARP This feature allows you to map the layer-2 MAC (Media Access Control) address that corresponds to the layer-3 IP address of the device. IP Address: Enter the IP of the device that the corresponding MAC address will be mapped to. MAC Address: Enter the MAC address that corresponds to the IP address of the device.

  • Page 133: Dynamic Dns

    Dynamic DNS The Dynamic DNS function lets you alias a dynamic IP address to a static hostname, so if your ISP does not assign you a static IP address you can still use a domain name. This is especially useful when hosting servers via your ADSL connection, so that anyone wishing to connect to you may use your domain name, rather than the dynamic IP address which is assigned to you by ISP.

  • Page 134: Vlan

    VLAN VLAN (Virtual Local Area Network) is a group of devices on different physical LAN segments that can communicate with each other as if they were all on the same physical LAN segment. Type: Select the VLAN type from the drop-down menu. There are three options: Port Based, Tag Based and Disable.
  • Page 135 Example: IPTV Service Setting Go to Advanced mode > Configuration > WAN > WAN Profile. Add a new WAN profile using the Pure Bridge protocol. Information should be provided by your local service provider. Note: Description name should not contain any space. Then go to Advanced mode >...

  • Page 136: Device Management

    Device Management The Device Management advanced configuration settings allow you to control your router’s security options and device monitoring features. Device Host Name Host Name: Assign it a name. Note: The Host Name must have more than a word. These two words should be connected with a ‘.’...
  • Page 137 control the required settings and removing the need for the user to control the advanced configuration of their device will make tasks such as port forwarding become easier. Both user’s Operating System and its relevant applications must support UPnP in addition to the router.
  • Page 138 Installing UPnP in Windows Example Follow the steps below to install the UPnP in Windows Me. Step 1: Click Start and Control Panel. Double-click Add/Remove Programs. Step 2: Click on the Windows Setup tab and select Communication in the Components selection box.
  • Page 139 Step 4: Click OK to go back to the Add/Remove Programs Properties window. Click Next. Step 5: Restart the computer when prompted. Follow the steps below to install the UPnP in Windows XP. Step 1: Click Start and Control Panel. Step 2: Double-click Network Connections.
  • Page 140 Auto-discover Your UPnP-enabled Network Device Step 1: Click start and Control Panel. Double-click Network Connections. An icon displays under Internet Gateway. Step 2: Right-click the icon and select Properties. Step 3: In the Internet Connection Properties window, click Settings to see the port mappings that were automatically created.
  • Page 141 Step 4: You may edit or delete the port mappings or click Add to manually add port mappings. Step 5: Select Show icon in notification area when connected option and click OK. An icon displays in the system tray. Step 6: Double-click on the icon to display your current Internet connection status.
  • Page 142 Step 3: Select My Network Places under Other Places. Step 4: An icon describing each UPnP-enabled device shows under Local Network. Step 5: Right-click on the icon of your BiPAC 7800(N) and select Invoke. The web configuration login screen displays.

  • Page 143: Igmp

    IGMP IGMP, known as Internet Group Management Protocol, is used to manage hosts from multicast group. IGMP Proxy: IGMP proxy enables the system to issue IGMP host messages on behalf of the hosts that the system has discovered through standard IGMP interfaces. The system acts as a proxy for its hosts.

  • Page 144: Tr-069 Client

    TR-069 Client Please contact your ISP for the information of TR069. Inform: You may enable or disable the periodic inform feature. Inform Interval: Enter the length of the periodic inform interval (unit: seconds). ACS URL: Enter the ACS URL address. ACS User Name: Enter the ACS server login name.

  • Page 145: Remote Access

    Remote Access Remote Access Control: Select Enable to allow management access from remote side (mostly from internet). "Allowed Access IP Address Range" was used to restrict which IP address could loggin to access system webGUI. Valid: means to enable the IP address Range limitation. IP Address Range: specifys the IP address Range.

  • Page 146: Save Configuration To Flash

    Save Configuration to Flash After changing the router’s configuration settings, you must save all of the configuration parameters to FLASH to avoid losing them after turning off or resetting your router. Click “Save Config“ and click “Apply” to write your new configuration to FLASH.

  • Page 147: Restart

    Restart Click “Restart” with option Current Settings to reboot your router (and restore your last saved configuration). If you wish to restart the router using the factory default settings (for example, after a firmware upgrade or if you have saved an incorrect configuration), select Factory Default Settings to reset to factory default settings.

  • Page 148: Chapter 5: Troubleshooting

    If your router is not functioning properly, please refer to the suggested solutions provided in this chapter. If your problems persist or the suggested solutions do not meet your needs, please kindly contact your service provider or Billion for support. Problems with the router...

  • Page 149: Appendix: Product Support & Contact

    Appendix: Product Support & Contact If you come across any problems please contact the dealer from where you purchased your prouct. Contact Billion Worldwide: http://www.billion.com MAC OS is a registered Trademark of Apple Computer, Inc. Windows 7/98, Windows NT, Windows 2000, Windows Me, Windows XP and Windows Vista are...

This manual is also suitable for:

Bipac 7800n

Table of Contents
