Billion BiPAC 7800(N) User Manual

(802.11n) dual wan adsl2+ firewall router
Hide thumbs Also See for BiPAC 7800(N):
Table of Contents

Advertisement

Quick Links

See also: User Manual
BiPAC 7800(N)
(802.11n) Dual WAN
ADSL2+ Firewall Router

User Manual

Version released 1.02b
Last revised date 06-03-2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BiPAC 7800(N) and is the answer not in the manual?

Questions and answers

Related Manuals for Billion BiPAC 7800(N)

Summary of Contents for Billion BiPAC 7800(N)

  • Page 1: User Manual

    BiPAC 7800(N) (802.11n) Dual WAN ADSL2+ Firewall Router User Manual Version released 1.02b Last revised date 06-03-2009...

  • Page 2: Table Of Contents

    Table of Contents Chapter 1: Introduction ..............1 Introduction to your Router ..............1 Features .................... 2 Chapter 2: Installing the Router ............5 Important note for using this router ............ 5 Package Contents ................. 6 Device Description ................. 7 The Front LEDs...................
  • Page 3 LAN ....................49 ..................49 Ethernet .................... 49 IP Alias ............50 Wireless (only for BiPAC 7800N) ..........52 Wireless Security (only for BiPAC 7800N) .............. 54 WPS (only for BiPAC 7800N) ................... 66 DHCP Server WAN....................67 ................67 WAN Profile (ADSL) ............
  • Page 4 ................. 102 TR-069 Client ................103 Remote Access Appendix: Product Support & Contact ........104...

  • Page 5: Chapter 1: Introduction

    Chapter 1: Introduction Introduction to your Router Thank you for purchasing BiPAC 7800(N) Router. Your new router is an all-in-one unit that combines an ADSL modem, ADSL2/2+ router and Ethernet network switch to provide everything you need to get the machines on your network connected to the Internet over an ADSL broadband connection.

  • Page 6: Features

    Features Express Internet Access The router complies with ADSL worldwide standards. It supports downstream rate up to 12/24 Mbps with ADSL2/2+, 8Mbps with ADSL. Users enjoy not only high-speed ADSL services but also broadband multimedia applications such as interactive gaming, video streaming and real-time audio much easier and faster than ever.
  • Page 7 web browser, ICQ, FTP, Telnet, E-mail, News, Net2phone, Ping, NetMeeting, IP phone and others. Domain Name System (DNS) Relay It provides an easy way to map the domain name (a friendly name for users such as www.yahoo. com) and IP address. When a local machine sets its DNS server with this router’s IP address, every DNS conversion request packet from the PC to this router will be forwarded to the real DNS in the outside network.
  • Page 8 Web based GUI It supports web based GUI for configuration and management. It is user-friendly and comes with on- line help. It also supports remote management capability for remote users to configure and manage this product. Firmware Upgradeable Device can be upgraded to the latest firmware through the WEB based GUI.

  • Page 9: Chapter 2: Installing The Router

    Chapter 2: Installing the Router Important note for using this router...

  • Page 10: Package Contents

    Package Contents BiPAC 7800(N) (802.11n) Dual WAN ADSL2+ Firewall Router CD containing the online manual RJ-11 ADSL/Telephone cable Ethernet (RJ-45) cable Three 2dBi detachable antennas (Wireless model only) Power adapter Quick Start Guide Splitter / Microfilter (Optional)

  • Page 11: Device Description

    Device Description The Front LEDs Meaning Lit orange when WAN port fails to get IP address. Lit green when WAN port gets IP address. Internet Lit off when device in bridged mode or ADSL connection not present. Lit Green when the device is successfully connected to an ADSL DSLAM.

  • Page 12: The Rear Ports

    The Rear Ports Port Meaning Power Switch Power ON/OFF switch. Power Connect it with the supplied power adapter. Press more than 1 second to restore the device to its default RESET mode. Push WPS button to trigger Wi-Fi Protected Setup function. (only for BiPAC 7800N) Connect to a PC or an office/home network of 10Mbps, 100Mbps or 1000Mbps using the provided RJ-45 Ethernet...

  • Page 13: Cabling

    Cabling One of the most common causes of problem is bad cabling or ADSL line(s). Make sure that all connected devices are turned on. On the front panel of your router is a bank of LEDs. Verify that the LAN Link and ADSL line LEDs are lit. If they are not, verify if you are using the proper cables. Make sure that all devices (e.g.

  • Page 14: Chapter 3: Basic Installation

    Chapter 3: Basic Installation The router can be configured through your web browser. A web browser is included as a standard application in the following operating systems: Linux, Mac OS, Windows 98/NT/2000/XP/Me/Vista, etc. The product provides an easy and user-friendly interface for configuration. Please check your PC network components.

  • Page 15: Connecting Your Router

    Connecting Your Router Users will not be able to connect to the internet through EWAN if DSL is already connected to the internet. Only one connection type (EWAN or DSL) is allowed to connect to the internet at one time. ADSL Router Mode Broadband Router Mode...

  • Page 16: Network Configuration

    Network Configuration Configuring PC in Windows Vista 1. Go to Start. Click on Network. 2. Then click on Network and Sharing Center at the top bar. 3. When the Network and Sharing Center window pops up, select and click on Manage network connec- tions on the left window column.
  • Page 17 5. Select Internet Protocol Version 4 (TCP/IPv4) then click Properties. 6. In the TCP/IPv4 properties window, select the Obtain an IP address au- tomatically and Obtain DNS Server address automatically radio but- tons. Then click OK to exit the set- ting.

  • Page 18: Configuring Pc In Windows Xp

    Configuring PC in Windows XP 1. Go to Start > Control Panel (in Classic View). In the Control Panel, double-click on Network Connections 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window, click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties.

  • Page 19: Configuring Pc In Windows 2000

    Configuring PC in Windows 2000 1. Go to Start > Settings > Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties.

  • Page 20: Configuring Pc In Windows 95/98/Me

    Configuring PC in Windows 95/98/Me 1. Go to Start > Settings > Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. 2. Select TCP/IP > NE2000 Compatible, or the name of your Network Interface Card (NIC) in your PC. 3.
  • Page 21 Configuring PC in Windows NT4.0 1. Go to Start > Settings > Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Prop- erties. 3. Select the Obtain an IP address from a DHCP server radio button and click...

  • Page 22: Factory Default Settings

    Factory Default Settings Before configuring your router, you need to know the following default settings. Web Interface (Username and Password) Username: admin Password: admin The default username and password are “admin” and “admin” respectively. Device LAN IP settings IP Address: 192.168.1.254 Subnet Mask: 255.255.255.0 ISP setting in WAN site PPPoE...

  • Page 23: Information From Your Isp

    Information from your ISP Before configuring this device, you have to check with your ISP (Internet Service Provider) to find out what kind of service is provided such as DHCP (Obtain an IP Address Automatically, Static IP (Fixed IP Address) or PPPoE. Gather the information as illustrated in the following table and keep it for reference.

  • Page 24: Chapter 4: Configuration

    GUI for any detail configuration. This configuration method is usually auto initiated if user is to connect to the internet via Billion's router for the first time.
  • Page 25 3. Please enter all the information in the blanks provided and then click continue. 4. The device will reboot and then load the new configuration. 5. If all information provided is valid and the device successfully connects to WAN, a dialog box will appear to signify the completion of the WAN port setup.
  • Page 26 7. Select Enable and enter the necessary information in the blanks provided for the Wireless LAN setting (wireless setting is only available for BiPAC 7800N) if you would like to use this feature and then click Continue. 8. The system will save your new configuration and complete the setup. You can test the con- nection by clicking on the URL link provided.

  • Page 27: Configuration Via Web Interface

    Configuration via Web Interface Open your web browser, enter the IP address of your router, which by default is 192.168.1.254, and click “Go”, a login window prompt will appear. The default username and password are “admin” and “admin” respectively. Congratulations! You are now successfully logon to the Firewall Router! If the authentication succeeds, the homepage “Device Info - Summary”...

  • Page 28: Quick Start

    Quick Start Step 1: Select WAN port connect mode from the connect mode drop down menu. There are two types of connect mode to choose from: ADSL or EWAN Step 2: After selecting the connect mode, press Continue to move on to the next configuring page. There are 5 types of connection protocols available under ADSL connect mode while there are 3 types of connection protocols available for EWAN connect mode.
  • Page 29 Step 3: After finishing configuring the WAN port connection, click Continue to proceed. The system will upload and apply the new WAN port configuration to the device. Step 4: After the configuration is successful, you may proceed to configure the Wireless setting. There are 4 types of security mode: WPA, WPA2, WPA/WPA2 Preshared Key &...
  • Page 30 ADSL Connect Mode For ADSL connect mode there are 5 types of connection protocols: PPPoE, PPPoA, IPoA, MPoA Pure Bridge. PPPoE VPI/VCI: Enter the information provided by your ISP. Username: Enter the username provided by your ISP. You can input up to 256 alphanumeric characters (case sensitive).
  • Page 31 PPPoA VPI/VCI: Enter the information provided by your ISP. Username: Enter the username provided by your ISP. You can input up to 256 alphanumeric characters (case sensitive). Password: Enter the password provided by your ISP. You can input up to 32 alphanumeric characters (case sensitive).
  • Page 32 IPoA Connection VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encapsulation method: Select the encapsulation format. Select the one provided by your ISP. IP Address: IPOA WAN IP address can only set fixed IP address. Netmask: User can change it to others such as 255.255.255.128. Type the netmask assigned to you by your ISP (if given).
  • Page 33 MPoA Connection VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encapsulation method: Select the encapsulation format. Select the one provided by your ISP. IP Address: Your WAN IP address. If the IP is set to 0.0.0.0 (auto IP detect), both netmask and gateway may be left blank.
  • Page 34 EWAN Connect Mode PPPoE connection Username: Enter the username provided by your ISP. You can input up to 256 alphanumeric characters (case sensitive). Password: Enter the password provided by your ISP. You can input up to 32 alphanumeric characters (case sensitive). Service Name: This item is for identification purposes.
  • Page 35 Obtain an IP Address Automatically Select this protocol enables the device to automatically retrieve IP address. Fixed IP Address IP Address: Enter your fixed IP address. Netmask: User can change it to others such as 255.255.255.128. Type the netmask assigned to you by your ISP (if given).
  • Page 36 Wireless Setting Mode (only for BiPAC 7800N) WPA / WPA2 / WPA/WPA2 Pre-shared Key WPA and WPA2 pre-shared keys are an authentication mechanism in which users provide some form of credentials to verify that they should be allowed access to a network. This requires a single password entered into each WLAN node (Access Points, Wireless Routers, client adapters, bridges).
  • Page 37 WLAN Service: Default setting is set to Enable. If you want to use wireless, you can select Enable. ESSID: The ESSID is the unique name of a wireless access point (AP) used to distinguish one from another. For security propose, change to a unique ID name which is already built into the router wireless interface.

  • Page 38: Status (Basic Mode)

    Status (Basic Mode)

  • Page 39: Cofiguration (Basic Mode)

    Cofiguration (Basic Mode) A WAN (Wide Area Network) is an outside connection to another network or the Internet. WAN – Main Port (ADSL) PPPoE Connection (ADSL) PPPoE (PPP over Ethernet) provides access control in a manner similar to dial-up services using PPP.
  • Page 40 PPPoA Connection (ADSL) PPPoA stands for Point to Point Protocol over ATM Adaptation Layer 5 (AAL5). It provides access control and billing functionality in a manner similar to dial-up services using PPP. VPI/VCI: Enter the information provided by your ISP. Username: Enter the username provided by your ISP.
  • Page 41 MPoA Connection (ADSL) VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encap. method: Select the encapsulation format. Select the one provided by your ISP. IP Address: Your WAN IP address. If the IP is set to 0.0.0.0 (auto IP detect), both netmask and gateway may be left blank.
  • Page 42 IPoA Connections (ADSL) VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encap. method: Select the encapsulation format. Select the one provided by your ISP. IP Address: Enter your fixed IP address. Netmask: User can change it to others such as 255.255.255.128. Type the netmask assigned to you by your ISP (if given).
  • Page 43 Pure Bridge Connections (ADSL) VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encap. method: Select the encapsulation format. Select the one provided by your ISP.

  • Page 44: Wan - Main Port (Ewan)

    WAN – Main Port (EWAN) Besides using ADSL to get connected to the Internet, EWAN port of BiPAC 7800(N) can be used as an alternative to connect to Cable Modems, VDSL and fiber optic lines. This alternative not only provides faster connection to the Internet, it also provides users with more flexibility to get online. PPPoE (EWAN) Username: Enter the username provided by your ISP.
  • Page 45 Obtain IP Address Automatically (EWAN) Select this protocol enables the device to automatically retrieve IP address. Fixed IP Address (EWAN) IP Address: Enter your fixed IP address. Netmask: User can change it to others such as 255.255.255.128. Type the netmask assigned to you by your ISP (if given).

  • Page 46: Wlan (Only For Bipac 7800N)

    WLAN (only for BiPAC 7800N) WPA / WPA2 / WPA/WPA2 Pre-Shared Key Wireless Parameters WLAN Service: Default setting is set to Enable. If you do not have any wireless, select Disable. ESSID: The ESSID is the unique name of a wireless access point (AP) used to distinguish one from another.
  • Page 47 Parameters WLAN Service: Default setting is set to Enable. If you do not have any wireless, select Disable. ESSID: The ESSID is the unique name of a wireless access point (AP) used to distinguish one from another. For security propose, change to a unique ID name which is already built into the router wireless interface.
  • Page 48 WEP Authentication: To prevent an unauthorized wireless station from accessing the data transmitted over the network, the router offers a secure data encryption, known as WEP. There are 3 options to select from: Open System, Shared key or both. Default Used WEP Key: Select the encryption key ID; please refer to Key (1~4) below. Passphrase: This is used to generate WEP keys automatically based upon the input string and a pre-defined algorithm in WEP64 or WEP128.

  • Page 49: Status (Advanced Mode)

    Status (Advanced Mode)

  • Page 50: Adsl

    ADSL DSP Firmware Version: DSP code version. DMT Status: Current DMT Status. Operational Mode: Display the ADSL state when the connect mode is set to AUTO. Upstream: Upstream rate. Downstream: Downstream rate. SNR Margin (Upstream): This shows the SNR margin for upstream rate. SNR Margin (Downstream): This shows the SNR margin for downstream rate.

  • Page 51: Arp

    This table stores mapping information that the device uses to find the Layer 2 Media Access Control (MAC) address that corresponds to the Layer 3 IP address of the device via the Address Resolution Protocol (ARP) feature. IP Address: Shows the IP Address of the device that the MAC address maps to. MAC Address: Shows the MAC address that is corresponded to the IP address of the device it is mapped to.

  • Page 52: System Log

    System Log Display all the system logs that have been recorded up to the present time.

  • Page 53: Configuration (Advanced Mode)

    Configuration (Advanced Mode) A Local Area Network (LAN) is a shared communication system network where many computers are connected. This type of network is area defined and is usually limited to a confined region within a building or just within the same storey of a building. There are 5 items within the LAN section: Ethernet, Alias, Wireless (7800N...

  • Page 54: Wireless (Only For Bipac 7800N)

    Wireless (only for BiPAC 7800N) Parameters WLAN Service: Default setting is set to Enable. If you do not have any wireless, select Disable. Mode: The default setting is 802.11g+n. If you do not know or have both 11g and 11b devices in your network, then keep the default in mixed mode.
  • Page 55 Channel width: Select either 20 MHz or 20/40 MHz for the channel bandwidth. The higher the bandwidth the better the performance will be. TX PowerLevel: It is a function that enhances the wireless transmitting signal strength. User may adjust this power level from minimum 0 up to maximum 100. Note: The Power Level maybe different in each access network user premise environment, choose the most suitable level for your network.

  • Page 56: Wireless Security (Only For Bipac 7800N)

    Wireless Security (only for BiPAC 7800N) You can disable or enable wireless security with WPA or WEP for protecting wireless network. The default mode of wireless security is disabled. WPA / WPA2 / WPA/WPA2 Pre-Shared Key Security Mode: You can choose the type of security mode you want to apply from the drop down menu.
  • Page 57 WEP Authentication: To prevent unauthorized wireless stations from accessing data transmitted over the network, the router offers secure data encryption, known as WEP. There are 3 options to select from: Open System, Shared key or both. Default Used WEP Key: Select the encryption key ID; please refer to Key (1~4) below. Passphrase: This is used to generate WEP keys automatically based upon the input string and a pre-defined algorithm in WEP64 or WEP128.

  • Page 58: Wps (Only For Bipac 7800N)

    WPS (only for BiPAC 7800N) WPS (WiFi Protected Setup) feature is a standard protocol created by Wi-Fi Alliance. This feature greatly simplifies the steps needed to create a Wi-Fi networks for a residential or an office setting. WPS supports 2 types of configuration methods which are commonly known among consumers: PIN Method &...
  • Page 59 Wi-Fi Network Setup (only for BiPAC 7800N) PIN Method: Configure AP as Registrar 1. Jot down the client’s Pin (eg. 16837546). 2. Enter the Enrollee’s PIN number and then press Start. 3. Launch the wireless client’s WPS utility (eg. Ralink Utility). Set the Config Mode as Enrollee, press the WPS button on the top bar, select the AP (eg.
  • Page 60 4. The client’s SSID and security setting will now be configured to match the SSID and security setting of the registrar.
  • Page 61 PIN Method: Configure AP as Enrollee 1. In the WPS configuration page, change the Role to Enrollee. Then press Start. 2. Jot down the WPS PIN (eg. 25879810). 3. Launch the wireless client’s WPS utility (eg. Ralink Utility). Set the Config Mode as Registrar. Enter the PIN number in the PIN Code column then choose the correct AP (eg.
  • Page 62 4. The router’s (AP’s) SSID and security setting will now be configured to match the SSID and security setting of the registrar. 5. Now to make sure that the setup is correctly done, cross check to see if the SSID and the secu- rity setting of the registrar setting match with the parameters found on both Wireless Configura- tion and Wireless Security Configuration page.
  • Page 65 PBC Method: 1. Press the PBC button of the AP. 2. Launch the wireless client’s WPS Utility (eg. Ralink Utility). Set the Config Mode as Enrollee. Then press the WPS button and choose the correct AP (eg. wlan-ap) from the WPS AP List section before pressing the PBC button to run the scan.
  • Page 66 3. When the PBC button is pushed, a wireless communication will be established between your router and the PC. The client’s SSID and security setting will now be configured to match the SSID and security setting of the router.
  • Page 67 Wi-Fi Network Setup with Windows Vista WCN: 1. Jot down the AP PIN from the Web (eg. 25879810). 2. Access the Wireless configuration of the web GUI. Set the WPS State to Unconfigured then click Apply. 3. In your Vista operating system, access the Control Panel page, then select Network and Inter- net >...
  • Page 68 4. Enter the AP SSID then click Next. 5. Enter the passphrase then click Next.
  • Page 69 6. When you have come to this step, you will have comleted the Wi-Fi network setup using the built-in WCN feature in Windows Vista.

  • Page 70: Dhcp Server

    DHCP Server DHCP allows networked devices to obtain information on the parameter of IP, Netmask, Gateway as well as DNS through the Ethernet Address of the device. If you check the DHCP Relay you must enter the IP address of the DHCP server that assigns an IP address to the DHCP client in the LAN.

  • Page 71: Wan

    A WAN (Wide Area Network) is a computer network that covers a broad geographical area (eg. Internet) that is used to connect LAN and other types of network systems. There are two items within the WAN section: WAN Profile ADSL Mode.
  • Page 72 Obtain DNS: A Domain Name System (DNS) contains a mapping table for domain name and IP addresses. DNS helps to find the IP address of a specific domain name. Check the checkbox to obtain DNS automatically. Primary DNS: Enter the primary DNS. Secondary DNS: Enter the secondary DNS.
  • Page 73 PPPoA Connection (ADSL) PPPoA stands for Point to Point Protocol over ATM Adaptation Layer 5 (AAL5). It provides access control and billing functions in a manner similar to dial-up services using PPP. Description: A given name for the connection. VPI/VCI: Enter the information provided by your ISP. Encap.
  • Page 74 when there is no activity on the line for a predetermined period of time. MTU: Control the maximum Ethernet packet size your PC will send.
  • Page 75 MPoA Connection (ADSL) Description: A given name for the connection. VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encap. method: Select the encapsulation format. Select the one provided by your ISP. NAT: The NAT (Network Address Translation) feature allows multiple users to access the Internet through a single ISP account by sharing a single IP address.
  • Page 76 IPoA Connections (ADSL) Description: A given name for the connection. VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encap. method: Select the encapsulation format. Select the one provided by your ISP. NAT: The NAT (Network Address Translation) feature allows multiple users to access the Internet through a single ISP account by sharing a single IP address.
  • Page 77 Pure Bridge Connections (ADSL) Description: A given name for the connection. VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encap. method: Select the encapsulation format. Select the one provided by your ISP.

  • Page 78: Wan Profile - Main Port (Ewan)

    WAN Profile – Main Port (EWAN) Besides using ADSL to connect to the Internet, BiPAC 7800(N) EWAN port is also an alternative to connect to Cable Modems, VDSL and fiber optic lines. This alternative provides users with faster connection & flexibility to connect to the Internet. PPPoE (EWAN) Username: Enter the username provided by your ISP.
  • Page 79 MAC Spoofing: This option is required by some service Providers. You must fill the MAC address specified by your service provider when this information is required. The default setting is set to disable.
  • Page 80 Obtain an IP Address Automatically NAT: The NAT (Network Address Translation) feature allows multiple users to access the Internet through a single IP account by sharing the single IP address. If users on your LAN have their own public IP addresses to access the Internet, NAT function can be disabled. MAC Spoofing: This option is required by some service Providers.
  • Page 81 Fixed IP Address NAT: The NAT (Network Address Translation) feature allows multiple users to access the Internet through a single IP account by sharing the single IP address. If users on your LAN have their own public IP addresses to access the Internet, NAT function can be disabled. MAC Spoofing: This option is required by some service Providers.

  • Page 82: Adsl Mode

    ADSL Mode ADSL Mode: There are 2 modes “Annex L” and “Annex M” that user can select for this connection. Modulator: There are 5 modes “ADSL2”, “ADSL2+”, “G.Lite:”, “T1.413” and “G.DMT” that user can select for this connection.

  • Page 83: System

    System There are five items within the System section: Time Zone, Firmware Upgrade, Backup/ Restore, Restart and User Management. Time Zone The router does not have a real time clock on board; instead, it uses the Simple Network Time Protocol (SNTP) to get the most current time from an SNTP server outside your network. Choose your local time zone from the drop down menu.

  • Page 84: Firmware Upgrade

    Firmware Upgrade Your router’s “firmware” is the software that allows it to operate and provides all its functionality. Think of your router as a dedicated computer, and the firmware as the software that runs in your router. Thus, by upgrading the newly improved version of the firmware allows you the advantage to use newly integrated features.

  • Page 85: Backup / Restore

    Backup / Restore These functions allow you to save a backup of the current configuration of your router to a defined location on your PC, or to restore a previously saved configuration. This is useful if you wish to experiment with different settings, knowing that you have a backup in hand in case any mistakes occur.

  • Page 86: Restart

    Restart There are 2 options for you to choose from before restarting the your 7800(N) device. You can either choose to restart your device to restore it to the Factory Default Settings or to restart the device with your current settings applied. Restarting your device to Factory Default Setting will be useful especially after you have accidentally changed your settings that may result in undesirable outcome.

  • Page 87: Firewall

    Firewall Packet Filter Packet filtering enables you to configure your router to block specific internal / external users (IP address) from Internet access, or disable specific service requests (Port number) to / from the Internet. This configuration program allows you to set up different filter rules for different users based on their IP addresses or their network Port number.

  • Page 88: Mac Filter

    Edit: Check the Rule No. you wish to edit, and then click “Edit”. Delete: Check the Rule No. you wish to delete, and then click “Delete”. MAC Filter A MAC (Media Access Control) address is the unique network hardware identifier for each PC on your network’s interface (i.e.

  • Page 89: Qos

    QoS helps you to control the data upload traffic of each application from LAN (Ethernet and/ or Wireless) to WAN (Internet). It facilitates you the features to control the quality and speed of throughput for each application when the system is running with full upstream load. Application: Assign a name that identifies the new QoS application rule.
  • Page 90 Example 1: Optimize Your Home Network with QoS If you are actively engaged in using P2P and are afraid of slowing down internet access throughput of other users within your network, you can thus use QoS function to set different priorities for the different applications that members of your network will be using to avoid bandwidth traffic from getting overloaded.
  • Page 91 Example 2: Optimize Your Home Network with QoS If you are running a lot of standard applications you cn just create a QoS rule that has its port range set from 1 ~ 1024 and its priority set to High. This port range is defined in RFC and so it can be used by all standard applications like FTP, Telnet, HTTPS etc.

  • Page 92: Virtual Server

    Virtual Server Virtual Server allows you to direct incoming traffic from WAN side (identified by Protocol and External port) to the Internal server with private IP address on the LAN side. The Internal port is required only if the external port needs to be converted to a different port number used by the server on the LAN side.

  • Page 93: Port Mapping

    Port Mapping Application: Select the service you wish to configure. Protocol: A protocol is automatically applied when an Application is selected from the listbox or you may select a protocol type which you want. External Port & Internal Port: Enter the public port number & range you wish to configure. Internal IP Address: Enter the IP address of a specific internal server to which requests from the specified port is forwarded.

  • Page 94: Dmz

    The DMZ Host is a local computer exposed to the Internet. When setting a particular internal IP address as the DMZ Host, all incoming packets that do not use a port number which is already used by any other Virtual Server entries will first be checked by the Firewall and NAT algorithms before it is passed to the DMZ host.

  • Page 95: Advanced

    Advanced Static Route With static route feature, you are equipped with the capability to control the routing of the all the traffic across your network. With each routing rule created, you can specifically assign the destination where the traffic will be routed to. Destination: Enter the destination IP where the traffic is to be forwarded.

  • Page 96: Dynamic Dns

    Dynamic DNS The Dynamic DNS function lets you alias a dynamic IP address to a static hostname, so if your ISP does not assign you a static IP address you can still use a domain name. This is especially useful when hosting servers via your ADSL connection, so that anyone wishing to connect to you may use your domain name, rather than the dynamic IP address which is assigned to you by ISP.

  • Page 97: Vlan

    VLAN VLAN (Virtual Local Area Network) is a group of devices on different physical LAN segments that can communicate with each other as if they were all on the same physical LAN segment.
  • Page 98 Example: IPTV Service Setting Go to Advanced mode > Configuration > WAN > WAN Profile. Add a new WAN profile using the Pure Bridge protocol. Information should be provided by your local service provider. Note: Description name should not contain any space. Then go to Advanced mode >...

  • Page 99: Device Management

    Device Management The Device Management advanced configuration settings allow you to control your router’s security options and device monitoring features. UPnP offers peer-to-peer network connectivity for PCs and other network devices, along with the feature to control data transfer between devices. UPnP offers many advantages for users running NAT routers through UPnP NAT Traversal, and on supported systems.
  • Page 100 Installing UPnP in Windows Example Follow the steps below to install the UPnP in Windows Me. Step 1: Click Start and Control Panel. Double-click Add/Remove Programs. Step 2: Click on the Windows Setup tab and select Communication in the Components selection box.
  • Page 101 Step 4: Click OK to go back to the Add/Remove Programs Properties window. Click Next. Step 5: Restart the computer when prompted. Follow the steps below to install the UPnP in Windows XP. Step 1: Click Start and Control Panel. Step 2: Double-click Network Connections.
  • Page 102 Auto-discover Your UPnP-enabled Network Device Step 1: Click start and Control Panel. Double-click Network Connections. An icon displays under Internet Gateway. Step 2: Right-click the icon and select Properties. Step 3: In the Internet Connection Properties window, click Settings to see the port mappings that were automatically created.
  • Page 103 Step 4: You may edit or delete the port mappings or click Add to manually add port mappings. Step 5: Select Show icon in notification area when connected option and click OK. An icon displays in the system tray. Step 6: Double-click on the icon to display your current Internet connection status.
  • Page 104 Web Configurator Easy Access With UPnP, you can access web-based configuration for the BiPAC 7800(N) without first finding out the IP address of the router. This helps if you do not know the router’s IP address. Follow the steps below to access web configuration. Step 1: Click Start and then Control Panel.

  • Page 105: Igmp

    IGMP IGMP, known as Internet Group Management Protocol, is used to manage hosts from multicast group. IGMP Proxy: IGMP proxy enables the system to issue IGMP host messages on behalf of the hosts that the system has discovered through standard IGMP interfaces. The system acts as a proxy for its hosts.
  • Page 106 TR-069 Client Please contact you ISP for the information of TR069. Inform: You may enable or disable the periodic inform feature. Inform Interval: Enter the length of the periodic inform interval (unit: seconds). ACS URL: Enter the ACS URL address. ACS User Name: Enter the ACS server login name.

  • Page 107: Remote Access

    Remote Access Remote Access Control: Select Enable to allow management access from remote side (mostly from internet).
  • Page 108 Appendix: Product Support & Contact If you come across any problems please contact the dealer from where you purchased your prod- uct. Contact Billion Worldwide: http://www.billion.com MAC OS is a registered Trademark of Apple Computer, Inc. Windows 98, Windows NT, Windows 2000, Windows Me, Windows XP and Windows Vista are registered...
