BIOS Setup Utility

3-1 SOYO COMBO SETUP

This motherboard does not use any hardware jumpers to set the CPU
frequency. Instead, CPU settings are software configurable with the BIOS
[SOYO COMBO SETUP].
After the hardware installation is complete, turn the power switch on, then
press the <DEL> key during the system diagnostic checks to enter the
Award BIOS Setup program. The CMOS SETUP UTILITY will display
on screen. Then, select the [SOYO COMBO SETUP] option from the
main menu and press the <Enter> key.
CPU TYPE :
CPU Frequency (MHz)
CPU Host/PCI Clock
CPU Ratio
DRAM Clock
AGP Clock
CAS Latency
Vcore Voltage Adjust
Boot Sequence
Quick Power On Self Test
POWER ON Function
Hot Key Power ON
Modem Ring Resume
RTC Alarm Resume
Date (of Month)
Timer (hh:mm:ss)
The [SOYO COMBO SETUP] menu combines the main parameters that
you need to configure, all in one menu, for a quick setup in BIOS.
ROM PCI/ISA BIOS
SOYO COMBO SETUP
AWARD SOFTWARE, INC.
CPU ID :
: Manual
: 100/33 MHz
: X 5 = 500 Mhz
: 100 MHz
: 66 MHz
: 3
: Normal
: A,C,SCSI
: Enabled
: BUTTON ONLY
: Ctrl-F1
: Disabled
: Disabled
:
:
CPU Warning Temperature
Current System Temp.
Current CPU Temperature
Current CPUFAN Speed
Current CHAFAN Speed
3.3V :
Vcore :
+12 V :
5VSB(V) :
PWRON After PWR-Fail
RTC Y2K H/W Rollover
ESC : Quit
F1 : Help
F5 : Old Values
F7 : Load Setup Defaults
53
SY-6VBA 133
: Disabled
: 26 ½ C / 78 ½ F
: 28 ½ C / 82 ½ F
: 5433 RPM
: 0 RPM
2.01 V VTT :
3.52 V + 5 V :
12.09 V VBAT(V) :
4.89 V
: Off
: Disabled
↑ ↓ → ←
: Select Item:
PU / PD / + / - : Modify
(Shift) F2 : Color
1.5 V
4.91 V
3.02 V
