Motherboard Description
n
CPU Multiplier
The SY-6VBA 133 supports a wide range of multipliers:
2.0x, 2.5x, 3.0x, 3.5x, 4.0x, 4.5x, 5.0x, 5.5x, 6.0x, 6.5x, 7.0x, 7.5x and
8.0x
n
CPU Core Voltage
The CPU Core voltage is set automatically according to CPU needs. The
SY-6VBA 133 supports an advanced Core voltage feature; it can be
adjusted through the BIOS directly without setting jumper. In normal
mode the voltage will be standard, apart from that the user can specify
increments of 2.5%, 5%, 7.5% and 10% on top of the standard voltage.
This will provide the CPU with the power it needs for overclocking.
Ø
EXPANDABILITY
The SY-6VBA 133 provides all the standard expansion slots, and many
more additional expansion features:
u
Expansion slots
n
1 x 32-bit bus mastering AGP slot
n
5 x 32-bit bus mastering PCI slots
n
2 x 16-bit ISA slots
u
Enhanced IO
n
Floppy disk controller
n
2x EIDE controllers with support for up to 4 Ultra DMA 33/66
devices
n
Standard/EPP/ECP parallel port
n
2x 16550 compatible serial ports
n
IrDA compatible infrared port
n
2x USB (Universal Serial Bus) connectors
n
PS/2 mouse connector
n
PS/2 keyboard connector
Ø
ADVANCED FUNCTIONS
The SY-6VBA 133 supports advanced functions such as:
n
Wake-On-LAN
Supports Wake-On-LAN (Some advanced network cards can
wake the system up over the network, the WOL connector is
