WARNING: Do not mount the camera on any soft material. The camera

may fall and be damaged.POE, Power, DIDO, Audio Connection:

h. Adjust the Lens

1) Adjust The Lens Angle

i. The lens holder can be rotated clockwise or counter clockwise.

ii. Release the tilt screw on both side of the device to tilt the lens up or

down. After completion, tighten the tilt screw.

iii. Release the video adjustment screw and to adjust the lens direction.

After completion, tighten the video adjustment screw.

(This function applies to all VD series, except for the VD-***Nf and VD-***Af.)
