3.10 Privacy Zone

Hide up to 4 unwanted scenes in a camera.
1. Place the cursor at the title field.
2. Hold down the CTRL key displays the privacy area menu while selecting the position using the
Joystick. Current position will be displayed. Release the CTRL key to complete the selection
of the position.
Or press the IRIS Open key then the privacy area menu displays. Move the desired position.
Press the IRIS Close key then the "CTRL" disappears and returns to the previous menu.
3. Place the cursor at the "TITLE" field. Twist the Joystick to enter the title edit mode. Follow the
procedure of the Auto Scan above to edit titles.
4. To turn the stored zone On or Off, twist the Joystick or press the Tele or Wide key.
5. Set the "METHOD", "BLOCK" or "V.OFF(video off)".
6. Select "SAVE AND EXIT" and push the Joystick to the right or press the IRIS Open key.
Press the ESC or IRIS Close key to exit the program without saving.
NOTE: Press the HOME key to delete programmed Privacy Zone at the title field.
PRIVACY ZONE SETUP
NO TITLE
01 ABC
02 DEF
03
04
SAVE AND EXIT(ESC TO CANCEL)
PRIVACY AREA MENU
NUMBER 001
354.8
18
(CTRL KEY)
METHOD
ON BLOCK
ON V.OFF
OFF ----
OFF ----
(CTRL KEY)
CONTROL
344.8
