3.4 Auto Scan
(Shortcut: SCAN)
The Auto Scan supports up to 5 programmed angles at user-programmable speeds.
Follow these steps to program Auto Scan:
NUMBER : 01 ~ 04, 09: AUTO-PAN mode.
TITLE : up to 12 characters.
MODE : NORMAL, VECTOR, RANDOM (AUTO-PAN mode: NORMAL, RANDOM only).
NORMAL : Move from start point to end point in panning only.
VECTOR : Move from start point to end point including tilt and zoom simultaneously and
linearly.
RANDOM : Move randomly between the start point and the end point.
SPEED : 01 ~ 13 step, the lower number means the slower speed.
SCAN DIR : Set the Scan direction, CCW(Counter Clock Wise), CW(Clock Wise).
SWAP : Swap the start point for the end point.
DWELL : Set the dwell time at the both end, 01 ~ 99 seconds.
1. Press the SCAN key to enter the Auto Scan menu directly. Or press the MENU key to display
the main menu on the monitor. Scroll to Auto Scan and push the Joystick to the right.
2. Select "NUMBER" and set the desired number by pushing the Joystick to the left or right.
3. Select "TITLE" and twist the Joystick to enter the title edit mode.
4. Twist the Joystick to change the alphanumeric characters and move the next position by
pushing the Joystick to the left or right. Or move down to the character table and press the
CTRL or IRIS Open key at the desired character then the cursor position moves to the next
position automatically. Push the Joystick to the left or right at the "ALL DELETE" field to
delete all characters. Push the Joystick to the left or right at the "EXIT" field to finish title edit
menu.
5. Select "MODE" and "SPEED".
AUTO SCAN SETUP
NUMBER
TITLE
MODE
SPEED
START ANGLE
END ANGLE
SCAN DIR
SWAP
DWELL
SAVE AND EXIT(ESC TO CANCEL)
TITLE EDIT MENU
A01
*
A B C D E F G H I J
K L M N O P Q R S T
U V W X Y Z 0 1 2 3
4 5 6 7 8 9 ( )
ALL DELETE
EXIT(ESC TO EXIT)
10
: 01
: A01
: NORMAL
: 5 STEP
: ----- -----
: ----- -----
: CCW
: OFF
: 03 SEC
