Page 1: Reference Manual
Version 1.0 Reference Manual C DA 5005 5 Channel SDI to CVBS Converter © LYNX Technik AG Brunnenweg 3 D-64331 Weiterstadt Germany www.lynx-technik.com... - Page 2 Except as expressly written by LYNX Technik AG, the furnishing of this document does not give you any license to patents, trademarks, copyrights or other intellectual property of LYNX Technik AG or any of its affiliates.
-
Page 3: Warranty
LYNX Technik, with shipping charges prepaid. LYNX Technik shall pay for the return of the product to the customer if the shipment is within the country which the LYNX Technik service center is located. -
Page 4: Regulatory Information
Reference Manual C DA 5005 Version1.0 Regulatory information Europe Declaration of Conformity LYNX Technik AG Brunnenweg 3 D-64331 Weiterstadt Germany Declare under our sole responsibility that the product TYPE: C DA 5005 To which this declaration relates is in conformity with the following... -
Page 5: Table Of Contents
Reference Manual C DA 5005 Version1.0 Contents Warranty ......................3 Regulatory information..................4 Europe........................4 Declaration of Conformity ................4 USA ........................4 FCC 47 Part 15.....................4 Getting Started ....................7 Packaging......................7 Product Description ..................7 Functional Diagram ..................8 Module Layout ....................8 Connections ......................10 Video Connections..................10 Installation ......................11 Settings and Control ..................12... - Page 6 Reference Manual C DA 5005 Version1.0 This page is intentionally left blank Page 6...
-
Page 7: Getting Started
Please retain the shipping cartons in case subsequent shipping of the product becomes necessary. Product Description The C DA 5005 is a 5 channel Monitoring 8 bit video D/A converter designed primarily for broadcast and professional applications. The Module accepts 5 SDI input signals and provides one CVBS output per channel. -
Page 8: Functional Diagram
C DA 5005 CardModule. Figure 1- C DA 5005 Functional Diagram Module Layout Figure 2 shows the physical layout of the C DA 5005 CardModule and also the connection panel which is fitted to the rear of the rack. - Page 9 Reference Manual C DA 5005 Version1.0 Figure 2 – Module Layout Page 9...
-
Page 10: Connections
PCB. Static discharge could result in serious damage to the module. Connections Video Connections The C DA 5005 CardModule is configured with standard 75 Ohm BNC connectors. Connection is self-explanatory. We recommend the use of high quality video cables for digital video connections to reduce the risk of interference or errors due to excessive cable attenuation. -
Page 11: Installation
Reference Manual C DA 5005 Version1.0 Installation Caution The CardModule is shipped in a protective anti-static bag. Please take suitable precautions to avoid static discharge onto any part of the PCB or components when handling module or serious damage could result. -
Page 12: Settings And Control
Reference Manual C DA 5005 Version1.0 Settings and Control The C DA 5005 has an integrated micro-controller, which enables the module to be configured and controlled locally using integral 8 position dip switch and the multifunction switch or from remote when using one of the optional controllers and control software. -
Page 13: Control Modes
Reference Manual C DA 5005 Version1.0 Control Modes There are two modes for the use of the dip switches and the corresponding LEDs: Channel Status Mode: In this mode the Dip Switches are used to switch the test signal (color bars) ON or OFF for the corresponding channel. -
Page 14: Switch Settings
Reference Manual C DA 5005 Version1.0 Switch Settings Below the switch settings for the 8-position dip- switch are defined. Please see the section following the table for more detail on the switch function. There are two modes for the use of the dip switches... -
Page 15: Switch Function Detail
Reference Manual C DA 5005 Version1.0 ALARM ENABLE MODE Switch Setting Function Toggle on-off-on: Re-acquire local control Alarm Enable Mode Channel Status Mode Color bars if no input Black if no input Channel 5 Alarm Enabled Channel 5 Alarm Disabled... - Page 16 Reference Manual C DA 5005 Version1.0 Dip Switch 2 This switch selects either the Channel Status Mode or Reference Configuration Mode as described above. ON = Channel Status Mode, OFF = Alarm Enable Mode Dip Switch 3 This is used to select what type signal is output for channels with input signal lost.
-
Page 17: Factory Preset Condition
Reference Manual C DA 5005 Version1.0 Factory Preset Condition The C DA 5005 is delivered preset for the following mode of operation: • Local control ENABLED • Channel Status Mode • Test Signal Color Bars • Test Signal OFF – Normal operation for all channels •... -
Page 18: Alarm/Led Status Indicators
Reference Manual C DA 5005 Version1.0 Alarm/LED Status Indicators The C DA 5005 module has six LED indicators, which serve as alarm and status indication for the module (Figure 2 or 3). Function is described below. Status Indicators 5 Status LEDs are provided on the module edge LED 1 –... -
Page 19: Locate Function
Reference Manual C DA 5005 Version1.0 Locate Function For larger systems which may have multiple MiniModules of the same type in a single rack, or multiple rack systems on a large central control system we have added a useful utility which will... -
Page 20: Specifications (C Da 5005)
Reference Manual C DA 5005 Version1.0 Specifications (C DA 5005) Inputs Signal Serial 4:2:2 SMPTE 259M-C (270 Mbit/s) Standards NTSC-(M/N), PAL (B/D/G/H/I/N/60) Auto detection Return Loss >15dB (270MHz) Cable Equalization 250 m (Belden 8281) Connection Impedance 75 Ohms Outputs Signal (composite) -
Page 21: Available Options
Reference Manual C DA 5005 Version1.0 Available Options Below is a list of related products for the C DA 5005 CardModule. Please refer to product brochures or our web site for more detailed information. Model Description Series 5000 Rack Frame (empty) with single... -
Page 22: Service
Reference Manual C DA 5005 Version1.0 Service If you are experiencing problems, or have questions concerning your C DA 5005 CardModule please contact your local distributor for assistance. We offer a fixed cost service exchange program for defective Series 5000 CardModules out of Warranty. -
Page 23: Contact Information
Reference Manual C DA 5005 Version1.0 Contact Information Please contact your local distributor; this is your local and fastest method for obtaining support and sales information. LYNX Technik can be contacted directly using the information below. Address LYNX Technik AG Brunnenweg 3 D-64331 Weiterstadt Germany. - Page 24 Reference Manual C DA 5005 Version1.0 This page is intentionally left blank Page 24...
