- Page 1 Version 1.1 Reference Manual C AD 3320 SB / C AD 3321 SB Dual Analog Audio to AES Converter C AD 3320 SB AES REF VID REF AES 1 out AUD 1L in AES 2 out AUD 1R in AUD 2L in made in Germany www.lynx-technik.com...
- Page 2 Except as expressly written by LYNX Technik AG, the furnishing of this document does not give you any license to patents, trademarks, copyrights or other intellectual property of LYNX Technik AG or any of its affiliates.
-
Page 3: Warranty
LYNX Technik, with shipping charges prepaid. LYNX Technik shall pay for the return of the product to the customer if the shipment is within the country which the LYNX Technik service center is located. -
Page 4: Regulatory Information
Brunnenweg 3 D-64331 Weiterstadt Germany Declare under our sole responsibility that the product TYPE: C AD 3320 SB / C AD 3321 SB To which this declaration relates is in conformity with the following standards (environments E1-E3): EN 55103-1 /1996... -
Page 5: Table Of Contents
Factory Preset Condition ................20 Alarm/LED Status Indicators..............21 Channel Condition Indicators ..............21 Front Panel Alarm Indicator ..............22 Locate Function..................22 Specifications (C AD 3320 SB / C AD 3321 SB)........23 Available Options ................24 Parts List....................25 Service ....................25 Contact Information ................26 Page 5... - Page 6 Reference Manual C AD 3320 SB Version1.1 This page is intentionally left blank Page 6...
-
Page 7: Getting Started
LYNX control software. The C AD 3320 SB / C AD 3321 SB is part of the 3000 series of MiniModules, which offer high quality, modularity and flexibility in a very small form factor ideal for applications where space is at a premium. -
Page 8: Features
Reference Manual C AD 3320 SB Version1.1 tightly integrated space saving system where up to 10 MiniModules can be mounted utilizing the optional LYNX R FR 3005 / 3010 rack housing. This includes integrated power supply and optional remote control interfaces. -
Page 9: Functional Diagram
Remote Status Alarm Switch Figure 1- C AD 3320 SB / C AD 3321 SB Functional Diagram Module Layout Figure 2 shows the physical layout of the C AD 3320 SB / C AD 3321 SB MiniModule. This module utilizes... - Page 10 Reference Manual C AD 3320 SB Version1.1 Figure 2 – Module Layout Page 10...
-
Page 11: Connections
Reference Manual C AD 3320 SB Version1.1 Connections Audio Connections The C AD 3320 SB / C AD 3321 SB MiniModule is configured for Weco connectors for analog audio inputs and 75 Ohm BNC connectors AES3id Digital outputs. The Weco connectors should be wired as indicated below. -
Page 12: Audio Input Connections (Un-Balanced)
Reference Manual C AD 3320 SB Version1.1 Audio Input Connections (un-balanced) Although the module is designed primarily for balanced line audio connections it is possible to make un-balanced audio connections to the module. NOTE. When used in this manor certain technical specifications of the module cannot be maintained. -
Page 13: Power Connections
Reference Manual C AD 3320 SB Version1.1 Power Connections If using the module in a stand-alone application use the separate R PS 3001 E (for Europe), R PS 3001 U (USA) power brick option or R PS 3001-3 desk power supply. -
Page 14: Installation
Reference Manual C AD 3320 SB Version1.1 Installation Mechanical Stand Alone Operation The C DA 3320 SB MiniModule can be used in a stand alone application. There are two options for the use of the module in this way. a) Using the R FR 3005 Rack Frame 1 option. This... -
Page 15: Multiple Units
Reference Manual C AD 3320 SB Version1.1 Multiple Units Most applications will require more than one MiniModule, which can include any of the available Series 3000 MiniModule product range. There are two options for mounting multiple units. a) Using the R FR 3005 Rack Frame option. This... -
Page 16: Electrical Installation
Reference Manual C AD 3320 SB Version1.1 Electrical Installation. Stand Alone Operation The MiniModule requires the R PS 3001 power brick option for stand-alone operation. Three versions are available, R PS 3001 E for European markets, R PS 3001 U for the US markets and the R PS 3001-3 desk power supply. -
Page 17: Multiple Units
Settings and Control The C AD 3320 SB / C AD 3321 SB has an integrated micro-controller, which enables the module to be configured and controlled locally via the integral... -
Page 18: Switch Settings
Reference Manual C AD 3320 SB Version1.1 Switch Settings Below the switch settings for the 8-position dip- switch are defined. Please refer to figure 2 for the location of the switch. DIP Switch 1 1 2 3 4 DIP Switch 2... -
Page 19: Switch Function Detail
Reference Manual C AD 3320 SB Version1.1 * Value selected depends on the range selected with switch 5 ** Value selected depends on range selected on switch 2 Switch Function Detail Dip Switch 1: Switch 1. Local Control Enable. ON enables local control (LED 3 green) and makes selections on the DIP switches active. -
Page 20: Auto Store
Reference Manual C AD 3320 SB Version1.1 Switch 2. Select full scale range (Switch 1 OFF) ON =15dBu for C AD 3320 and 18dBu for C AD 3321 OFF =12dBu for C AD 3320 and 15dBu for C AD 3321 Note. -
Page 21: Alarm/Led Status Indicators
Reference Manual C AD 3320 SB Version1.1 Alarm/LED Status Indicators The C AD 3320 SB / C AD 3321 SB module has built in LED indicators that serve as alarm and status indication for the module. Function is described below. -
Page 22: Front Panel Alarm Indicator
Reference Manual C AD 3320 SB Version1.1 Front Panel Alarm Indicator There is also a single alarm LED on the front side of the module, (figure2) which is designed for quick and easy indication of a problem condition in installations where visible access to the bottom of the module is not convenient. -
Page 23: Specifications (C Ad 3320 Sb / C Ad 3321 Sb)
85.5mm x 35.3mm x 27mm + connectors Weight 150g Ambient Temperature 5°C to 35°C Maintaining specifications -20°C to 70°C Storage Humidity Max 80% non condensing Supplied Accessories Documentation C AD 3320 SB / C AD 3321 SB Reference Manual Page 23... -
Page 24: Available Options
Reference Manual C AD 3320 SB Version1.1 Available Options Below is a list of available options for the C AD 3320 SB / C AD 3321 SB MiniModule. Please refer to product brochures or our web site for more detailed information. -
Page 25: Parts List
Parts List Due to the very dense design and high level of integration there are no user serviceable electronic assemblies within the C AD 3320 SB / C AD 3321 SB module. C AD 3320 SB Mini Module (complete) Description... -
Page 26: Contact Information
Reference Manual C AD 3320 SB Version1.1 Contact Information Please contact your local distributor; this is your local and fastest method for obtaining support and sales information. LYNX Technik can be contacted directly using the information below. Address LYNX Technik AG... - Page 27 Reference Manual C AD 3320 SB Version1.1 Notes Page 27...
