    Reference Manual Version 2.0 C DX 5024 C SDI to Analog Audio & Video Converter © LYNX Technik AG Brunnenweg 3 D-64331 Weiterstadt Germany www.lynx-technik.com...
  • Page 2 Except as expressly written by LYNX Technik AG, the furnishing of this document does not give you any license to patents, trademarks, copyrights or other intellectual property of LYNX Technik AG or any of its affiliates.

  • Page 3: Warranty

    LYNX Technik, with shipping charges prepaid. LYNX Technik shall pay for the return of the product to the customer if the shipment is within the country which the LYNX Technik service center is located.

  • Page 4: Regulatory Information

    Reference Manual C DX 5024 C Version 2.0 Regulatory information Europe Declaration of Conformity LYNX Technik AG Brunnenweg 3 D-64331 Weiterstadt Germany Declare under our sole responsibility that the product TYPE: C DX 5024 C To which this declaration relates is in conformity with the following...

  • Page 5: Table Of Contents

    Reference Manual C DX 5024 C Version 2.0 Contents Warranty ...................3 Regulatory information............4 Europe....................4 Declaration of Conformity ............4 USA ....................4 FCC 47 Part 15................4 Contents ...................5 Getting Started .................7 Packaging..................7 Product Description ................7 Functional Diagram ................9 Module Layout..................9 Connections ................11 Video Connections................11...
  • Page 6 Reference Manual C DX 5024 C Version 2.0 This page is intentionally left blank Page 6...

  • Page 7: Getting Started

    Please retain the shipping cartons in case subsequent shipping of the product becomes necessary. Product Description The C DX 5024 C is a high quality Audio de- multiplexer and Audio and Video D to A Converter primarily for broadcast and professional applications.
  • Page 8 Reference Manual C DX 5024 C Version 2.0 The module has a built in micro-controller with local controls, status and alarm indicators and well as internal flash ram for storing setups. Any operational parameters configured and stored into the module are recalled when powered up.

  • Page 9: Functional Diagram

    Reference Manual C DX 5024 C Version 2.0 Functional Diagram Figure 1 below is the basic functional diagram for the C DX 5024 C CardModule. Figure 1- C DX 5024 C Functional Diagram Module Layout Figure 2 shows the physical layout of the C DX 5024 C CardModule and also the connection panel that is fitted to the rear of the rack.
  • Page 10 Reference Manual C DX 5024 C Version 2.0 Figure 2 – Module Layout Page 10...

  • Page 11: Connections

    PCB. Static discharge could result in serious damage to the module. Connections Video Connections The C DX 5024 C CardModule is configured with standard 75 Ohm BNC connectors. Connection is self-explanatory. We recommend the use of high quality video cable for digital video connections to reduce the risk of interference or errors due to excessive cable attenuation.

  • Page 12: Audio Connections

    Reference Manual C DX 5024 C Version 2.0 Audio Connections Audio Output Connections (balanced) SubD 25 pin female connector. Connection Connection Number Number + Left 1 - Left 1 GND Left 1 + Right 1 - Right 1 GND Right 1...

  • Page 13: Installation

    Reference Manual C DX 5024 C Version 2.0 Installation Caution The CardModule is shipped in a protective anti-static bag. Please take suitable precautions to avoid static discharge onto any part of the PCB or components when handling module or serious damage could result.

  • Page 14: Link Settings

    All Series 5000 Card Modules can be hot plugged / unplugged. Settings and Control The C DX 5024 C has an integrated micro- controller, which enables the module to be configured and controlled locally using the...

  • Page 15: Multi Function Switch

    Reference Manual C DX 5024 C Version 2.0 Multi Function Switch The CardModule is equipped with a multi-function switch located on the front bottom edge of the card (refer to figure 2) Multi-function Switch Side Front Switch Operations Down Enter Figure 3 –...

  • Page 16: Using The Local Display Menus

    Reference Manual C DX 5024 C Version 2.0 Using the Local Display Menus Making local adjustments to the module is done using the multifunction switch and the integrated 4- character dot matrix display (figure 3). The menu system is layered, and navigation through the system is done using the UP and DOWN functions of the switch.

  • Page 17: Menu Structure

    Reference Manual C DX 5024 C Version 2.0 Menu Structure The Menu structure is defined in the next table, and should be used when navigating through the system. Notes / Tips. ENTER moves between Levels UP/DOWN moves between items within the level When you enter a new setting the system will jump back one level in the menu system.

  • Page 18: Factory Preset Condition

    Reference Manual C DX 5024 C Version 2.0 Factory Preset Condition The C DX 5024 C is delivered preset for the following mode of operation: • Audio Group 1 selected • Full Scale Level 15dBu (analog Audio) • Video Output Component •...
  • Page 19 Reference Manual C DX 5024 C Version 2.0 Page 19...
  • Page 20 Reference Manual C DX 5024 C Version 2.0 Page 20...
  • Page 21 Reference Manual C DX 5024 C Version 2.0 Page 21...
  • Page 22 Reference Manual C DX 5024 C Version 2.0 Page 22...
  • Page 23 Reference Manual C DX 5024 C Version 2.0 Page 23...

  • Page 24: Alarm/Led Status Indicators

    Reference Manual C DX 5024 C Version 2.0 Alarm/LED Status Indicators The C DX 5024 C module has several LED indicators on the card edge that serve as alarm and status indication for the module. The alarm indicator is visible with the cover fitted to the rack. LED functions are described below.

  • Page 25: Locate Function

    Reference Manual C DX 5024 C Version 2.0 Locate Function For larger systems which may have multiple MiniModules of the same type in a single rack, or multiple rack systems on a large central control system we have added a useful utility which will...

  • Page 26: Specifications (C Dx 5024 C)

    Reference Manual C DX 5024 C Version 2.0 Specifications (C DX 5024 C) Digital Video Input SDI Video 1 x Serial Digital Video. SMPTE 259 A-D Embedded Audio SMPTE 272 M-C Input impedance 75 Ohm (BNC connector) Digital Video Output Signal (Video) 2 x reclocked Serial Digital Video.

  • Page 27: Available Options

    Reference Manual C DX 5024 C Version 2.0 Available Options Below is a list of related products for the C DX 5024 C CardModule. Please refer to product brochures or our web site for more detailed information. Model Description Series 5000 Rack Frame (empty) with single...

  • Page 28: Service

    Reference Manual C DX 5024 C Version 2.0 Service If you are experiencing problems, or have questions concerning your C DX 5024 CardModule please contact your local distributor for assistance. We offer a fixed cost service exchange program for defective Series 5000 CardModules out of Warranty.

  • Page 29: Contact Information

    Reference Manual C DX 5024 C Version 2.0 Contact Information Please contact your local distributor; this is your local and fastest method for obtaining support and sales information. LYNX Technik can be contacted directly using the information below. Address LYNX Technik AG...
  • Page 30 Reference Manual C DX 5024 C Version 2.0 This page is intentionally left blank Page 30...
