Page 1: Reference Manual
Reference Manual Ver 1.1 C AD 3100 12 Bit CVBS / YC to SDI Converter © LYNX Technik AG Brunnenweg 3 64331 Weiterstadt Germany www.lynx-technik.com... - Page 2 Except as expressly written by LYNX Technik AG, the furnishing of this document does not give you any license to patents, trademarks, copyrights or other intellectual property of LYNX Technik AG or any of its affiliates.
-
Page 3: Warranty
LYNX Technik, with shipping charges prepaid. LYNX Technik shall pay for the return of the product to the customer if the shipment is within the country which the LYNX Technik service center is located. -
Page 4: Regulatory Information
Reference Manual C AD 3100 Version 1.1 Regulatory information Europe Declaration of Conformity LYNX Technik AG Brunnenweg 3 D-64331 Weiterstadt Germany Declare under our sole responsibility that the product TYPE: C AD 3100 To which this declaration relates is in conformity with the following... -
Page 5: Table Of Contents
Reference Manual C AD 3100 Version 1.1 Contents Warranty ......................3 Regulatory information ..................4 Europe........................4 Declaration of Conformity ................4 USA ........................4 FCC 47 Part 15.....................4 Contents ......................5 Getting Started....................7 Packaging......................7 Product Description ..................7 Functional Diagram ..................9 Module Layout ....................9 Connections ...................... - Page 6 Reference Manual C AD 3100 Version 1.1 This Page is intentionally left blank Page 6...
-
Page 7: Getting Started
Please retain the shipping cartons in case subsequent shipping of the product becomes necessary. Product Description The C AD 3100 is a high quality 12 bit video analog to digital converter designed primarily for broadcast and professional applications. The Module accepts Composite (CVBS) or Luma/... - Page 8 • Test signal select (color bars, color bars over red, black, pll / equalizer pathological) The C AD 3100 is part of the 3000 series of MiniModules, which offer high quality, modularity and flexibility in a very small form factor ideal for applications where space is at a premium.
-
Page 9: Functional Diagram
C AD 3100 MiniModule. Figure 1- C AD 3100 Functional Diagram Module Layout Figure 2 shows the physical layout of the C AD 3100 MiniModule. Connections are made through standard 75 Ohm BNC video connections. Module configuration is set via a small dip-switch located behind an access hole in the bottom of the module. - Page 10 Reference Manual C AD 3100 Version 1.1 Figure 2 – Module Layout Page 10...
-
Page 11: Connections
Reference Manual C AD 3100 Version 1.1 Connections Video Connections The C AD 3100 MiniModule is configured with standard 75 Ohm BNC connectors. Connection is self-explanatory. We recommend the use of high quality video cable suitable for digital video connections to reduce the risk of interference or errors due to excessive cable attenuation. -
Page 12: Power Connections
Reference Manual C AD 3100 Version 1.1 Power Connections If using the module in a stand-alone application use the separate R PS 3001 E (for Europe), R PS 3001 U (USA) power brick option or the R PS 3001-3 desk power supply. -
Page 13: Installation
Installation Mechanical Stand Alone Operation The C AD 3100 MiniModule can be used in a stand alone application. There are two options for the use of the module in this way. a) Using the R FR 3005 Rack Frame 1 option. This... -
Page 14: Multiple Units
Reference Manual C AD 3100 Version 1.1 Multiple Units Most applications will require more than one MiniModule, which can include any of the available Series 3000 MiniModule product range. There are two options for mounting multiple units. a) Using the R FR 3005 Rack Frame option. This... -
Page 15: Electrical Installation
/ receiving the signals from the module or damage can result. Caution. Only use the optional Lynx R PS 3001 power modules. Ensure the 5-pin power connector is locked securely in place. -
Page 16: Settings And Control
Reference Manual C AD 3100 Version 1.1 Settings and Control The C AD 3100 is configured via the integral 6- position dip-switch. This is located on the bottom of the module and can be accessed through the cutout provided (fig 2) -
Page 17: Switch Function Detail
Reference Manual C AD 3100 Version 1.1 Switch Function Detail Dip Switch 1 Enables or disables local control ON this will enable local control OFF this disables local control, the module can only be controlled via remote control Dip Switch 2 Studio Quality input or Low Quality input. -
Page 18: Auto Store
Reference Manual C AD 3100 Version 1.1 Auto Store If no parameters are changed for 10 seconds then the current settings will be written into flash memory automatically, this can be seen by the front LED flashing yellow four times. -
Page 19: Factory Preset Condition
Reference Manual C AD 3100 Version 1.1 Factory Preset Condition The C AD 3100 is delivered preset for the following mode of operation: • CVBS (composite) operation • Video re-construction lowpass filter enabled • Y full bandwidth • Auto clamp •... -
Page 20: Alarm/Led Status Indicators
Reference Manual C AD 3100 Version 1.1 Alarm/LED Status Indicators The C DA 3100 module has built in LED indicators, which serve as alarm and status indication for the module. Function is described below. Module Edge Status LED 2 Status LEDs are provided on the module edge,... -
Page 21: Locate Function
Reference Manual C AD 3100 Version 1.1 Locate Function For large systems which have many modules in various locations we have added a utility which will help visually identify a module quickly. (When used in conjunction with the optional control system and... -
Page 22: Specifications (C Ad 3100)
85.5mm x 35.3mm x 27 mm + connectors Weight 250g Ambient Temperature 5°C to 35°C Maintaining specifications -20°C to +70°C Storage Humidity Max 80% non condensing Supplied Accessories Documentation C AD 3100 Reference Manual and quick ref guide Page 22... -
Page 23: Available Options
Reference Manual C AD 3100 Version 1.1 Available Options Below is a list of available options for the C AD 3100 MiniModule. Please refer to product brochures or our web site for more detailed information. Model Description External brick power supply module for R PS 3001 E Series 3000 MiniModules. -
Page 24: Parts List
Reference Manual C AD 3100 Version 1.1 Parts List Due to the very dense design and high level of integration there are no user serviceable electronic assemblies within the C AD 3110 module. C AD 3100 Mini Module (complete) Description 12 Bit CVBS to SDI Conv. -
Page 25: Contact Information
Reference Manual C AD 3100 Version 1.1 Contact Information Please contact your local distributor; this is your local and fastest method for obtaining support and sales information. LYNX Technik can be contacted directly using the information below. Address LYNX Technik AG... - Page 26 Reference Manual C AD 3100 Version 1.1 Notes Page 26...
