- Page 1 CS-802D Ultra High Resolution Scaler Operation Manual Operation Manual...
- Page 2 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
-
Page 3: Safety Precautions
SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 4: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......1 5. Features ..........1 6. Operation Controls and Functions ..2 6.1 Front Panel ........2 6.2 Rear Panel .........4 7.OSD Menu and Function List ....5 8. -
Page 5: Introduction
1. INTRODUCTION This Ultra Hight Resolution Scaler with Dual-Link DVI, Mini-DisplayPort and PC/Component inputs to its HDMI output and the associated audio signal processed synchronously. Accepting most of PC/Graphic signal and scaling features can be handled easily through on-panel buttons, IR remote control, or RS-232 protocol. 2. -
Page 6: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel OPTICAL AUDIO HDMI OUT POWER DC 5V MENU/ ENTER OPTICAL AUDIO 720P MENU/ENTER Press this button to ENTER the OSD menu. Press again to confirm the selection. Press it together with - button to switch output to720p or with + button to swtich output to XGA instantly. - Page 7 AUDIO L/R OUT This slot is where you connect the speaker or amplifier with audio phone jack to the display. OPTICAL IN This slot is where you connect the input OPTICAL audio source. AUDIO L/R IN This slot is where you connect the L/R input audio source. HDMI OUT This slot is where you connect the HDMI display with HDMI cable.
-
Page 8: Rear Panel
6.2 Rear Panel RS232 Dual-Link DVI PC/COMP SERVICE RS232 This slot is to connect with D-Sub 9pin cable from the PC/NB device for RS-232 control. SERVICE This slot is to connect with USB cable for manufacturers’ firmware update only. Mini-DisplayPort IN This slot is where you connect the MiniDisplayPort source output for DisplayPort signal sending. -
Page 9: Osd Menu And Function List
7.OSD MENU AND FUNCTION LIST Main Menu 2nd Layer Input Video COMP Exit Input Audio AUDIO Optical Mute Exit Output Resolution 720x480P 1280x720P 1920x1080P 640x480 800x600 1024x768 1280x1024 1600x1200 1920x1200RB By Native Exit... -
Page 10: Remote Control
Main Menu 2nd Layer 3rd Layer Misc. Setup EDID Mode Internal / External / Exit Info. OSD Mode Off / On / Exit About CS-802D FW Ver. Factory Reset System Reset Exit Exit 8. REMOTE CONTROL Power Press to select DV MDP/PC/... -
Page 11: Rs-232 Protocols
▲/▼ Press up/down buttons to select OSD selection. Native Press to switch to Native resolution. 8.1 RS-232 Protocols RS-232 modem cable. Pins definition of modem cable CS-802D Remote Controller Definition Definition → ← Baud Rate: 19200 bps Data Bit: 8 bits... -
Page 12: Rs-232 Commands
8.2 RS-232 Commands User Command Code Description POWER ? Power Status POWER ON Power On POWER OFF Power Off VIDEO ? Video Input Source Video Input in DVI Video Input in Mini-DisplayPort Video Input in PC COMP Video Input in Component AUDIO ? Audio Input Source AUDIO... - Page 13 FEEDBACK OFF Key Feedback Disable STATE ? Video Input Signal Status VERSION ? Firmware Version DEFAULT Reset to Factory Default About ? About CS-802D Note: Any commands will not be executed unless followed by a carriage return. Commands are not case-sensitive.
-
Page 14: Connection And Installation
9. CONNECTION AND INSTALLATION HD TV Amplifier D-Sub15pin Optical HDMI RS232 OPTICAL AUDIO HDMI OUT POWER DC 5V MENU/ Dual-Link DVI PC/COMP ENTER SERVICE OPTICAL AUDIO 720P Optical 3.5Ø audio MAC PC Dell PC... -
Page 15: Specifications
10. SPECIFICATIONS DP Input Frequency 2.7Gbps & 1.62Gbps/Lane Bandwidth Input Port 1 x Dual-Link DVI (Female type), 1 x Mini-DisplayPort, 1 x PC/COMP Audio Input Port 1 x L/R, 1xOptical Output Port 1 x HDMI, 1 x L/R, 1 x Optical Power Supply 5V DC/ 2.6A (US/EU standards, CE/FCC/ UL certified) -
Page 16: Pc, Hdmi, Dp Input Timing
10.1 PC, HDMI, DP Input Timing COMP Input Resolution Input Resolution 640*350@85 ˇ ˇ ˇ 640*400@85 ˇ ˇ ˇ 720*400@85 ˇ ˇ ˇ VGA640*480@60/72/ ˇ ˇ ˇ 75/85 SVGA800*600@56/60/ ˇ ˇ ˇ 72/75/85/120R 848*480@60Hz ˇ ˇ ˇ XGA1024*768@43i/60/ ˇ ˇ 75/85/120R XGA+1152*864@75 ˇ... - Page 17 UXGA1600*1200@60/ ˇ@60 only ˇ ˇ 65/70/75/85/120R WSXGA1680*1050@60/ ˇ@60CVT/ ˇ ˇ 60R/75/85/120R 60 only 1792*1366@60/75 ˇ ˇ 1856*1392@60/75 ˇ ˇ 1920*1080@60 ˇ ˇ ˇ 1920*1200 ˇ@60R ˇ ˇ only (@60R/60/75Hz) 1920*1440@60 ˇ 720*480I/P ˇ 720*576I/P ˇ 720I/P@24/25/30/50/60 ˇ 1080I@50/60 ˇ 1080P@24 ˇ...
-
Page 18: Output Resolution
10.2 Output Resolution 640*480 800*600 1024*768 1280*1024 1600*1200 1920*1200@60RB 720*480P 1280*720P(Default) 1920*1080P Note: When output timing is set to 'By Native' yet the timing does not match the built-in support timing,output timing will set to defualt at 1280*720p automatically. -
Page 19: Acronyms
11. ACRONYMS ACRONYM COMPLETE TERM HDMI High-Definition Multimedia Interface... - Page 20 CYPRESS TECHNOLOGY CO., LTD Home page: http://www.cypress.com.tw 20121217 MPM-CS802D...
