- Page 1 RPC-0801-910 8” Multi-functional Touch Panel PC Quick Reference Guide Ed – 19 March 2010 Copyright Notice Copyright © 2010 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E20177630A0R...
- Page 2 CORRECT THE INTERFERENCE AT HIS OWN EXPENSE. Copyright Notice Copyright © 20010 Avalue Technology Inc., ALL RIGHTS RESERVED. No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer.
-
Page 3: Table Of Contents
Rear View............................. 7 1.4.2 Right View ............................ 7 System Dimensions....................8 1.5.1 RPC-0801-910 ..........................8 Hardware Configuration.....................9 Jumper and Connector Setting, Driver and BIOS Installing........9 Installing SD card ....................10 Mode setting for RSC-W910 (only for boot loader update)........11 RPC-0801-910 Quick Reference Guide... -
Page 4: Getting Started
1 x Quick Reference Guide 1 x CD/ DVD-ROM contains the followings: — User’s Manual (this manual in PDF file) — WinCE5.0/6.0 BSP,SDK and utilities — Linux BSP and utilities 1 x Power Adapter 4 x screws for VESA 4 RPC-0801-910 Quick Reference Guide... -
Page 5: System Specifications
Board RSC-W910 Onboard Nuvoton NUC910ABN 200 MHz NAND/NOR Flash Boot loader Onboard 64MB SDRAM, Optional 128MB Memory Flash Onboard 128MB, Optional 512MB Watchdog Timer Interrupt 0.28/1.12/4.47/17.9sec. System Memory Onboard 64MB SDRAM, Optional 128MB SD or SDHC RPC-0801-910 Quick Reference Guide... - Page 6 +12V DC Input Operating Temperature 0°C to 60°C. Relative Humidity 0% to 90% relative humidity, non-condensing Mounting Wall/Stand/VESA 75 mm X 75 mm 202 mm X 159 mm X 42.5 mm Dimensions 1.07 Kgs Weight 6 RPC-0801-910 Quick Reference Guide...
-
Page 7: System Overview
Debug message output COM0 COM1 Serial port 1 DB-9 male connector +12V DC-in power connector DC-in Ethernet connector RJ-45 Power switch Power Mini USB USB client connector Mini USB connector 2 x USB 2.0 connector Dual USB decks RPC-0801-910 Quick Reference Guide... -
