- Page 1 FPC-10W09 10" Intel® Atom™ WSVGA TFT Touch Panel PC Quick Reference Guide Ed – 21 June, 2016 Copyright Notice Copyright © 2016 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E2017F090A0R...
- Page 2 Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
- Page 3 Applications that are described in this manual are for illustration purposes only. Avalue Technology Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification.
-
Page 4: Table Of Contents
System Specifications ................... 6 System Overview ....................8 1.4.1 Rear View ............................. 8 System Dimensions ....................9 Hardware Configuration ................... 10 FPC-10W09 connector setting ................11 2.1.1 Serial Port connector (COM) ...................... 11 Installing Hard Disk ....................12 4 FPC-10W09 Quick Reference Guide... -
Page 5: Getting Started
Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis. 1.2 Packing List 1 x FPC-10W09 Panel PC 1 x CD/DVD-ROM contains the followings: ... -
Page 6: System Specifications
1 x COM D-sub 9 pin USB Port 1 x USB 3.0, 4 x USB 2.0 Video Port 1 x VGA HDMI Port 1 x HDMI LAN Port 2 x RJ-45 Intel® I211AT Switch 1 x Power switch 6 FPC-10W09 Quick Reference Guide... - Page 7 With CF/SSD : 10Grms, IEC 60068-2-27, Half Sine, 11ms Test Operating 0°C ~ 40°C Temperature Operating Humidity 10% to 95% @ 40°C, Non-condensing Storage -10°C ~ 50°C Temperature Note: Specifications are subject to change without notice. FPC-10W09 Quick Reference Guide...
-
Page 8: System Overview
DB-9 male connector DC IN DC-in power connector HDD LED 2 x RJ-45 Ethernet connector POWER S/W Power switch Power LED 4 x USB 2.0 connector 1 x USB 3.0 connector HDMI HDMI connector VGA connector 8 FPC-10W09 Quick Reference Guide... -
Page 9: System Dimensions
Quick Reference Guide 1.5 System Dimensions 電鍍 陽極 液烤漆 粉烤漆 材質 表面處理 鐵件 鋁件 塑膠件 扭拉力 ≦0.015 ≦0.2 ≦0.3 膜厚 (mm) ≦0.007 扭力值 (kgf/cm) 拉力值 (kgf) 攻牙( *4)(Max. DP=3.5) (Unit: mm) FPC-10W09 Quick Reference Guide FPC-10W09 ID_20160616 PART No. TASK DWG No. -
Page 10: Hardware Configuration
FPC-10W09 2. Hardware Configuration Please refer to ECM-BYT User’s Manual for further information. Note: If you need more information, please visit our website: http://www.avalue.com.tw 10 FPC-10W09 Quick Reference Guide... -
Page 11: Fpc-10W09 Connector Setting
Quick Reference Guide 2.1 FPC-10W09 connector setting 2.1.1 Serial Port connector (COM) Signal Signal NDCD# NDSR# NRXD NRTS# NTXD NCTS# NDTR# NRI# FPC-10W09 Quick Reference Guide 11... -
Page 12: Installing Hard Disk
FPC-10W09 2.2 Installing Hard Disk Step 1. Unfasten 10 screws from the case to take off the top chassis. 12 FPC-10W09 Quick Reference Guide... - Page 13 Quick Reference Guide Step 2. Insert the HDD into the bracket and fasten 4 screws. Step 3. Insert the HDD back and fasten 4 screws. FPC-10W09 Quick Reference Guide 13...
- Page 14 FPC-10W09 Step 4. Place back the chassis with 10 screws locked. 14 FPC-10W09 Quick Reference Guide...
