- Page 1 Medi-View AID-185 18.5" Intel® ATOM™ Z3735F Processor Touch Panel PC Quick Reference Guide Ed – 19 August 2020 Copyright Notice Copyright 2020 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E2017A8C0A0R...
-
Page 2: Table Of Contents
5.2 Safety information ....................19 5.3 Environmental information ..................22 5.4 Regulatory compliance information ................24 5.5 Explanation of symbols..................... 24 5.6 Legal disclaimer ....................... 25 5.7 Technical specifications.................... 26 5.8 System Dimensions ....................28 2 Medi-View AID-185 Quick Reference Guide... -
Page 3: Getting Started
Quick Reference Guide 1. Getting Started Medi-View AID-185 Quick Reference Guide 3... -
Page 4: About The Product
1.1 About the product The Medi-View AID-185 is a multimedia Intel® processor-based computer that is designed to serve as a Point of Care (POC) and Point of Information terminal (POI) within healthcare applications. It is a PC based system with 18.5"... -
Page 5: Parts, Controls And Connectors
Quick Reference Guide 2. PARTS, CONTROLS AND CONNECTORS Medi-View AID-185 Quick Reference Guide 5... -
Page 6: System Setup
Front When you place the Medi-View upright on the desktop, its front panel appears as shown in the figure below. Image 2-1 Front view of the Medi-View AID-185 Webcam Contact Card Reader Multimedia Handset (2D BCS Optional) - Page 7 Quick Reference Guide Left and Right Image 2-2 Left and Right side view of the Medi-View AID-185 Bottom Image 2-3 Bottom view of the Medi-View AID-185 I/O area bottom Contact Card Reader Reset button USB 2.0 (2x) Audio Jack (2x)
- Page 8 Medi-View AID-185 Rear Image 2-4 Rear view of the Medi-View AID-185 Simple grab handle 2D BCS (Optional) I/O inside the cover * The access doors may only be opened by qualified service personal, no AUTION user serviceable parts inside. * The grab handle is designed at user’s convenience to move the Medi-View AUTION around, DO NOT use it for any other purposes, ex.
- Page 9 Quick Reference Guide Label Medi-View AID-185 Quick Reference Guide 9...
- Page 10 End Call Integrated Help Home Return Left Arrow Right Arrow Up Arrow Down Arrow View Toggle Back Channel Up Mute Channel Down Volume Up Volume Down Scan Next Track Scan Previous Track Play/ Pause 10 Medi-View AID-185 Quick Reference Guide...
- Page 11 “Dial” icon. 2. To end a phone conversation, press the “Hang Up” icon. 3. Use the volume control to adjust the volume of the handset. Note: Phone application software and Internet connection are required. Medi-View AID-185 Quick Reference Guide 11...
-
Page 12: System Installation
Medi-View AID-185 SYSTEM INSTALLATION 12 Medi-View AID-185 Quick Reference Guide... -
Page 13: Vesa Mounting (For Vesa Sku)
Installation instructions follow: 1. First attach the wall-mounting to the heat-sink of the Medi-View AID-185, securing it in place with four of the M4 x 6mm screws provided. 2. Mount the system on the wall, stand or other flat surface. -
Page 14: Installation Of Hdd, Ssd (Optional)
After installing the system software, you will be able to install the necessary drivers. The drivers and utilities used for the Medi-View are subject to change without notice. If in doubt, check with our application engineers for the latest information regarding drivers and utilities. 14 Medi-View AID-185 Quick Reference Guide... -
Page 15: System Operation
Quick Reference Guide 4. SYSTEM OPERATION Medi-View AID-185 Quick Reference Guide 15... -
Page 16: Frequently Used Functions
. The system reset itself. I/O recess Shut down: 1. Enter the OS, select shutdown and the system will shut down. 4.3 The LED color definition Green: Back light powered on. Orange: Back light powered off (Stand-by mode). 16 Medi-View AID-185 Quick Reference Guide... -
Page 17: Important Information
Quick Reference Guide 5. IMPORTANT INFORMATION Medi-View AID-185 Quick Reference Guide 17... -
Page 18: Cleaning Agents Tested
5.1 Cleaning agents tested. The Medi-View AID-185 is designed to be easily cleaned and can use the same standard cleaning solutions used by the hospitals to clean other IT Equipment. When using a cloth or similar please ensure that the cloth i s damp / moist and not overly wet, and avoid applying pressure when cleaning the LCD. -
Page 19: Safety Information
Dropping the equipment is likely to cause serious injury to a child or adult, and serious damage to the equipment. • Improper installation of VESA mounting can result in serious personal injury! Use a VESA mounting Medi-View AID-185 Quick Reference Guide 19... - Page 20 Equipment primarily for use in a health care facility that is intended for use where contact with a patient is unlikely (no applied part). • The equipment may not be used with life support equipment. • The user is not supposed to touch SIP/SOPs and the patient at the same time. 20 Medi-View AID-185 Quick Reference Guide...
- Page 21 Do not cover or block any ventilation openings in the cover of the set. When installing the device in a cupboard or another closed location, heed the necessary space between the set and the sides of the cupboard. This apparatus conforms to: ANSI/AAMI ES 60601-1:2005; CAN/CSA-C22.2 No.60601-1:08; FCC-Class A; CE Medi-View AID-185 Quick Reference Guide 21...
-
Page 22: Environmental Information
有 毒 有 害 物 质 或 元 素 Component name Hazardous substances and elements 铅 六价 铬 镉 多 溴 二 苯 汞 多溴联苯 醚 Cr6+ PBDE 印 制 电 路 配 件 Printed Circuit Assemblies 22 Medi-View AID-185 Quick Reference Guide... - Page 23 Friendly Use Period (EFUP) logo. The number inside the EFUP logo that Remedi uses (please refer to the photo) is based on the “Standard of Electronic Information Products Environmental Friendly Use Period” of Chinese Mainland. Medi-View AID-185 Quick Reference Guide 23...
-
Page 24: Regulatory Compliance Information
European WEEE (Waste Electrical and Electronic Equipment) directive Symbols on the box On the box of the device, you may find the following symbols (nonrestrictive list): 5. Values for xx and yy can be found in the technical specifications paragraph. 24 Medi-View AID-185 Quick Reference Guide... -
Page 25: Legal Disclaimer
- graphical, electronic, or mechanical including photocopying, taping or information storage and retrieval systems - without written permission of Remedi. 6. Values for xx and yy can be found in the technical specifications paragrap Medi-View AID-185 Quick Reference Guide 25... -
Page 26: Technical Specifications
Medi-View AID-185 5.7 Technical specifications Technical specifications for the Medi-View AID-185 Component Mother Board AID-156 Mother board (BCX30) Onboard Intel® Atom™ Processor Z3735F CPU Cooler (Type) Passive cooling Memory 2GB DDR3L on board Power Supply 14~26V DC input Adapter AC/DC adapter 19V/4.73A... - Page 27 4 Test drawing Operating 0°C ~ 40°C (32°F ~ 104°F) Temperature Operating Humidity 0% ~ 90% Relative Humidity, Non-Condensing Storage -10°C ~ 60°C (14°F ~ 140°F) Temperature Note: Specifications are subject to change without notice. Medi-View AID-185 Quick Reference Guide 27...
-
Page 28: System Dimensions
Medi-View AID-185 5.8 System Dimensions Unit: mm 28 Medi-View AID-185 Quick Reference Guide...
