Page 2
Federal Communication Commission Interference Statement THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
Page 3
FCC RF Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible.
Page 4
WARNING “WARNING: Users must not allow SIP/SOPs and the patient to come into contact at the same time.” “CAUTION – Use suitable mounting apparatus to avoid risk of injury.” “CAUTION - Grounding reliability can only be achieved when the equipment is connected to an equivalent receptacle marked “Hospital Only”...
Page 5
Statement Accessory equipment connected to the analog and digital interfaces must be in compliance with the respective nationally harmonized IEC standards (i.e. IEC 60950 for data processing equipment, IEC 60065 for video equipment, IEC 61010-1 for laboratory equipment, and IEC 60601-1 for medical equipment.) Furthermore all configurations shall comply with the system standard IEC 60601-1-1.
Page 6
Intended Use AID-173 Series Medical PC is intended to be used for displaying information and providing interactive services by doctors, nurses, patients, and staff in the hospitals. It shall not be used for diagnosis purpose and shall not be used for life supporting system. Cleaning Materials Lint-free cloth, microfiber cloth, damp cloth...
Page 7
Explanation of Graphic Symbols WARNING: dangerous voltage. Attention, consult ACCOMPANYING DOCUMENTS. Follow operating instructions or Consult instructions for use. STAND-BY (Orange Light) Direct current. UL Mark Authentication sign of Standard Inspection Bureau for U.S.A Complies with ANSI/AAMI ES60601-1 and CSA C22.2 No.
Page 8
Troubleshooting No Power LED Indicator Check if power cord and adapter is plugged. Power Button Not Working Check the certified technician Brightness Buttons Not Working Check if the MAX or MIN level is reached. Volume Buttons Not Working Check if the MAX or MIN level is reached. Check audio setting in the operating system.
Page 9
Disposing of Your Old Product WEEE Mark (European Directive 2002/96/EC) Within the European Union EU-wide legislation, as implemented in each Member State, requires that waste electrical and electronic products carrying the mark (left) must be disposed of separately from normal household waste. This includes monitors and electrical accessories, such as signal cables or power cords.
Page 10
System and Adapter Specifications System Specifications Display 17.3” TFT-LCD 1920x1080 LED Backlight Touch Screen 5-Wire Resistive Touch Panel Processor Intel 2 Generation Core i7-2610UE1.5GHz/2340UE 1.3GHz/Celeron1.4GHz Chipset Intel QM67 Memory 2~16GB DDR3 1066/1333MHz SODIMM Storage 2.5” SATA HDD/SSD Expansion 1 x USB mini Card Socket 3 x mini-PCIe Card Sockets Rating 19V 3.15A...
Page 11
EMC Table Guidance and manufacturer’s declaration – electromagnetic emissions The model AID-173SHR is intended for use in the electromagnetic environment specified below. The customer or the user of the model AID-173SHR should assure that it is used in such an environment.
Page 12
Guidance and manufacturer’s declaration – electromagnetic immunity The model AID-173SHR is intended for use in the electromagnetic environment specified below. The customer or the user of the model AID-173SHR should assure that it is used in such an environment. Immunity test...
Page 13
Guidance and manufacturer’s declaration – electromagnetic immunity The model AID-173SHR is intended for use in the electromagnetic environment specified below. The customer or the user of the model AID-173SHR should assure that it is used in such an environment. IEC 60601...
Page 14
RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the model AID-173SHR is used exceeds the applicable RF compliance level above, the model AID-173SHR should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as reorienting or relocating the model AID-173SHR.
AID-173SHR Quick Reference Guide 1. AID-173SHR Bedside Terminals Features ▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬ In this chapter, you will learn all of the features of AID-173SHR bedside terminals. 1.1 Front Look 1.2 Rear & Bottom Look 1.3 Handset AID-173S Quick Reference Guide...
AID-173SHR Quick Reference Guide 1.2 Rear & Bottom Look DP Output TV Antenna Input (optional) USB Port DC in HDMI Output Service Door Speaker Speaker Microphone BNC Video Input (Optional) COM2 COM1 Nursing Call Input AID-173S Quick Reference Guide...
AID-173SHR Quick Reference Guide 2. Setting Up AID-173SHR Bedside Terminals ▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬ In this chapter, you will learn how to set up AID-173SHR bedside terminal hardware and cable connection. Finally, with Internet ISP setting information, you will be able to connect AID-173SHR bedside terminal to the Internet.
AID-173SHR Quick Reference Guide 2.2 Cabling 1. Power Cable 2. Ethernet (RJ-45) Cable (Optional) 3. TV (Coaxial) Cable (Optional) Coaxial connector Ethernet (RJ-45) Power Jack Connector Please follow below steps to connect the power cable and the system. AID-173S Quick Reference Guide...
AID-173SHR Quick Reference Guide 2.3 System Activation & Registration 1. When you first receive the system, a system activation and software registration might be performed before the use of this system. 2. Please consult your local service providers for more details.
AID-173SHR Quick Reference Guide 2.4 Connecting to the Internet 1. Use built-in wireless LAN to connect to the Internet. 2. Use Ethernet (RJ-45) to connect to the Internet. 3. Consult your Internet Service Provider (ISP) for software settings. Note: ISP, IP, (wireless) router, Access Point, DSL modem, Access ID &...
AID-173SHR Quick Reference Guide 3. Using AID-173SHR Bedside Terminals ▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬ In this chapter, you will learn how to use all the features of AID-173SHR bedside terminal. Turn ON/OFF the System 3.2 Using LCD Display and Touch Screen 3.3 Using Ear Phone and Microphone 3.4 Using Smart Card Reader...
AID-173SHR Quick Reference Guide 3.1. Turn ON/OFF the System ON/OFF Touch Button 3.1.1 Turn ON the System 1. Check if the led on the Power ON/OFF icon is red. 2. Move your finger on the top of the Power ON/OFF icon.
AID-173SHR Quick Reference Guide 3.2 Using LCD Display and Touch Screen Control Buttons 3.2.1 Adjust System Volume 1. Move your finger on the top of the Volume Up or Volume Down icon. 2. The volume will be adjusted accordingly. 3.2.2 Adjust LCD Display Brightness 1.
AID-173SHR Quick Reference Guide Using Earphone and Microphone 1. Open the rubber cover on the right side of the system. 2. Insert the earphone phone or microphone into the jacks. AID-173S Quick Reference Guide...
AID-173SHR Quick Reference Guide 3.4 Using the Smart Card Reader 1. Have the IC card face up. 2. Insert the IC card into the Smart Card Reader slot. AID-173S Quick Reference Guide...
AID-173SHR Quick Reference Guide 3.5 Using Magnetic Stripe Reader 1. Have your card with the magnetic stripe facing outside. 2. Slide the card from top to the bottom. AID-173S Quick Reference Guide...
AID-173SHR Quick Reference Guide 3.6 Using RFID Reader/Writer 1. Attach the card to the RFID Reader/Writer. Keep card close to the reader no greater than 5cm. 2. The RFID will beep if the card is read or written successfully. Note: The RFID Reader/Writer accepts ISO 14443A standard cards ONLY.
AID-173SHR Quick Reference Guide 3.7 Using Handset Take the Handset 1. When you want to use the handset, lift the handset from the cradle. 2. Replace the handset back to the handset cradle with keypad facing inside. AID-173S Quick Reference Guide...
Page 33
AID-173SHR Quick Reference Guide Start and End a Phone Conversation 1. To make a phone call, enter the numbers by press the number on the keypad and press “Dial” icon. 2. To end a phone conversation, press the “Hang Up” icon.
AID-173SHR Quick Reference Guide 3.8 Using Barcode Scanner 1. Take the handset and turn it over. 2. Aim the barcode and maintain an appropriate distance between and barcode and scanner. 3. Press SCAN button. The Barcode Scanner will “Beep” when the barcode is successfully read.
Page 35
AID-173SHR Quick Reference Guide 3.9 Moving the Terminal 1. Use your hand to hold the handle. 2. Pull or push to move the terminal towards the direction you want. Note: Make sure the terminal is fixed firmly via wall mount or other device to prevent injury by sudden fall of the terminal.
AID-173SHR Quick Reference Guide 4. Upgrading AID-173S Bedside Terminals ▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬ In this chapter, you will learn several peripherals upgrade or replacement. Please perform these steps with care. ▲ WARNING: Turn OFF the system and disconnect the power cable before performing the following tasks.
AID-173SHR Quick Reference Guide 4.1 Adding/Removing/Replacing Memory 1. Remove the two screws from the service door. 2. Open the service door. 1. Push the two latches of the retaining clips away from the memory module. 2. The memory module will pop up at an angle.
AID-173SHR Quick Reference Guide 4.2 Removing and Replacing the Wireless Card 1. Remove the two screws from the service door. 2. Open the service door. 1. Unplug the two antennas from the wireless module. 2. Unlock the mini-PCIe socket. 3. Pull the wireless module out of the socket.
AID-173SHR Quick Reference Guide 4.3 Adding 3rd Party Mini-PCIe Cards 1. Remove the two screws from the service door. 2. Open the service door. 1. Insert the 3 party mini-PCIe card into the empty mini-PCIe expansion socket. 2. Lock the mini-PCIe socket.
AID-173SHR Quick Reference Guide 4.4 Removing and Replacing the Hard Disk Drive 1. Remove the two screws from the service door. 2. Open the service door. 1. Remove the two top screws from the hard bracket from the hard disk cage.
Page 41
AID-173SHR Quick Reference Guide 1. Insert the two screws on the bracket. 2. Place the hard disk drive into the cage. 3. Insert two screws on the bracket and the cage. 4. Connect the power and data cable to the hard disk drive.
Page 42
AID-173SHR Quick Reference Guide Thank you for purchasing and using AID-173SHR Bedside Terminals. We hope you have a joyful experience with our products and services. Avalue Technology Address: 7F, 228, Lian-cheng Road, Zhonghe Dist., New Taipei City 235, Taiwan Tel: +886-2-8226-2345...
