- Page 1 RITY153 15” XGA Flat Touch Panel PC Intel® Atom™ Processor with Intel® Valleyview SoC Quick Reference Guide Ed – 19 February 2019 Copyright Notice Copyright 2019 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E2017RT53A0R...
- Page 2 These answers are normally a lot more detailed than the ones we can give over the phone. So please consult the user’s manual first. To receive the latest version of the user’s manual; please visit our Web site at: http://www.avalue.com.tw/ 2 RITY153 Quick Reference Guide...
-
Page 3: Table Of Contents
1.5 System Dimensions ....................10 1.6 Stand Dimensions ....................11 1.7 Panel + Stand Dimensions ..................13 Hardware Configuration ..................15 2.1 RITY153 connector mapping .................. 16 2.1.1 External Serial Port 1 connector (COM1) ................16 2.1.2 External Serial Port 2 connector (COM2) ................17 2.1.3... -
Page 4: Getting Started
1.2 Packing List 1 x RITY Series Panel PC 1 x Power Adapter 1 x Power Cord 1 x Stand (option) 4 RITY153 Quick Reference Guide... -
Page 5: System Specifications
All Pin 9 supported 5V/12V 1A max output, selected by BIOS. Serial Port COM1 & 2: RS232/422/485 selected in BIOS, RS422/485 by standard. COM3 Pin header COM4 Pin header 10 x USB ports supported USB Port Internal x6 1 x USB 2.0 for resistive touch controller RITY153 Quick Reference Guide... - Page 6 All design for this project have to comply with UL / CB / CCC Dust and Rain IP 65 for front panel, IP 41 for back Test Follow Avalue standard: Vibration Test Ramdom Vibration Operation 6 RITY153 Quick Reference Guide...
- Page 7 Reference ISTA 2A, Method : IEC-60068-2-32 Test:Ed Test Ea : Drop Test Drop Test 1 Test phase : One corner, three edges, six faces 2 Test high : 3 Package weight : 4 Test drawing Operating 0°C ~ 40°C RITY153 Quick Reference Guide...
- Page 8 RITY153 Temperature Operating 12hrs operation dwell time at 40°C/80% Relative Humidity, Non-condensing Humidity Storage 0°C ~ 60°C Temperature Note: Specifications are subject to change without notice. 8 RITY153 Quick Reference Guide...
-
Page 9: System Overview
External Serial Port 3 connector (For RS-232) VGA connector Cash Drawer connector 4 x USB 3.0 connector 1 x USB 2.0 connector 2 x RJ-45 Ethernet connector HDMI connector HDMI DC-IN DC Power-in connector DC Power-out connector BATTERY RITY153 Quick Reference Guide... -
Page 10: System Dimensions
RITY153 1.5 System Dimensions (Unit: mm) 10 RITY153 Quick Reference Guide... -
Page 11: Stand Dimensions
Quick Reference Guide 1.6 Stand Dimensions (Unit: mm) RITY153 Quick Reference Guide 11... - Page 12 RITY153 12 RITY153 Quick Reference Guide...
-
Page 13: Panel + Stand Dimensions
Quick Reference Guide 1.7 Panel + Stand Dimensions (Unit: mm) RITY153 Quick Reference Guide 13... - Page 14 RITY153 14 RITY153 Quick Reference Guide...
-
Page 15: Hardware Configuration
Quick Reference Guide 2. Hardware Configuration Note: If you need more information, please visit our website: http://www.avalue.com.tw RITY153 Quick Reference Guide 15... -
Page 16: Rity153 Connector Mapping
External Serial Port 1 connector (COM1) In RS-232 Mode Signal Signal DCDA# DSRA# RXDA RTSA# TXDA CTSA# DTRA# RIA# In RS-422 Mode Signal Signal TxD1- TxD1+ RxD1+ RxD1- In RS-485 Mode Signal Signal DATA1- DATA1+ 16 RITY153 Quick Reference Guide... -
Page 17: External Serial Port 2 Connector (Com2)
External Serial Port 2 connector (COM2) In RS-232 Mode Signal Signal DCDB# DSRB# RXDB RTSB# TXDB CTSB# DTRB# RIB# In RS-422 Mode Signal Signal TxD1- TxD1+ RxD1+ RxD1- In RS-485 Mode Signal Signal DATA1- DATA1+ RITY153 Quick Reference Guide 17... -
Page 18: External Serial Port 3 Connector (Com3)
RITY153 2.1.3 External Serial Port 3 connector (COM3) Signal Signal 2.1.4 VGA connector (VGA) Signal PIN Signal PIN Signal +12V GREED DATA BLUE HSYNC +12V VSYNC 18 RITY153 Quick Reference Guide... -
Page 19: Installing Battery(Optional)
Step 1. Put the Battery into the battery holder and fasten 4 screws. Step 2. Insert and fasten 2 screws to secure battery chassis. Note: Battery is optional. During abnormal power outage, the system will activate the reserve battery power for 10-15 minutes to avoid disk shutdown. RITY153 Quick Reference Guide 19...
