4
BASIC OPERATION

Monitor function

This function is used to listen to weak signals or to open the
tone squelch manually.
Push and hold [SQL] to monitor the operating frequency.
• "RX" flashes while monitoring.
The [SQL] switch can be set to 'sticky' operation in set
mode. (p. 41)
You can monitor duplex communication by pushing the
[SQL] switch when the duplex function is in use. (p. 31)
12
FM
146.100.000
TS 15.0
S1 3 5 7 9
RX
VOL
FM
RX

Receive mode selection

Receive modes are determined by the physical properties of
the radio signals. The receiver has 3 receive modes: FM, AM
and WFM modes. TV and ATV (ATV type only) also use WFM
mode. The mode selection is stored independently in each
band and memory channels.
Typically, AM mode is used for the AM broadcast stations
(0.495–1.620 MHz) and air band (118–135.995 MHz), and
WFM is used for FM broadcast stations (76–107.9 MHz).
Push [MODE] one or more times to select the desired re-
ceive mode.
FM AM
146.010.000 118.000.000
TS 15.0 TS
S1 3 5 7 9 S1 3
VOL VOL
FM AM
FM mode AM mode
WFM
76.000.000
25.0 TS 50.0
5 7 9 S1 3 5 7 9
VOL
W FM
WFM mode
