Icom IC-V85 Instruction Manual page 66

11
SET MODES
D D Squelch delay
Selects squelch delay from short and long to prevent re-
peated opening and closing of the squelch during reception
of the same signal.
• Sqt. S : The squelch closes in short delay. (default)
• Sqt. L : The squelch closes in long delay.
D D DTMF rate
The rate at which DTMF memories send individual DTMF
characters can be set to accommodate operating needs.
• 1: 100 msec. interval; 5.0 cps rate (default)
• 2: 200 msec. interval; 2.5 cps rate
• 3: 300 msec. interval; 1.6 cps rate
• 5: 500 msec. interval; 1.0 cps rate
53
D D Dial assignment
Selects [VOL] control action from volume and tuning dial.
• tOP.VO: AF volume (default)
• tOP.dI : Tuning dial
D D Display type
Selects LCD indication type from frequency, channel number
and channel names.
• dSP.FR : Shows frequency (default)
• dSP.CH : Shows channel number*
• dSP.nm : Shows channel names
*Only memory channels can be selected.
†
(cps=characters/sec.)
Frequency indication will be displayed when the selected memory
channel has no programmed memory name.
NOTE: When this setting is selected other than "FR" ("CH"
or "nm") and accessing
SET MODE
most of set mode items are restricted.
†
from memory mode,
