INSTRUCTION MANUAL
FM TRANSCEIVER
iV85
iV85E
iV85-T
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.

Advertisement

loading
Need help?

Need help?

Do you have a question about the IC-V85E and is the answer not in the manual?

Questions and answers

Related Manuals for Icom IC-V85E

Summary of Contents for Icom IC-V85E

  • Page 1 INSTRUCTION MANUAL FM TRANSCEIVER iV85 iV85E iV85-T This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 2 ❍ CTCSS and DTCS encoder/decoder stand- ❍ Optional DTMF decoder Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the United Kingdom, Germany, France, Spain, Russia and/or other countries.
  • Page 3 PRECAUTIONS RWARNING RF EXPOSURE! RWARNING! NEVER This device emits connect the transceiver to an Radio Frequency (RF) energy. Extreme caution should be ob- AC outlet. This may pose a fire hazard or result in an electric served when operating this device. If you have any questions shock.
  • Page 4 Otherwise, the battery pack (Li-ion: BP-227) or installed batteries will be- come exhausted. For USA only: Caution: Changes or modifications to this transceiver, not expressly approved by Icom Inc., could void your authority to operate this transceiver under FCC regulations.
  • Page 5 OPTION LIST • BP-226 • HM-75A/HM-131L/HM-158L battery case speaker microphones × Battery case for 5 AA (LR6) size alkaline batteries. Combination speaker-microphones that provide convenient operation while hanging the transceiver from your belt. • BP-227 ion battery pack HM-75A has 4 function switches for remote control capabilities. 7.4 V, 1850 mAh (minimum)/1950 mAh (typical) Lithium-ion HM-131L/HM-158L are equipp ed with an earphone jack and battery pack.
  • Page 6 TABLE OF CONTENTS 4 BASIC OPERATION ���������������������������������������������� 17–21 FOREWORD ................ i IMPORTANT ................. i ■ Power ON ..............17 EXPLICIT DEFINITIONS ............i ■ VFO mode selection ..........17 PRECAUTIONS .............. ii–iii ■ Setting a frequency ..........17 SUPPLIED ACCESSORIES ..........iii ■...
  • Page 7 11 SET MODES ���������������������������������������������������������� 47–56 ■ Memory bank selection ..........30 ■ SET MODE .............. 47 ■ Memory bank setting ..........30 ■ Transferring bank contents ........31 ■ INITIAL SET MODE ..........51 12 SET MODE INSPECTION ������������������������������������� 57–58 7 DTMF MEMORY ����������������������������������������������������...
  • Page 8 QUICK REFERENCE GUIDE ■ Preparation D Antenna D Battery pack replacement Before replacing the battery pack, push and hold [PWR] for Attach the antenna to the trans- ceiver as illustrated at right. 1 sec. to turn the power OFF. • To attach the battery pack Slide the battery pack on the back of the transceiver in the direction of the arrow (q), then lock it with the battery re- lease button.
  • Page 9 QUICK REFERENCE GUIDE BP-226 Latch D Battery case— optional for some versions Fig.1 When using a BP-226 attached to the trans- battery case ceiver, install 5 AA (LR6) size alkaline batteries as illustrated at right. q Hook your finger under the latch, and open the cover in the direction of the arrow (q).
  • Page 10 QUICK REFERENCE GUIDE D Regular charging When using a BP-227 attached to the trans- battery pack ceiver, prior to using the transceiver for the first time, the bat- tery pack must be fully charged for optimum life and Transceiver operation. D Charging note •...
  • Page 11 #23 UK ■ ■ ■ ■ ■ ■ ■ ■ ■ GBR ■ ■ ■ ■ ■ ■ ■ ■ A-6552D-1EX- Printed in Japan 2006–2012 Icom Inc. © 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan Printed on recycled paper with soy ink.
