<PRESET> menu
This menu can be entered by scrolling selector, or pushing at the same time both quick
channel setup buttons (<ch> & <gain>).
The other 8 configuration presets are user programmable thru the infrared and the
PC interface (using the programmer UPK 300 or the receiver MRK950/MRK960).
All parameters can be "left unchanged", "changed" or "changed and lock",
allowing a very flexible way to pre-program MTP40 configuration.
<TUNING> menu
This menu can be entered by scrolling selector or using quick channel setup buttons (<ch>).
<AUDIO> menu
This menu can be entered by scrolling selector or using quick gain setup buttons (<gain>).
MTP40 User Manual
MTP40 can recall configuration presets. "FACTORY" recall
the Wisycom factory configuration. "USER" recall the
user configuration (the transmitter configuration is
copied into the USER using the "save to" submenu). All
"USER" menus are not locked by default,
thus this is quick way to unlock features!
In this menu current channel/group and frequencies can
be setup. Use the selector to change values (<+/->) and
<click> to confirm.
Sync group is a quick self-settable channel synchronized
by receiver.
"AF In Gain" setup to tune audio input sensitivity:
To help proper audio gain setting, an audio
bar is supplied with peak hold bar)
indicating the headroom to audio peak
(0 dB).
AF gain is shown with 2 different unit of
measurements dB (gain in dB of MTP40 amplifiers) or
in dBu peak.
"HighPass Filter" applies different audio HP filter:
Flat / 60Hz / 120Hz / 170Hz / 250Hz / 400Hz.
Use the selector to change values (<+/->) and <click> to
confirm.
