INSTALLATION AND OPERATION MANUAL
FIGURE 1 – CNFE2MCPOE MEDIA CONVERTER
CAT5e/6
OPTICAL FIBER
DETERMINED BY
SELECTION OF
SFP MODULE
FIGURE 2 – CNFE2MCPOE MEDIA CONVERTER
FRONT PANEL
TECH SUPPORT: 1.888.678.9427
REAR PANEL
NOTE: Remove Electrical Connector for Rack Mount Units
CNFE2MCPOE
BLACK
BLACK WITH WHITE STRIPE
INS_CNFE2MCPOE_REV–
07/28/10
PAGE 2
