Summary of Contents for Spagna Vetro Vetro SV156 -30/36”
- Page 1 Spagna Vetro Range Hood Under cabinet Model SV156 -30/36” Users Manual 7272 Buller Ave, Burnaby, BC, Canada. Tel: 604 430 5252 www.KitchenHoods.ca...
-
Page 2: Installation Instructions
INSTALLATION INSTRUCTIONS ★ Please check the following items before installation: (A) Environment: Keep the Range Hood far away form the window and for avoiding the air convection if the evaporated oil does not raise to the 25cm effective range of the suction power. -
Page 3: Operation Instructions
OPERATION INSTRUCTIONS SECURE BY 2 MOUNTING SCREW ATTACHED TO THE WALL. LIGHT SWITCH: ON/OFF SWITCH ● : ON SPEED SWITCH OF RIGHT BLOWER MOTOR. R: O I : SLOW II : FAST SPEED SWITCH OF LEFT BLOWER MOTOR. L: O I : SLOW II : FAST LIGHT COVER. -
Page 4: Installation
INSTALLATION • A minimum of 6” round (standard for this range hood) must be used to maintain maximum airflow efficiency. • Always use rigid type metal/aluminum ducts if available to maximize airflow when connecting to provided duct. • ALWAYS, when possible, reduce the number or transitions and turns. If long duct run is required, increase duct size from 6”... -
Page 5: Electrical Requirements
ELECTRICAL REQUIREMENTS IMPORTANT: Observe all governing codes and ordinances. It is the customer’s responsibility: • To contact a qualified electrical installer. • To assure that the electrical installation is adequate and in conformance with National Electrical Code. If codes permit and a separate ground wire is used, it is recommended that a qualified electrician determine that the ground path is adequate. - Page 6 Vent system must terminate to the outside (roof or side wall). • DO NOT terminate the vent system in an attic or other enclosed area. • DO NOT use 4” (10.2 cm) laundry-type wall caps. • Use metal/aluminum vent only. Rigid metal/ aluminum vent is recommended.
-
Page 7: Troubleshooting
TROUBLESHOOTING Problems Fixing Check the plug and the socket. No electric power Check the wires. Check whether the bulb is broken. The bulb does not light. Check whether the switch is damaged Check whether the switch of the motor is damaged. -
Page 8: Wiring Diagram
WIRING DIAGRAM - 7 -... -
Page 9: Specification
SPECIFICATION 30”: 29 ”×20 ”×2 ” DIMENSION (W×D×H) 36”: 35 ”×20 ”×2 ” 30”: 32 ”×6 ”×22 ” PACKING DIMENSION 36”: 38 ”×6 ”×22 ” 120V 60Hz ELEC. SPECIFICATION 6” dia. or 8 ”×2 ” EXHAUST DUCT Twin Motors TRANSMISSION STYLE 2 x 40 W (Max) LIGHTING SYSTEM VOLUME...
