- Page 1 Installation Guide and Users Manual SPAGNA VETRO - 200 Series IMPORTANT: Read and save these instructions. NOTICE: Installer: Leave this guide with the homeowner Homeowner: Keep this guide for future reference Wall Mount Range Hood www.SpagnaVetro.ca...
-
Page 3: Important Safety Notice
Important Safety Notice Read all Instructions before Installing and operating this appliance • The installation in this manual is intended for qualified installers, service technicians or persons with similar qualified background. Installation and electrical wiring must be done by qualified profession- als and in accordance with all applicable codes and standards, including fire-rated construction. • DO NOT attempt to install this appliance yourself. Injury could result from installing the unit due to lack of appropriate electrical and technical background. • Range hood may have very sharp edges; please wear protective gloves if it is necessary to remove any parts for installing, cleaning or servicing. • Activating any switch ON before completing installation may cause ignition or an explosion. • Due to the size and weight of this range hood, two people installation is recommended. To reduce the risk of fire, electric shock, or injury to persons: • For general ventilating use only. DO NOT use to exhaust hazardous or explosive materials and va- pors. - Page 4 Important Safety Notice Read all Instructions before Installing and operating this appliance • Clean ventilating fan frequently. • Always use appropriate cookware and utensils size. • Always use cookware appropriate for the size of the surface element. To reduce the risk of injury to persons in the event of a stove top grease fire: • SMOTHER FLAMES with a close-fitting lid, cookie sheet, or metal tray, then turn OFF the burner. BECAREFUL TO PREVENT BURNS. NEVER PICK UP A FLAMING PAN—you may be burned. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames DO NOT go out immediately, EVACUATE AND CALL THE FIRE DEPARTMENT or dial your local emergency service immediately.
-
Page 5: Table Of Contents
Table of Contents INSTALLATION USE AND CARE Tools needed............3 Troubleshooting...........23 Parts supplied...........4 Use and care information.......24 Venting requirements........5 Specifications..........24 MAINTENANCE Mount heights & clearance......5-6 Calculating vent system length.......6 Cleaning..........25 Venting methods & ductless conversion..7 Replacing filter & light bulb....25-26 WARRANTY Charcoal filters & electrical requirements..8 Preparation............9 Coverage & exceptions.........27 Installation..........10-12 Disclaimer & contact information....28 Range hood operations......13-22 Tools needed: Measuring Marker or tape Utility knife pencil Level Flat-blade and Powered Phillips screw- screwdriver drivers... -
Page 6: Parts Supplied
Parts supplied: Range Hood (vary with model) Flappers Stainless Steel Baffle or Aluminum Filter(s) Mounting Bracket Lower standard chimney Upper standard chimney Charcoal Filter Air diverter Flexible Duct Tube (Optional) (Optional re-circulating kit) (Optional re-circulating kit) Description Quantity Toggle Bolts 2 Pcs Duct Set 1 Set Body Hook (vary with model) 2 Pcs Chimney Mounting Bracket 1 Set This Guide and Warranty Card 1 Set 5mm x 16mm Screw with Washer 4 Set Optional: 4mm x 16mm Tapping Screw 6 Pcs Optional; 4mm x 10mm Tapping Screw 16 Pcs Optional: Toggle Bolt with Tapping Screw for Air Diverter 2 Set Optional: Screw for Charcoal Filter 3 Pcs Page 4... -
Page 7: Venting Requirements
Venting Requirements Height & Clearance • Vent system must terminate to the outside Mounting (roof or side wall). Maximum* ceiling clearance Bracket • DO NOT terminate the vent system in an at- 110” at 31” hood mounting Standard tic or other enclosed area. height above countertop/stove Upper (may vary with different • DO NOT use 4” (10.2 cm) laundry-type wall Chimney model). Chimney extensions caps. Extension available* available for higher ceiling. • Use metal/aluminum vent only. Rigid metal/ aluminum vent is recommended. Standard • DO NOT use plastic vent. -
Page 8: Calculating Vent System Length
IMPORTANT: • A minimum of 6” round (standard for this range hood) or 3-1/4 x 10” rectangular duct (purchased separately) must be used to maintain maximum airflow efficiency. • Flexible 6” round duct provided for convenience, always use rigid type metal/aluminum ducts if available to maximize airflow when connecting to provided duct. • Please use Duct Run Calculation below to compute the total available duct run when using elbows, transitions and caps. • ALWAYS, when possible, reduce the number or transitions and turns. If long duct run is required, increase duct size from 6” to 7” or 8”. If a reducer is used, install a long reducer instead of a pancake reducer. Reduc- ing duct size will restrict airflow and decrease airflow, thus reduce duct size as far away from opening as pos- sible. • If turns or transitions are required: Install as far away from opening and as far apart, between 2, as possible. • Minimum mount height between stove top to hood bottom should be no less than 28-inch*. • Maximum mount height between stove top to hood bottom should be no higher than 31-inch*. • It is important to install the hood at the proper mounting height. Hoods mounted too low could result in heat damage and fire hazard; while hoods mounted too high will be hard to reach and will loose its performance and efficiency. • If available, also refer to stove top manufacturer’s height clearance requirements and recommended hood mounting height above range. -
Page 9: Venting Methods
Venting Methods • This range hood is factory set for venting through the roof or wall. For non-vented (re-circulating) installa- tions, see Recirculating (Non-Vented) Kit on Page 11. • Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed. IMPORTANT: • NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages. All exhaust must be ducted to the outside. • Use metal/aluminum duct work only. • Fasten all connections with sheet metal screws and tape all joints with certified Silver Tape or Duct Tape. • Use caulking to seal exterior wall or roof opening around the cap. Vertical roof venting Horizontal wall venting Option 1: Option 2: Roof cap Side wall cap Ductless Conversion • Ductless conversion is intended for applications where an exhaust duct work is not possible to be installed. When converted, the hood functions as a purifying hood rather than an exhaust hood. Fumes and exhaust from cooking is drawn and filtered by a set of charcoal filters. The air is then purified and re-circulated back within the home. • We recommend to ALWAYS exhaust air outside of the home by employing existing or installing new duct work, if possible. Only when the exhaust option is not possible should you recourse to converting the hood into a purifying unit. -
Page 10: Charcoal Filter Installation
Charcoal Filter Installation NOTE: The charcoal filters are preinstalled if you purchased the range hood with re-circulating kit from us. 1. Remove aluminum filters on hood. 2. Remove the safety filter under the aluminum filter by unscrewing two screws, then position the charcoal filter and align the screw holes, reinstall and fasten two screws. 3. Reinstall the aluminum filters back to the hood. 4. Charcoal filters must be replaced after 120 hours of use (or approximately every 2 to 3 months based on the average of 1 to 2 hours of daily cooking time). Available at your local reseller. Electrical Requirements IMPORTANT: Observe all governing codes and ordinances. It is the customer’s responsibility: To contact a qualified electrical installer. To assure that the electrical installation is adequate and in conformance with National Electrical Code, ANSI/ NFPA 70 — latest edition*, or CSA Standards C22. 1-94, Canadian Electrical Code, Part 1 and C22. 2 No. 0-M91 - latest edition** and all local codes and ordinances. • If codes permit and a separate ground wire is used, it is recommended that a qualified electrician determine that the ground path is adequate. • A 120-volt, 60 Hz, AC-only, fused electrical supply is required on a separate 15-amp circuit, fused on both sides of the line. • Do not ground to a gas pipe. -
Page 11: Preparation
Preparation WARNING Excessive Weight Require three or more person to move and install this range hood. Spinal or other bodily injuries could occur if it is not followed. Advanced Preparations: 1. Read the entire installation guide and users manual thoroughly, understand instructions and warnings. 2. Be familiar with the controls of the range hood by reading through Range Hood Operations, Page 13. 3. Place the range hood on a flat, stable surface. Connect the range hood to a designated standard outlet (please refer the product label for the suitable voltage of this unit) and verify no debris has entered the vent openings, then turn on the range hood. Verify all operations of the range hood by referring to Range Hood Operations, Page 13. -
Page 12: Installation
Installation WARNING Installations (refer to Page 4 for parts): Due to excessive weight, two or more person is recommended for this step. Excessive Weight 1. Locate an optimal location to place the range hood. Mark the Require three or more person to move and leveling points for two Body Hooks (Figure 1) on the wall and install this range hood. Spinal or other bodily drill two holes with diameter not exceeding 5/8”. Insert two injuries could occur if it is not followed. toggle bolts then fasten two 4mm x 16mm Tapping Screws, reserve approximately 1/8” for the body hooks. Be sure to use appropriate anchors for your wall. -
Page 13: Installation
Installation (Continued) If Recirculating (Non-Vented) Kit is NOT purchased, please go back to step 2 on Page 10. 4. Find an optimal location for the Air Diverter. The air diverter must be placed directly above and align with the two body hooks, see Figure 4. Drill four more holes with diameter not exceeding 5/8” and in- sert four toggle bolts. Secure the air diverter with four 4mm x 16mm Tapping Screws as shown in Fig- ure 4. Be sure to use appropriate anchors for your wall. Use four sets of 5mm x 16mm Screw with Washer to install the body hooks onto the hood. Then hang the hood on the wall and tighten the screws. - Page 14 Installation (Continued) 6. Connect the duct tube to the exterior exhaust system or the optional air diverter. Make sure all joints are secure and air tight. Use of duct tape is recommended. 7. Place Upper Chimney and Lower Chimney over the body of the hood as shown in Figure 7A (or Figure 7B of air diverter is present). Slide up the upper duct cover towards the chimney mounting bracket or the optional air diverter. Use four 4mm x 10mm Tapping Screws to secure the upper chimney onto the chimney mounting bracket or the optional air diverter. Finally secure the lower chimney to the hood body by using two 4mm x 10mm Tapping Screws. Figure 7A Chimney Mounting Bracket Upper Chimney 4 x 10 Screw (has vent- ing holes) Lower Chimney 4 x 10 Screw Figure 7B Air Divertor Upper Chimney (has vent- ing holes) 4 x 10 Screw Lower Chimney WARNING 4 x 10 Screw Excessive Weight Require three or more person to move and...
-
Page 15: Range Hood Operations
Range Hood Operations & Wiring Diagram SV200 Series Standard Class (3 Speed Mechanical Control) Low Speed High Speed Power Switch Medium Speed Light Switch Turn On: • Press the speed control (Low Speed, Medium Speed, High Speed) switch to select the desired level of power. Once button is pressed, the previous speed mode will cancel. • Press the Light Switch to power on the lights. CAUTION: DO NOT touch the lights until switched OFF and cooled. Turn Off: • Press the Power Switch to turn off the power. • Press the Light Switch to power off the lights SV200 Series Standard Class Wiring Diagram NOTE: Wiring Diagrams shown above with GU10 light configuration. A transformer is required for MR16 Lights. Page 13... -
Page 16: Range Hood Operations
Range Hood Operations & Wiring Diagram (Continued) SV168/198 Series “E” Class (6 Speed Electronic Touch Control) Power Light Decrease Value Increase Value Blower Power Indicator Power-On Elapsed Digital Timer Blower Speed Indicator Power-Off Delay Digital Timer Light Power Indicator Power-Off Delay Timer Indicator This range hood is designed to remove smoke, cooking vapors and odors from the cook top area. For best results, start the range hood before cooking and allow it to operate several minutes after the cooking is completed to clear all smoke and odors from the kitchen. • Button functions: • Power: Power ON/OFF the range hood and activate power-off delay timer. • Decrease Value: Blower (motor) speed decrease, timer value decrease, and enter timer mode. • Increase Value: Blower (motor) speed increase timer value increase, and cumulative timer reset. • Blower Power Indicator: Lights up when blower (motor) is running. • Blower Speed Indicator: Shows current blower (motor) speed (1-6). • Light Power Indicator: Lights up when lights turned on. • Light: Turns ON/OFF and dim halogen lights. • Power-On Elapsed Digital Timer: Indicates the accumulated time the system is running. • Power-Off Delay Digital Timer: Indicates the length of time left for delay off function. • Power-Off Delay Timer Indicator: Lights up when auto-shutdown delay timer function is on. -
Page 17: Level
Range Hood Operations & Wiring Diagram (Continued) SV200 Series “E” Class (6 Speed Electronic Touch Control) Power Light Decrease Value Increase Value Blower Power Indicator Power-On Elapsed Digital Timer Blower Speed Indicator Power-Off Delay Digital Timer Light Power Indicator Power-Off Delay Timer Indicator • Controls: • Adjusting the timer function: • While the blower (motor) is not running, press and hold Decrease Value button over 3 seconds to enter timer mode. Adjust to desired period of delay off timer by pressing Increase Value or Decrease Value button (minimum 1 minute to maximum 15 minutes). This setting will be saved immediately. • Activating the timer function: • While the blower (motor) is running, press and hold Power button for over 3 seconds to activate delay off timer. Power-off delay indicator will lit up and power-off delay digital timer will begin to countdown, when it reaches zero, the blower (motor) will shut down. • Adjusting the light: • Press Light button once to turn on the lights, and once again to turn off the lights. -
Page 18: Wiring Diagram
Wiring Diagram SV200 Series “E” Class Wiring Diagram (6 Speed with GU10 Bulb) Page 16... -
Page 19: Troubleshooting
• Make sure the power is on high speed for heavy cooking. 6. Purpose of the slots/holes/openings near the top of • These slots/holes/openings are used to exhaust the upper chimney: cleaned air with optional re-circulating kit. If you did not install one, you do not need them. NOTE: For all other inquiries, please contact your SPAGNA VETRO local reseller. Page 17... -
Page 20: Use And Care Information
Use and Care Information Operations: • Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. • Always leave safety grills and filters in place. Without these components, operating blowers could catch on to hair, fingers and loose clothing. • NEVER dispose cigarette ashes, ignitable substances, or any foreign objects into blowers. • NEVER leave cooking unattended. When frying, oil in the pan can easily overheat and catch fire. The risk of self combustion is higher when the oil has been used several times. • NEVER cook on “open” flames under the range hood. Check deep-fryers during use: Superheated oil may be flammable. Cleaning: • The saturation of greasy residue in the blower and filters may cause increased inflammability. Keep unit clean and free of grease and residue build-up at all times to prevent possible fires. • Filters must be cleaned periodically and free from accumulation of cooking residue (see cleaning instructions on Page 22). Old and worn filters must be replaced immediately. • Do not operate blowers when filters are removed. Never disassemble parts to clean without proper instruc- tions. Disassembly is recommended to be performed by qualified personnel only. Read and understand all instructions and warnings in this manual before proceeding. Specifications Specifications Body Stainless Steel / Tempered Glass Power Rating 120V/60Hz (USA & Canada standard) General Input Power 160W + # of Light x Votage of Light Motor Input Power... - Page 21 WARNING Maintenance SAFETY WARNING: Never put your hand into area housing the fan while the fan is operating! Hazard of Burns! For optimal operation, clean range hood & all filter/oil container regu- Light bulb become extremely hot when turned on. larly. Regular care will help preserve the range hood’s performance & DO NOT touch bulb until switched off and cooled. appearance.
- Page 22 Maintenance (Continued) Replacing J4 Type Halogen Light Bulb: • This range hood uses halogen light bulb: 20W 12V (Product ID: SV-ACS-HAL20W-B). • Make sure the range hood is unplugged or turn OFF breaker and the lights are cool to touch. • Place a small flat-head screwdriver between light housing and lens cover, carefully and gently pry up the lens cover. • Remove the old halogen light bulb by pulling in the direction of wavy arrow. Do not touch the new light bulb with bare hands. • Reverse the steps to install a new halogen light bulb. Turn ON breaker and range hood to test for operation. Light Housing Halogen Bulb Lens Cover Lens Cover Flat-head Screwdriver Lens Cover Replacing MR16 / GU10 Type Halogen Light Bulb: • This range hood uses halogen bulb (please refer to the actual specification of the hood purchased): USA/Canada: 35W Type MR16 12V / Type GU10 120V Europe and other Countries:...
- Page 23 Warranty TO OBTAIN SERVICE UNDER WARRANTY: You must present proof of original purchase date. Please provide an original dated proof of purchase (sales receipt / invoice) in order to obtain service under warranty. One Year Parts Warranty: For one year from the date of original purchase, your local reseller will provide free of charge, non-consumable replace- ment parts or components that failed due to manufacturing defects. Subject to the conditions and limitations set forth below, your local reseller will, at its option, either repair or replace any part of its products that prove defective by reason of improper workmanship or materials. Repaired parts or replacement products will be provided by your local reseller on an exchange basis, and will be either new or refurbished to be functionally equivalent to new. The consumer is re- sponsible for all shipping costs. Consumable parts not covered by this warranty include but not limited to: Light bulbs, metal, aluminum and charcoal filters. Who is Covered: This warranty is extended to the original purchaser for products purchased for ordinary home use. This Warranty Will Be Voided When: Product damaged through negligence, improper installation, accident, abuse, misuse, natural disaster, insufficient or excessive electrical supply, abnormal mechanical or environmental conditions, or any unauthorized disassembly, repair, modification, or failure to follow installation instructions. When product is used commercially or other than its intended purpose. Damaged because of improper connection with equipment of other manufacturers. Repaired or modified by anyone other than your local reseller’s authorized agents. This limited warranty also does not apply to any product on which the original identification information has been altered, obliterated or removed, has not been handled or packaged correctly or has been sold as second-hand. What is Not Covered: Consumable parts such as light bulbs, metal and charcoal filters. The natural wear of finish, and wear due to improper maintenance, use of corrosive and abrasive cleaning products, pads, and oven cleaner products. Chips, dents or cracks due to abuse, misuse, freight damage, or improper installation. Damage of product caused by accident, fire, floods or act of God. The manufacturer and/or distributor/reseller is not liable for, and does not cover under warranty, any loss of properties or any costs associated with removing, servicing, installing, or determining the source of problems with this product. This warranty is valid in the country of the original purchase at retail. It is non-transferable and applies only to the original purchaser and does not extend to subsequent owners of this product. Any applicable implied warranties, including the war- ranty of merchantability, are limited in duration to a period of express warranty as provided herein beginning with the date of original purchase at retail and, no warranties, whether express or implied, shall apply to this product thereafter. To obtain warranty service, you may contact your local reseller from which you purchased this product. Please confirm the terms of your local reseller’s policies prior to contacting. Typically, you must include product identification information, including model number and serial number with a detailed description of the problem you are experiencing. You must also include proof of the date of original retail purchase as evidence that the product is within the applicable warranty period.
- Page 24 Disclaimer Carefully inspect all items for damages before accepting delivery. note any damages on the freight bill or express receipt. request name and signature of the carrier’s agent and keep copy to support your claim. Upon acceptance of items, owner assumes responsibility for its safe arrival. Report damages to the carrier and file a claim immediately. Failure to do so may result in the denial of your claim. The carrier will furnish you with necessary forms for filing a claim. Damages caused during transit are not covered under our warranty. Please contact us to file an insurance claim. Please inspect contents of package(s) carefully upon receiving! We must be notified of any damages and/or missing parts within five (5) days upon your receipt of package(s). Claims will not be accepted after five (5) days. NOTE: Items were thoroughly tested and carefully packed in our factory before shipping. Products must be returned in good working condition with ALL original parts and documentation packed in ALL original cartons, fillers and shipping cartons. A restocking fee of 15% will be charged for all approved return(s). Exchanges or returns may not be accepted if any packaging is missing. Make sure to inspect the hood for damages and defects before installation. Appearance flaws of the hood found after installation and not affecting hood performance is not covered under our warranty for returns or exchang- es. Service visits not covered under warranty will carry a service charge. Before Installation: Return for exchange or refund (please see above for acceptable returns). After Installation: NO exchange or refund. Contact Us If you need any assistance, please contact your local reseller. Please have your order number and model of the range hood ready. This information will help them better respond to your request. If you need replacement parts, we recommend that you only use genuine parts. Our accessories and parts are engineered and designed specifically for this series of range hood, each is rigorously tested assuring the utmost in durability and reliability, providing a factory match, factory-installed appearance and functionality tailored to each individual range hood model. Page 22 The information in this document is subject to change without notice, please contact your local reseller for updated details.
- Page 25 Your Notes Page 23...
- Page 26 SPAGNA VETRO RANGE HOOD SV200 Series - Wall Mount Burnaby, BC, Canada www.SpagnaVetro.ca...
