Page 1
Installation Guide and Users Manual SPAGNA VETRO SV300 SERIES IMPORTANT: Read and save these instructions. NOTICE: Installer: Leave this guide with the homeowner Homeowner: Keep this guide for future reference Wall and Island Mount Installation www.spagnavetro.ca...
Important Safety Notice Read all Instructions before Installing and operating this appliance • The installation in this manual is intended for qualified installers, service technicians or persons with similar qualified background. Installation and electrical wiring must be done by qualified profession- als and in accordance with all applicable codes and standards, including fire-rated construction. • DO NOT attempt to install this appliance yourself. Injury could result from installing the unit due to lack of appropriate electrical and technical background. • Range hood may have very sharp edges; please wear protective gloves if it is necessary to remove any parts for installing, cleaning or servicing. • Activating any switch ON before completing installation may cause ignition or an explosion. • Due to the size and weight of this range hood, two people installation is recommended. To reduce the risk of fire, electric shock, or injury to persons: • For general ventilating use only. DO NOT use to exhaust hazardous or explosive materials and va- pors.
Important Safety Notice Table of Contents Read all Instructions before Installing and operating this appliance INSTALLATION USE AND CARE Tools needed............3 Troubleshooting...........23 • Clean ventilating fan frequently. Parts supplied...........4 Use and care information.......24 • Always use appropriate cookware and utensils size. Venting requirements........5 Specifications..........24 • Always use cookware appropriate for the size of the surface element. Mount heights & clearance......5-6 MAINTENANCE Calculating vent system length.......6 Cleaning..........25 To reduce the risk of injury to persons in the event of a stove top grease fire: Venting methods &...
Parts supplied: Island Hoods Parts supplied: Wall hoods Range Hood (vary with model) Flappers Upper Standard Chimney Lower Standard Chimney Support frame extension Grease/Oil Cup (Length varies with ceiling height) (Optional) Aluminum Filter(s) Mounting Brackets Qty: 32 PCS Lower standard chimney Upper standard chimney Qty: 4 PCS Flappers Qty: 32 PCS Charcoal Filter Flexible Duct Tube (Optional) (Optional re-circulating kit) Qty: 4 PCS Description Quantity Qty: 4 PCS Toggle Bolts 2 Pcs (Optional with re-circulat- ing kit. Pre-installed when Charcoal filter Duct Set 1 Set kit ordered together with...
Venting Requirements Height & Clearance IMPORTANT: • A minimum of 6” round (standard for this range hood) or 3-1/4 x 10” rectangular duct (purchased separately) • Vent system must terminate to the outside Mounting must be used to maintain maximum airflow efficiency. (roof or side wall). Maximum* ceiling clearance Bracket • Flexible 6” round duct provided for convenience, always use rigid type metal/aluminum ducts if available to • DO NOT terminate the vent system in an at- 110” at 31” hood mounting Standard maximize airflow when connecting to provided duct. tic or other enclosed area. height above countertop/stove Upper • Please use Duct Run Calculation below to compute the total available duct run when using elbows, transitions (may vary with different • DO NOT use 4” (10.2 cm) laundry-type wall Chimney and caps.
Venting Methods Charcoal Filter Installation NOTE: The charcoal filters are preinstalled if you purchased the range hood with re-circulating kit from us. • This range hood is factory set for venting through the roof or wall. For non-vented (re-circulating) installa- 1. Remove aluminum filters on hood. tions, see Recirculating (Non-Vented) Kit on Page 11. 2. Remove the safety filter under the aluminum filter by unscrewing two screws, then position the charcoal filter • Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed. and align the screw holes, reinstall and fasten two screws. IMPORTANT: 3. Reinstall the aluminum filters back to the hood. • NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages. 4. Charcoal filters must be replaced after 120 hours of use (or approximately every 2 to 3 months based on the All exhaust must be ducted to the outside. average of 1 to 2 hours of daily cooking time). Available at your local reseller. • Use metal/aluminum duct work only. • Fasten all connections with sheet metal screws and tape all joints with certified Silver Tape or Duct Tape. Electrical Requirements • Use caulking to seal exterior wall or roof opening around the cap. Vertical roof venting Horizontal wall venting IMPORTANT: Observe all governing codes and ordinances.
Preparation Installation: Wall Hoods WARNING This range hood come with mounting brackets, one main and one or two additional for the chimney cover. The range hoods shall be placed at a distance of 28-31” from the cooking surface for best performance. See Excessive Weight Page 5. Require three or more person to move and install this range hood. Spinal or other bodily b) Drill three Ø8 mm holes in a horizontal line at the appropriate height for installation of the mounting bracket. injuries could occur if it is not followed. Advanced Preparations: c) Insert brick anchor bolts (drywall anchor) into the holes , fix the mounting bracket on the wall, then secure 1. Read the entire installation guide and users manual thoroughly, understand instructions and warnings. the cooker hood to it see Pic 2.
Installation: Island Hoods Installation (Continued) 1. Align upper support frame with holes in ceiling. Mount the upper support frame to the ceiling using four “A” screws (for sheet rock only). Make sure that the upper Recirculation Mode support frame is securely fastened to the joist or support (requires optional charcoal filters 4 ) in the ceiling. Attach support frame to ceiling using an- chors recommended for your type of ceiling: If you do not have access to outside, you will need to • Sheet rock ceiling: Attach support frame to ceiling...
Page 9
Installation: Island Hoods-2 Range Hood Operations & Wiring Diagram 9. Have a third person raise up and hold the island range hood in position, connect power plug to the 12” hanging SV300 Series Standard Class (3 Speed Mechanical Control) electrical cord, and connect the duct work to the range hood. 10. Mount the hood to the lower support frame using four “D” bolts and four “E” nuts: Securely fasten two “E” Low Speed High Speed nuts to two “D” bolts by reaching up from the underside of the hood. Repeat this step to secure the other side using two “E” nuts to two “D” bolts. 11. After all four “D” bolts and four “E” nuts securely fastened, connect the lower end of the duct tube to the hood and slide the lower chimney cover down carefully so that it sits on top of the hood. 12. Install grease cup and aluminum filters then check the operation of the range hood. Island Hood Installation Overview Medium Speed Power Switch Light Switch Turn On: • Press the speed control (Low Speed, Medium Speed, High Speed) switch to select the desired level of power. Once button is pressed, the previous speed mode will cancel. • Press the Light Switch to power on the lights. CAUTION: DO NOT touch the lights until switched OFF and cooled. Turn Off: • Press the Power Switch to turn off the power.
Range Hood Operations ( Electronic control ) Troubleshooting Range Hood Operations- Electronic switch: Use 1,2,3 and 4 to choose the fan speed. The light control is on seperate switch 1. If the range hood or halogen light does not operate • Check if the range hood has been plugged in, make after installation: sure that all power has been turned back ON, fused Control Panel Layout and LED Configurations: not blown and all electrical wiring are properly con- nected. • Swap out light assembly to working ones to deter- mine whether it is caused by defective bulbs. See Replacing the light bulbs on Page 22-23. 2. The range hood vibrates when the blower is on: • The range hood might not have been secured prop- erly on to the ceiling or wall. Check with your in-...
Use and Care Information Maintenance WARNING SAFETY WARNING: Never put your hand into area housing the Operations: fan while the fan is operating! Hazard of Burns! For optimal operation, clean range hood & all filter/oil container regu- • Read and understand all instructions and warnings in this manual before operating the appliance. Save these Light bulb become extremely hot when turned on. larly. Regular care will help preserve the range hood’s performance & instructions for future reference. DO NOT touch bulb until switched off and cooled.
Maintenance Warranty (Continued) Replacing J4 Type Halogen Light Bulb: TO OBTAIN SERVICE UNDER WARRANTY: • This range hood uses halogen light bulb: 20W 12V (Product ID: SV-ACS-HAL20W-B). You must present proof of original purchase date. • Make sure the range hood is unplugged or turn OFF breaker and the lights are cool to touch. • Rotate the light housing and lens cover counter clockwise, carefully and gently pry up the lens cover. Please provide an original dated proof of purchase (sales receipt / invoice) in order to obtain service under warranty. • Remove the old halogen light bulb by pulling in the direction of wavy arrow. Do not touch the new light bulb with bare hands. One Year Parts Warranty: • Reverse the steps to install a new halogen light bulb. Turn ON breaker and range hood to test for operation. For one year from the date of original purchase, your local reseller will provide free of charge, non-consumable replace- ment parts or components that failed due to manufacturing defects. Subject to the conditions and limitations set forth WARNING below, your local reseller will, at its option, either repair or replace any part of its products that prove defective by reason of improper workmanship or materials. Repaired parts or replacement products will be provided by your local reseller on an exchange basis, and will be either new or refurbished to be functionally equivalent to new. The consumer is re- sponsible for all shipping costs. Consumable parts not covered by this warranty include but not limited to: Light bulbs, Hazard of Burns! metal, aluminum and charcoal filters. Light bulb become extremely hot when turned on. Who is Covered: DO NOT touch bulb until switched off and cooled.
Page 13
Disclaimer Carefully inspect all items for damages before accepting delivery. note any damages on the freight bill or express receipt. request name and signature of the carrier’s agent and keep copy to support your claim. Upon acceptance of items, owner assumes responsibility for its safe arrival. Report damages to the carrier and file a claim immediately. Failure to do so may result in the denial of your claim. The carrier will furnish you with necessary forms for filing a claim. Damages caused during transit are not covered under our warranty. Please contact us to file an insurance claim. Please inspect contents of package(s) carefully upon receiving! We must be notified of any damages and/or missing parts within five (5) days upon your receipt of package(s). Claims will not be accepted after five (5) days. NOTE: Items were thoroughly tested and carefully packed in our factory before shipping. Products must be returned in good working condition with ALL original parts and documentation packed in ALL original cartons, fillers and shipping cartons. A restocking fee of 15% will be charged for all approved return(s). Exchanges or returns may not be accepted if any packaging is missing. Make sure to inspect the hood for damages and defects before installation. Appearance flaws of the hood found after installation and not affecting hood performance is not covered under our warranty for returns or exchang- Spagna Vetro Appliances Inc. es. Service visits not covered under warranty will carry a service charge. 7272 Buller Ave Before Installation: Return for exchange or refund (please see above for acceptable returns). After Installation: NO exchange or refund. Burnaby, BC, Canada www.KitchenHoods.ca Contact Us If you need any assistance, please contact your local Spagna Vetro reseller or call 604 430 5252. Please have your order number and model of the range hood ready. This information will help them better respond to your request. If you need replacement parts, we recommend that you only use genuine parts. Our accessories and parts are engineered and designed specifically for this series of range hood, each is rigorously tested assuring the utmost in durability and reliability, providing a factory match, factory-installed appearance and functionality tailored to each individual range hood model. Page 22 The information in this document is subject to change without notice, please contact your local reseller for updated details.
