B
This appendix describes the specifications for the 3C619C
adapter and contains the following sections:

Cabling

Pin Assignments

Configuration Options
Cabling
3C619C adapters support industry-standard token ring
cabling that follows IEEE 802.5 specifications. Use cabling
type 3 (UTP) or types 1 or 6 (STP).
Pin Assignments
The 3C619C adapter can be connected to a network with
either a DB-9 or an RJ-45 connector. Figure B-1 and Figure B-2
illustrate the pin assignments for each of these connectors.
S
PECIFICATIONS
