7 When the next screen appears, select Configuration and
Diagnostic Program.
8 Highlight Install and press [Enter].
9 Press [Enter] to select Configure Adapter.
A screen similar to the one shown in Figure 4-3 appears.
Quit Install Test
Configuration Mode
l/O Base Address
Interrupt Request Level
Ring Speed
BIOS/MMIO Base Address
Shared RAM Address Range
Memory Mode
I/O Mode
IRQ Driver Type
Auto Switch
Boot PROM
Modify
[ENTER]=Change the Setting
[ ]=Scroll
[Alt]+<Highlighted Key>=Execute Function
Figure 4-3 Adapter Configuration Screen
10 Use the arrow keys to highlight a desired parameter option
and press [Enter].
A second dialog box appears.
11 Use the arrow keys to scroll through the list of settings for
that option. Select a setting and press [Enter].
12 Continue this procedure with any of the other options.
13 Press [Tab] three times to highlight <OK>. Press [Enter].
You must highlight <OK> and press [Enter] to save the new
settings to the adapter.
Changing Software Option Settings
Diagnostic and Manual Configuration Program
View Select
Adapter Configuration
TokenLink III Adapter Configuration
File Options
3Com
A20h
3
16 Mbps
CC000h
D8000h - DBFFFh
16 bit
16 bit
Edge Triggered
Enabled
Enabled
OK
4-7
F1=Help
Cancel
