If you want to run the tests continuously, select the Continuous
option in the Test Setup dialog box, as described in the next
section, "Changing the Test Setup."
Quit Install Test
Run Tests...
Test Setup... (F6)
3Com 3C619C: Token Ring Address = 00608C112233
[ENTER]=Run the Diagnostic Tests
[Alt]+<Highlighted Key>=Execute Function [ ]=Scroll
[F1]=Help [F3]=Exit [F4]=Configure Adapter [F6]=Test Setup
Figure 7-3 Test Menu
Quit Install Test
3Com 3C619C Token Ring Address = 0060BC112233
Group 1 Tests
MMIO Register Write/Read Test
Boot PROM Test (If installed & recognized)
AIP Checksum Test
Shared RAM Boundary/Domain Test
Shared RAM Write/Read Test
Timer Test
Open Adapter for Ring Operation Test
Ring Operations Test
Close Adapter Test
Group 2 Tests
Adapter Wrap Test
Waiting for <Start>
Start Continue Test Setup... Zoom... Stats... File Options...
[ENTER]=<Start> Begin Diagnostic Tests
[Alt]+<Highlighted Key>=Execute Function
[TAB]=Next Field [SHIFT+TAB]=Previous Field [F1]=Help [ESC]=Cancel
Figure 7-4 Run Tests Dialog Box
Diagnostic and Manual Configuration Program
View Select
(F5)
Selected Adapter
TokenLink III 16-bit ISA Adapter
Diagnostic and Manual Configuration Program
View Select
Test Results
Diagnostic Test Types
Run
Repetitions Completed
Repetitions Completed
Pass
F1=Help
F1=Help
Results
0 Not Tested
0 Not Tested
0 Not Tested
0 Not Tested
0 Not Tested
0 Not Tested
0 Not Tested
0 Not Tested
0
Results
Disabled
0 of 1
Cancel
