2-6 C 2: I
HAPTER
Figure 2-3 Removing the Backplate
2 Remove the screw holding the expansion slot's backplate,
as shown in Figure 2-3.
Your PC may look different from the one illustrated, particularly if
it is an EISA PC. With an EISA PC, use any empty slot.
3 Insert the 3C619C adapter into the empty expansion slot,
as shown in Figure 2-4, and secure it with the screw you
removed earlier.
4 Replace the PC's cover.
5 Proceed to the next section, "Connecting to the Network."
3C619C A
NSTALLING THE DAPTER
