Changing the Test Setup

If you want to change the test parameters, follow these steps:
1 Choose the <Test Setup> command button in the Run Tests
dialog box shown in Figure 7-4.
The Test Setup dialog box appears, as shown in Figure 7-5.
Quit Install
Group Select
Group 1
Group 2
Repetitions
(.) [1
Continuous
Errors
[X] Halt on Error
[ ]=Select a Test Group to View
[Alt]+<Highlighted Key>=Execute Function
[TAB]=Next Field [SHIFT+TAB]=Previous Field [F1]=Help [ESC]=<Cancel>
Figure 7-5 Test Setup Dialog Box
2 Press [Tab] to move from field to field and highlight any
field within the Test Setup dialog box.
Within the Group Select area, use the arrow keys to highlight
Group 1 or Group 2. Use the <Enable Group> or <Disable
Group> command buttons to enable or disable a group of tests.
For a description of these tests, refer to the on-line help in
the diagnostic program.
3 When you are satisfied with the new test setup, highlight
the <OK> command button and press [Enter].
4 To run the tests, choose Run Tests from the Test menu and
select the <Start> button.
7: T
ROUBLESHOOTING
Diagnostic and Manual Configuration Program
Test View Select
MMIO Register Write/Read Test
AIP Checksum Test
Shared RAM Boundary/Domain Test
Shared RAM Write/Read Test
Timer Test
Open Adapter for Ring Operation Test
Ring Operations Test
Close Adapter Test
]Times
Defaults
File Options...
Test Setup
Group 1 Tests
Enable Group
F1=Help
*Enabled
*Enabled
*Enabled
*Enabled
*Enabled
*Enabled
*Enabled
*Enabled
Disable Group
OK Cancel
