Operating principles of robot cleaner 최적의 청소를 위한 참고사항
Running of robot cleaner
This product recognizes the image of the ceiling with camera then cleans while drawing a map.
The robot cleaner decides the finished area and area to clean by itself. It draws the most effective
map for cleaning and operates according to the map.
With more than 20 detection sensors, it can avoid wall or objects (chair, vase, etc).
It recognizes the location even in front of fixed object with more than 13mm high and does not
fall down on the stairs with its floor detection sensor.
Suction of robot cleaner
This product has one main brush, two side-brushes and vacuum suction duct.
Side-brush gathers the dust on the floor by spinning and main brush will sweep up by rotating.
Fine dust will pile up in the dust bin through vacuum suction duct.
Empty the dust bin after use and wipe the main brush & side-brush regularly.
For further information, refer to <<Product control and maintenance>>(p.13~).
Using remote control
It is more convenient when you operate the robot cleaner with remote control.
- Press the power button of the remote control to start robot cleaner. Press power button to
stop the operation of the robot cleaner when it's cleaning.
- User can choose one from four modes with Mode select button. Select Auto-mode for
general cleaning. For wet mop cleaning, select Mopping mode. Carpet mode is for
cleaning the carpet and Climb mode is for cleaning the area with threshold.
For further information, refer to <<Cleaning mode>>(p.12).
- The strength of suctioning will be higher by pressing Turbo button.
- Use Base button to charge.
- Use Clock button to set the time.
- Use Timer button to timer the cleaning.
- Use direction button to change the movement of the robot cleaner.
- Backward direction button of the remote control does not work.
Necessary information
- This product is systemized to have the same starting spot and returning spot. It must start
cleaning from the charging station to be able to return to the charging station after cleaning.
(If the robot cleaner started from other spot, it will return to where it started after cleaning.)
- If the battery is not enough when the robot cleaner is operating, it will return to charging
station for re-charge. After charging, robot cleaner will return to its last location to resume
cleaning.
