Change antibacterial filter
Ultra microfiber mop control
14
4.Clean the filter using
the cleaning brush.
1
2
1. Separate the dust bin from the main body then
2. Change the used antibacterial filter to new one
after dividing the filter.
※ The white side of the antibacterial filter to the filter case then assemble.
3. Insert the dust bin with new antibacterial filter to the main body.
1. Separate the microfiber mop from the mop board.
2. Dry it thoroughly after cleaning.
(※ Refer to page 8 for assembly.)
6. Attach the filtering device
to the dust bin then insert it
to the main body.
divide the filter of the dust bin.
5. After cleaning, align
the black rubber border
side to the filtering
device then assemble.
